I N S TA L L AT I O N M A N U A L
1. Rectangular Des k
M FX L E G S
C -l e g
T- le g
M F X
RECTANGULAR & CORNER SIT TO STAND (S2S)
2 . Co rne r D e s k
B E A M S
T-leg ( sma ll )
Al umi niu m Bea m
- ALUMINIUM BEAM
C O N T R O L B O X
ASSEMBLY OVERVIEW
Handset
V E R S IO N S
S2 S - mo tor ized
Drive 1
Drive 2
Drive 3
(If necessary)
Drive 1
Drive 2
Attention:
Before starting the system, please
make sure, that the operating voltage
of the system conforms with the local
power supply. The mains plug of the
control has to be connected to a free
accessible power supply.
w w w . m a r k a n t o f f i c e . c o m
Main Cable
