Page 1
Indoor Unit Operation & Installation Manual AWSI-CBV005-N11 AWSI-CBV007-N11 AWSI-CBV009-N11 AWSI-CBV012-N11 AWSI-CBV016-N11 AWSI-CCV018-N11 AWSI-CCV024-N11 AWSI-CCV030-N11 AWSI-CCV038-N11 AWSI-CCV042-N11 AWSI-CCV048-N11 No. 0150510086 Please read this manual carefully before using Keep this operation manual for future reference...
Page 2
Product Features: AWSI-CBV005-N11 Hanging-style installation to save space; CBV005 Automatic display of faults; AWSI-CBV007-N11 CBV007 Function of central control (optional from our company).
Page 3
Parts and Functions Indoor Units CBV005-016,CCV018-048 electrical cabinet wind deflector (regulate wind direction with remote controller) inlet grid air cleaner (in inlet grid)
Page 4
Safety If the air conditioner is transferred to a new user, this manual shall be transferred to the user, together with the conditioner. Before installation, be sure to read Safety Considerations in this manual for proper installation. The safety considerations stated below is divided into “ Warning”...
Page 5
Safety Attention It is not allowed to put any heating 3-minute protection apparatus under the indoor units, for the To protect the unit, compressor can be heat may cause distortion of the units. actuated with at least 3-minute delay after stopping.
Page 6
Maintenance Attention Repair can only be performed by professional personnel. Before touching the connection line, all power supplies should be switched off. Only after switching off the power supply can the operator clean the air conditioner as to avoid electric shock or injury.
Page 7
Maintenance Cleaning Air Cleaner Cleaning Clean the air cleaner with the dust collector or water to remove dusts. For too much dust, use the fan or directly spray the special cookware detergent on the air inlet grid, and then clean it with water after 10 minutes. (A) remove dust with dust collector;...
Page 8
Maintenance Cleaning the air outlet port and the shell: Attention Don’t use gasoline, benzene, diluents, polishing powder or liquid insecticide to clean them. Do not clean them with hot water of above 50℃ to avoid fading or distorting. Wipe them with soft dry cloth. Water or neutral dry cleanser is recommended if the dust cannot be removed.
Page 9
Fault Checkup Please check the following when consigning repair service: Reasons Symptoms Water flow sound can be heard when starting operation, during operation or immediately after stopping operation. When it starts to work for 2-3 minutes, the sound may become louder, which is Water flow sound the flowing sound of refrigerant or the draining sound of condensed water.
Page 10
Installation Procedures The standard attached accessories of the units of this series refer to the packing list; prepare other accessories according to the requirements of the local installation point of our company. Indoor units should be installed in places with the environment of even circulation of cool and warm blows.
Page 11
Installation Procedures 2. Location Relationship among Ceiling Hole, Unit and Hoisting Studs CBV005-016 The ceiling and decorated board overlapping part should be more than 25mm holder ceiling decorated board gap between studs 535mm indoor unit 570mm ceiling 650mm decorated board 700mm CCV018-048 The ceiling and decorated board overlapping part should be more than 25mm...
Page 12
Installation Procedures 3. Ceiling Hole & Reinforcement (1) Cut and withdraw the foundation of ceiling according to the size of indoor unit. (2) After cutting an appropriate hole, reinforce the cutting area on the foundation of indoor unit, and append the rim to the ceiling to secure its foundation. In order to prevent the ceiling from vibrating, it is vital to reinforce the ceiling foundation and ensure the original levelness of the ceiling.
Page 13
Installation Procedures Installing the decorated board on the body of indoor unit: receiving window for remote control the lamp will not flash when wired controller is used Limits when mounting the board: mount the board as shown in the figure. Incorrect direction may cause air leakage, and meanwhile the swinging and receiving displays can’t be connected.
Page 14
Installation Procedures Piping Materials & Heat Insulating Materials As to prevent condensation, heat insulating Piping Hard PVC tube VP31. Material 5mm(inner bore) treatment should be performed. The heat insulating treatment for piping should be done respectively. Vesicant polythene Heat Insulating thickness: over 7mm Material Hose...
Page 15
Installation Procedures Tubing Permissible Length & Height Difference Please refer to the attached manual of outdoor units. Tubing Materials & Specifications CBV005-009 CBV012/016,CCV018 CCV024-048 Model Gas pipe 9.52 12.7 15.88 Tubing Size (mm) Liquid pipe 6.35 6.35 9.52 Tubing Material Phosphor deoxybronze seamless pipe (TP 2 ) for air conditioner Refrigerant Filling Amount Add the refrigerant according to the installation instruction of outdoor unit.
Page 16
Electrical Wiring Warning Electrical construction should be made with specific mains circuit by the qualified personnel according to the installation instruction. Electric shock and fire may be caused if the capacity of power supply is not sufficient. During arranging the wiring layout, specified cables should be used as the mains line, which accords with the local regulations on wiring.
Page 17
Electrical Wiring Signal Wiring Drawing outdoor 1 outdoor 3 outdoor 2 P Q A B C A B C A B C control wire for wired controller with polarity communication wire with polarity indoor 5 indoor 4 indoor 3 indoor 1 indoor 2 P Q A B C P Q A B C...
Page 18
Electrical Wiring The combination of multiple indoor units can be controlled by wired controller or remote controller. ※ Switching Mode of Line-Controlled Main Unit/ Line-Controlled Sub Units/ Remote-Controlled Types can be used for switching over ※ Setting Master Remote Wired 1# Remote Wired Wireless Remote Mode...
Page 19
Electrical Wiring Dip switch setting Indoor PCB In the following table, 1 is ON, 0 is OFF. SW01 is used for indoor unit group control address setting and capacity selection. CN44,CN42,CN43 are used for indoor unit type selection. CN41 is used for addressing by wired controller. SW03 is used for indoor unit address setting (including physical address and central address).
Page 20
Electrical Wiring (3) Description of SW03 Set the address with wired controller or Manner of automatism (default) SW03_1 address Set the address with dip switch Commu Central [6] [7] [8] nication control address address *Note Set the 1. The address must be set by Commun (default) (default)
Page 21
Electrical Wiring (5) Description of jump wire:SW08(1:ON, 2:OFF) (6) Jumper explanation a) EEV operation manually Normal mode(default) (CN27, CN29) Fix air volume Air volume is fixed at high speed (for duct CN27: short circuit CN27 2 type) seconds continuously, EEV Run at Mid speed Normal mode(default) is openned fully.
Page 22
Test Run & Fault Code Before Test Run Before switching it on, test the supply terminal tier (L, N terminals) and grounding points with 500V megaohm meter and check if the resistance is above 1MΩ. It can’t be operated if it is below 1MΩ. Connect it to the power supply of outdoor units to energize the heating belt of the compressor.
Page 23
Disposal DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. It is prohibited to dispose of this appliance in domestic household waste. For disposal there are several possibilities: a) The municipality has established collection systems, where electronic waste can be disposed of ate least free of charge to the user.
