GENESIS-II DIRECTIONAL

2. Installation

Use the following instructions to mount your Genesis-II
Directional.

2.1 Separating the Computer/Display Unit (optional)

If the space in your vehicle is at a premium, you will
appreciate Genesis-II Directional's compact size and
versatile components. You can separate and remotely
mount the computer unit from the display unit.
Common places to mount it are behind the dash, under
the driver's seat, or on the console.
To separate the combined unit, firmly grasp the ends
and pull them apart.
Note the 9-pin connectors on each half of the unit.
Screw two standoffs into the holes next to each
connector to attach the two pieces with the 9-pin
connector cable.
10
™
USER'S AND INSTALLATION MANUAL
Figure 2.1a Separating the computer/display unit.
Rev. 02/05
