Comfort Company Body Point Shoulder Harness Manual

BODY POINTS SHOULDER HARNESS
AVAILABLE: Chest Harness Extension Brackets. Call customer service for details: 1.800.564.9248
PARTS INCLUDED:
1 - Body Point Shoulder Harness - Part # SHS-RP-P (Small) or SHXS-RP-P (x-small)
2 - Washer: #10 SAE - Part # 10011
2 - 10-32 x 5/8" Button Head Cap Screw - Part # 10003
2 - Nut: 10-32 UNF Nylon Fasten - Part # 10012
1 - Wrench: 1/8" Allen - Part # 10017
Tools Not Included: 3/8" Wrench
1
Lay chest harness (Item 1) on backrest shell with
the top straps hanging over the back and the
bottom straps underneath the shell.
2
Remove the bottom flap of the back rest cover
from the shell as shown in Figure 2.
3
Attach chest harness (Item 1) to the shell using
the 10-32 screws (Item 3) and washers (Item 2)
inserted into the holes at the bottom of the shell
as orientated in Figures 1, 2.
Assembly order: screw – washer – clinch-mount
fitting – plastic tab – shell – nut.
4
Fasten the screw with the 10-32 nut (Item 4)
behind the shell, must use both the 1/8" allen
wrench (Item 5) for the screw and 3/8" wrench
for the nut.
5
Rotate both of the clinch-mounts sideways to
reattach the shell cover, and then rotate both
mounts back.
Page 1 of 2
509 South 22nd Ave Bozeman, MT 59718
6
Once both screws are fastened, pull straps
down as shown in Figure 3 to tighten the
harness. Then close the clinch-mounts to fasten
the straps in place.
7
To adjust the clinch-mounts, use the allen
wrench to pry it open.
8
Insert the top straps into the shell guide slots as
shown in Figure 4.
9
To tighten the top straps, pull the plastic
D-loops at the end of the pull straps as shown in
Figure 5.
