- Page 1 CD100A COMBUSTIBLE GAS DETECTOR Kane International Ltd Kane House Swallowfield Welwyn Garden City Hertfordshire AL7 1JG Tel: 01707 375550 Fax: 01707 393277 Stock No: 17444-2 June 2004 Downloaded from Elcodis.com electronic components distributor...
-
Page 2: Product Features
PRODUCT FEATURES Flexible Gooseneck Audible Leak Indicator Visual Leak Tic Adjustment indicator (located on the side of Low Battery the unit) Indicator Protective Boot Power On Light Gooseneck Clip Solid State semi- Socket for Optional conductor sensor Earphone Sensor Cover Tip Light Downloaded from Elcodis.com... -
Page 3: General Description
GENERAL DESCRIPTION This instrument is an advanced combustible gas leak detector, capable of locating many combustible, non combustible and toxic gases. A partial list of these gases include: Acetone Jet Fuel Alcohol Lacquer Thinners Ammonia Methane Benzene Naphtha Butane Natural Gas Ethylene Propane Gasoline - Petrol... -
Page 4: Operation
Operation Turn the instrument on by rotating the thumbwheel downwards in a non-contaminated environment. i.e. Fresh Air. The green Power LED will be illuminated when the unit is turned on. If the battery level is low then the red LED will be steady and the tic rate will not be adjustable. -
Page 5: Battery Replacement
The ‘Tip-light’ is used to see around the area of the leak when in a dark environment. When this instrument is used in noisy environments, look at the red LED which flashes more rapidly as the tic rate increases. The optional earphone can be plugged into the unit’s side if there is high background noise or the operator does not want to disturb other people. -
Page 6: Electromagnetic Compatibility
ELECTROMAGNETIC COMPATIBILITY The European Council Directive 89/336/EEC requires that electronic equipment does not generate electromagnetic disturbances that exceed defined levels and has an adequate level of immunity to enable it to be operated as intended. The specific standards applicable to this product are detailed in the appendices. - Page 7 At the time of writing this manual (April 1998) there is no awareness of any field based situation where such interference has ever occurred and this advice is only given to satisfy the requirements of the Directive. Sensor Filter and Sensor Replacement The sensor is housed at the tip of the gooseneck assembly.
-
Page 8: Specifications
Specifications Power Supply 1 x 9V battery (alkaline preferred) Sensor Solid state semi conductor Sensitivity <50ppm methane Indicators Audible: Adjustable tic rate Visual: Flashing LED Warm-up 10 seconds Response Time Instantaneous Duty Cycle Continuous Battery Life 5 hours typical use Dimensions 8 “... - Page 9 EN 61000-6-3 EN 61000-6-1 and is certified to be compliant Specification EC/EMC/KI/CD100A details the specific test configuration, performance and conditions of use. Please Note: Batteries used in this instrument should be disposed of in accordance with current...
