COMFORT FOOT DOUBLE
WARNING:
Make sure all screws are tightly secured upon completion.
Bolt On
Parts Included:
2 - ¼-20 x 1" or ¼-20 x 1 ¼ " Screws (dimensions vary depending on style of part)
2 - ¼ " x 1 ¼ " OD Fender Washer
Base
Comfort Foot Double with Leg Separator shown
1
Place the provided left or right footplate template
on the wheelchair footplate in the desired position.
2
Drill two 5/16" diameter holes through the footplate
as marked on the template.
3
Adjust Comfort Foot Double to desired angle using
base straps (A).
4
Screw two ¼-20 x 1" or ¼-20 x 1 ¼ " bolts* with the
provided washers into position (B) for left side or (C)
for right side from the bottom of the footplate into
the Comfort Foot Double base. *Note: use 1" bolts
for Comfort Foot Double with Gel.
B
C
5
Wrap footplate straps (D) around wheelchair
footplates and secure using side-release buck-
les.
6
Wrap rear strap (E) around leg rest tubing and
secure with side release buckle. Tall style uses
two rear straps to secure.
Bolt on installation with securing buckle allows the Comfort
Foot to swing away for patient transfers. Note: product can
be installed with securing buckles only.
Toll Free 800.564.9248
www.comfortcompany.com
509 South 22nd Ave Bozeman, MT 59718
A
D
IS-CFDOUBLEBOLTON
E
REV0814
