Powerleap PL-PROMMX Manual page 12

8
SW1: Pins 1, 2, & 3
Pins 1, 2, & 3: Clock Multiplier
CLKMUL 6x
SW1: Pin 1
ON
SW1: Pin 2 OFF
SW1: Pin 3 OFF
SW1: Pins 4, 5, 6, 7, & 8
Pins 4, 5, 6, 7, & 8: Core Voltage
Core Volt. 3.5V
CPU TYPE C6
WinChip2
SW1: Pin 4 ON
SW1: Pin 5 ON
SW1: Pin 6 ON
SW1: Pin 7 ON
SW1: Pin 8 OFF
For systems with an external clock speed of less than 66MHz,
there may be a slight performance sacrifice for your new
CPU. For example, changing to a K6-2/400 from a
Pentium-75 will result in a system upgrade speed of 300MHz
(not 400MHz). In this case, you can get improved
performance by adjusting the external clock speed to
66MHz.
PowerLeap Installation Guide
™
The PowerLeap
5.5x 5x 4.5x
OFF OFF ON
OFF ON ON
ON ON ON
3.2V 2.9V
K6-233 K6-200
6x86MX
MII
OFF ON
OFF OFF
ON OFF
ON ON
OFF OFF
PL-ProMMX
™
4x 3.5x 3x
ON OFF OFF
OFF OFF ON
ON OFF OFF OFF
2.8V 2.4V 2.2V
P55C K6-2/450 K6-266
K6-300
K6-2
OFF OFF OFF
OFF OFF ON
OFF ON OFF
ON OFF OFF
OFF OFF OFF
2.5x
ON
ON
