MIXED FUEL
COOKER
ZCM 600 W
ZCM 610 X
INSTRUCTION BOOKLET
1
Please read this instruction booklet before using the appliance

Advertisement

loading

  Related Manuals for Zanussi ZCM 610 X

  Summary of Contents for Zanussi ZCM 610 X

  • Page 1 MIXED FUEL COOKER ZCM 600 W ZCM 610 X INSTRUCTION BOOKLET Please read this instruction booklet before using the appliance...
  • Page 2: Important Safety Information

    Important Safety Information You MUST read these warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 08705 727727 Installation This cooker must be installed by qualified personnel, according to the manufacturer’s instructions and to the relevant British Standards.
  • Page 3: Table Of Contents

    Electrical connections ... 26 Commissioning ... 27 Conversion from Natural Gas to LPG .. 28 Oven Door Protection Device (Model ZCM 610 X) All our appliances comply with the European safety standards. Nevertheless, in order to ensure the highest safety...
  • Page 4: Description Of The Cooker

    Shelf Oven door Fitting the Splash back (only in model ZCM 610 X) A stainless steel splash back is supplied with the appliance. This is meant to be fitted on the rear edge of the cooker's hob. The splash back package is in the oven cavity.
  • Page 5: Control Panel

    Control Panel BACK LEFT FRONT LEFT MAINS ON THERMOSTAT IGNITION 1. Cooker Operation Pilot Light 2. Oven Thermostat Pilot Light 3. Electric ignition push button 4. Back left burner control knob (semi-rapid) 5. Front left burner control knob (rapid) 6. Front right burner control knob (auxiliary) 7.
  • Page 6: Operation

    Take care when frying food in hot oil or fat, as the overheated splashes could easily ignite. maximum If the control knobs become difficult to turn, diameter please contact your local Zanussi Service Force Centre. 260 mm. 220 mm. 160 mm.
  • Page 7: Electric Oven

    Electric Oven Oven Function Control Knob Oven Light - The oven light will be on without any cooking function Defrost Setting - This setting is intended to assist in thawing of frozen food (see page 15). Fan cooking - This allows you to roast or roast and bake simoultaneously using any shelf, without flavour transference.
  • Page 8: 24 Hour Clock And Timer

    24 Hour Clock and Timer 1. ( - ) DECREASE CONTROL & TIMER SETTING BUTTON 2. ( + ) INCREASE CONTROL ) COOKPOT SYMBOL ) PUSH BOTH CLOCK SETTING SYMBOL 1. SET THE TIME OF DAY When the electricity supply is first switched ON, the display will flash 0.00.
  • Page 9 2. THE TIMER IMPORTANT The timer can be used to time a set cooking period. At the end of the cook time the timer will automatically switch off the oven if in use. The timer gives an audible reminder at the end of any period of cooking up to 23 hours and 59 minutes.
  • Page 10: Before The First Use Of The Cooker

    Before the First Use of the Cooker Remove all packaging, both inside and outside the cooker, before using it. Before first use, the oven should be heated without food. During this time, an unpleasant odour may be emitted. This is quite normal. 1.
  • Page 11: Condensation And Steam

    Hints and Tips Condensation and steam When food is heated it produces steam in the same way as a boiling kettle. The oven vents allow some of this steam to escape. However, always stand back from the oven when opening the oven door to allow any build up of steam or heat to release.
  • Page 12: Using The Fan Oven

    Using the Fan Oven The air inside the oven is heated by the element around the fan situated behind the back panel. The fan circulates hot air to maintain an even temperature inside the oven. The advantages of cooking with this function are: Faster Preheating As the fan oven quickly reaches temperature, it is not usually necessary to preheat the oven...
  • Page 13: Cooking Chart

    Cooking Chart This chart is intended as a guide only. It may be necessary to increase or decrease the temperature to suit your individual requirements. Only experience will enable you to determine the correct setting for your personal requirements. Food Biscuits, cookies Bread, yeast doughs Cakes, Victoria sandwich...
  • Page 14 Hints and Tips Runner positions are not critical, but make sure the shelves are evenly spread. When cooking more than one dish in the fan oven, place dishes centrally on the shelves rather than several dishes on one shelf. When the oven is full, you may need to allow slightly longer cooking time.
  • Page 15: Defrosting

