Liberty Pumps 2460 Series Installation Manual

Installation Manual
Simplex Grinder Systems
2460/2472/2484/2496-Series
• 24" Diameter Fiberglass Basin
• Available in 60", 72", 84", and 96" Heights
3060/3072/3084/3096-Series
• 30" Diameter Fiberglass Basin
• Available in 60", 72", 84", and 96" Heights
Features
• LSG Grinder Pump (2 hp, 208/230V)
-or-
• LSGX Grinder Pump (2 hp, 208–230V)
• GR20 Guide Rail System
• Simplex Control Panel with Alarm
-or-
• Automatic Pump with Alarm
IMPORTANT: All Liberty Pumps products are supplied with their own
separate Installation/Operation/Maintenance manuals. Ensure receipt of
these manuals, and that they are read and understood prior to installation.
For questions, call Liberty Pumps customer service at 800-543-2550.
7000 Apple Tree Avenue
Bergen, NY 14416
ph: 800-543-2550
fax: 585-494-1839
www.LibertyPumps.com
Keep this manual handy for future reference.
For replacement manual, visit LibertyPumps.com,
or contact Liberty Pumps at 800-543-2550.
Retain dated sales receipt for warranty.
Copyright © Liberty Pumps, Inc. 2020 All rights reserved.
3084-Series Shown
Installer: Manual must remain with owner or
system operator/maintainer.
Prior to installation, record information
from pump nameplate for future reference:
System:
Model(s):
Serial(s):
Control Panel:
Mfg Date:
Install Date:
5651000L
