- Page 1 COMPASS HARDWARE ADAPTATION FOR PILOT CHAIRS Attaching Compass 4 Hardware (Quick Release) ® to TiLite Pilot Pediatric Wheelchairs www.comfortcompany.com www.comfortcompany.com IS-COMPASS4PILOT Questions? Contact Customer Support at: 800.564.9428 REV0618...
- Page 2 COMPASS HARDWARE PILOT ADAPTATION FIGURE 2 PARTS INCLUDED PARTS REQUIRED FROM COMPASS HARDWARE KIT 2 - Double Nuts (F) 2 - Slide Lock Brackets (H) 1 - 5mm Hex Key 4 - M6x1 - 30 Angle Adjustment Screws (L) 4 - M6 Safety Lock Washers (M) 4 - M6 Flat Washers (N) 4 - M6x1 - 14mm Screws (O) 2 - Socket Mount Plates (P)