    Defrosting The oven fan operates without heat and circulates the air, at room temperature, inside the oven. This increases the speed of defrosting. However, please note that the temperature of the kitchen will influence the speed of defrosting. This function is particularly suitable for delicate food which could be damaged by heat, e.g.
  • Page 16: Grilling

    Grilling Grilling must be carried out with the oven door closed. The grill pan handles must be removed from the pan. How to Use the Grill 1. Turn the oven control function knob to 2. Turn the thermostat control knob on the required temperature.
  • Page 17: Maintenance And Cleaning

    If the rubber feet become detached from the pan support re-fit as per diagram. Anti-scratch rubber feet can be obtained from your local Zanussi Service Force Centre. The Burners The burner caps and crowns can be removed for cleaning.
  • Page 18: Cleaning The Oven

    Cleaning the Oven Before cleaning always allow the cooling fan to cool the oven down before switching off at the electricity supply. The oven should be kept clean at all times. A build-up of fats or other foodstuffs could result in a fire, especially in the grill pan. Cleaning materials Before using any cleaning materials on your oven, check that they are suitable and that their use is...
  • Page 19 Oven Cavity The enamelled oven cavity is best cleaned whilst the oven is still warm. Wipe the oven over with a soft cloth soaked in warm soapy water after each use. From time to time it will be necessary to do a more thorough cleaning, using a proprietary oven cleaner.
  • Page 20: Something Not Working

    If the aplliance is not working correctly, please carry out the following checks, before contacting your local Zanussi Service Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee.
  • Page 21: Service And Spare Parts

    Customer Care Booklet. Peace of Mind for 12 Months ZANUSSI GUARANTEE CONDITIONS We, Zanussi, undertake that if, within 12 months of the date of the purchase, this Zanussi appliance or any part thereof is proved to be defective by any...
  • Page 22: Instructions For The Installer

    Instructions for the Installer Technical Data Model Number: ZCM 600W/ZCM610 X Appliance Class 2 sub class 1 and Class 1 APPLIANCE CATEGORY: II 2H3+ APPLIANCE GAS SUPPLY: Natural Gas 20 mbar Dimensions Height Depth Width Oven Capacity Rear left burner (semi-rapid) Front left burner (rapid) Rear right burner (semi-rapid) Front right burner (auxiliary)
  • Page 23: Important Safety Requirements

    Important Safety Requirements This appliance must be installed in accordance with the Gas Safety (Installation and Use) Regulations (current addition) and the I.E.E. Wiring Regulations. Detailed recommendations are contained in the following British Standard Codes of Practice - B.S. 6172, B.S. 5440: Part 2 and B.S. 6891: Current Editions.
  • Page 24: Installation

    Installation FO 1141 The appliance must be installed in accordance to the type X (standard EN 60335-2-6). Therefore the appliance can not be installed beside furniture higher than the cooker worktop. Positioning the Appliance (Fig. 1) Note A: The appliance is designed to be flush fitted with 2mm clearance at each side to allow for it to be pulled forward for cleaning etc.
  • Page 25: Fitting The Stability Bracket

    WALL FACE PENCIL LINE ON THE FLOOR PLAN VIEW OF THE COOKER FO 0179 Fig. 2 Fitting the Stability Bracket (Not supplied) If the cooker has to be installed with a flexible supply pipe, it is necessary that a stability device is fitted.
  • Page 26: Electrical Connections

    Electrical connections Any electrical work required to install this cooker should be carried out by a qualified electrician or competent person, in accordance with the current regulations. THIS COOKER MUST BE EARTHED. The manufacturer declines any liability should these safety measures not be observed.
  • Page 27: Commissioning

    Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. - Turn the gas tap to the MAX position and ignite. - Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times.
  • Page 28: Conversion From Natural Gas To Lpg

    Conversion from Natural Gas to LPG It is important to note that this model is designed for use with natural gas but can be converted for use with butane or propane gas providing the correct injectors are fitted and the gas rate is adjusted to suit. Method •...
