MIDI Settings in the BK for the communication with GESINI
Settings required in the
MIDI Set of the BK-7m
for the communication
with GERD
The BK-7m must be prepared to communicate with the PC via MIDI/USB. Obviously
you have to connect the BK-7m to the PC. This can be done either with an USB cable
or with two MIDI cables for MIDI IN and MIDI OUT (MIDI cables require additionally
a MIDI-USB-Interface at your PC). Both approaches provide the identical
functionality.
Comment: If you use the USB cable to connect the BK to the PC, the MIDI ports of
the BK can be used to connect further MIDI controllers (e.g. keyboard, organ,
accordion, etc.) to the BK.
Connection via USB
If you have problems to find the appropriate driver on the websites of Roland, please
contact GESINI's support team.
Connection via MIDI cables and MIDI/USB interface
(c) 2017 by SINEGA GmbH
If you connect your BK via USB to the PC,
please make sure that you have installed
the latest "Arranger Driver" from Roland
for your Windows operating system.
These drivers are provided by Roland for
download in the support/download areas
of Roland's websites and they are included
in the installation package of GERD.
www.gesini.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BK-7m and is the answer not in the manual?

Questions and answers

Summary of Contents for Roland BK-7m

  • Page 1 The BK-7m must be prepared to communicate with the PC via MIDI/USB. Obviously you have to connect the BK-7m to the PC. This can be done either with an USB cable or with two MIDI cables for MIDI IN and MIDI OUT (MIDI cables require additionally a MIDI-USB-Interface at your PC).
  • Page 2 OS, please upgrade your BK to V1.07. Further information on how to check the version of the OS and on how to upgrade the OS can be found in the Owner's Manual of the BK. This manual is provided by Roland for each BK. 1.2. Version of...
  • Page 3 MIDI Settings in the BK for the communication with GESINI 2.2. 'Connection Wizard' of the BK The BK-7m offers a 'Connection Wizard'. For the first tests of GERD we recommend to ignore this wizard. Because if you select an operating mode with this wizard, some settings are made automatically which cannot be changed later in the menu of the BK.
  • Page 4 The BK allows in its default settings external access only to the "Tone Parts" UP1, UP2, LWR, and MBS. If you use the BK-7m, you can control these parts with an external controller keyboard. In case you are using a BK-5 or BK-9, you can use the (internal) keyboard to address these parts.
  • Page 5 According to the MIDI Implementation of the BK series, the style parts can only be switched on or off with NRPN MIDI messages. But any further changes of any parameter of these parts (e.g. sounds, volume) are disabled by Roland. System Settings for full controlling with GERD Selection of Sounds, Controllers, etc.
  • Page 6 GERD  MENU  MIDI  Edit System  Style  Rx  Style Volume On Selection of internal styles of the BK-7m with GERD  MENU  MIDI  Edit System  Style  Rx  Style PcRx On (c) 2017 by SINEGA GmbH www.gesini.com...
  • Page 7 MIDI Settings in the BK for the communication with GESINI Selection of Performances on the USB stick with GERD  MENU  MIDI  Edit System  Basic  Rx On  Tx On  Performance PcRx On  Performance PcTx On 2.4.
  • Page 8 (Format 0 and 1). Substitute patches, modify effect settings, etc.  Style Edit Edit and adapt styles (Roland style format). Substitute patches, modify effect settings, etc. A sub mode to play the styles in the BK and to control them with GERD available.
