Yard force LS G30A Original Instructions Manual

40v cordless chain saw
Hide thumbs

Advertisement

Table of Contents

40V CORDLESS CHAIN SAW
Original Instructions
READ & UNDERSTAND
INSTRUCTION MANUAL
Save all warnings and instructions for future reference.
Hotline: 1300 418 640
Monday/Friday: 9.00am to 4.30pm
Saturday: 9.00am to 3.00pm
Email: service@actionspares.com.au
LS G30A & LS G30W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS G30A and is the answer not in the manual?

Questions and answers

Related Manuals for Yard force LS G30A

Summary of Contents for Yard force LS G30A

  • Page 1 LS G30A & LS G30W 40V CORDLESS CHAIN SAW Original Instructions READ & UNDERSTAND INSTRUCTION MANUAL Save all warnings and instructions for future reference. Hotline: 1300 418 640 Monday/Friday: 9.00am to 4.30pm Saturday: 9.00am to 3.00pm Email: service@actionspares.com.au...

  • Page 3: Table Of Contents

    LS G30A & LS G30W Original Instruction CONTENT Description of Product Parts Technical Specifications Intended Use Safety Information Assembly Adjustment Knowledge of kickback Operation Storing and Maintenance Troubleshooting Warranty Conditions...

  • Page 4: Description Of Product Parts

    DESCRIPTION OF PRODUCT PARTS Fig 1 Fig 2 Fig 3 Fig 4...
  • Page 5 DESCRIPTION OF PRODUCT PARTS Parts List As shown in Fig 1-4 14. Locking pin Rear handle 15. Sprocket Lock-off button 16. Battery pack (sold with AL GC2A only) On/off trigger switch 17. Battery pack release button Oil tank cap 18. Power indicator button Oil tank watching window 19.

  • Page 6: Technical Specifications

    TECHNICAL SPECIFICATIONS LS G30A&LS G30W Model Nominal voltage of product with battery 40 V d.c. No load chain speed 11.3 m/s Bar Length 300mm (12”) Oregen 124MLEA041 Chain Oregen 90PX045X (chain pitch 0.375”) Guaranteed sound power level 98 dB(A) Net weight 5.5 kg...

  • Page 7: Safety Information

    SAFETY INFORMATION IMPORTANT Please read these instructions fully before assembling and operating. Description of symbols Symbols are used in this manual to attract your attention to possible risks. The safety sym- bols and the explications which accompany them must be perfectly understood. The warning themselves do not prevent the risks and cannot be a substitute for proper methods of avoiding accidents.
  • Page 8 SAFETY INFORMATION Bar length 300 mm, Maximum cutting length 240mm Australian Regulatory Compliance Mark. Waste electrical products should not be disposed of with house- hold waste. Please recycle where facilities exist. Check your Local Authority or retailer for recycling advice. Warning Symbols on the charger Warning! Before any use, refer to the corresponding paragraph in the pres-...
  • Page 9 SAFETY INFORMATION GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instruc- tions. Failure to follow the warnings and instructions may result in electric shock,fire and/or serious injury. Save all warnings and instructions for future refer- ence. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery- operated (cordless) power tool.
  • Page 10 SAFETY INFORMATION risk of electric shock. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords in- crease the risk of electric shock. When operating a power tool outdoors, use an extension cord suitable for outdoor use.
  • Page 11 SAFETY INFORMATION source and/or battery pack, picking up or carry- ing the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. Remove any adjusting key or wrench before turn- ing the power tool on.
  • Page 12 SAFETY INFORMATION or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. Store idle power tools out of the reach of chil- dren and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.
  • Page 13 SAFETY INFORMATION When battery pack is not in use, keep it away from other metal objects, like paperclips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
  • Page 14 SAFETY INFORMATION Do not subject battery pack to mechanical shock. In the event of battery leaking, do not allow the liquid to come into contact with the skin or eyes. If contact has been made, wash the affected area with copious amounts of water and seek medical advice.
  • Page 15 SAFETY INFORMATION 16. Keep battery pack out of the reach of children. 17. Retain the original product literature for future refer- ence. 18. Remove the battery from the equipment when not in use. 19. Dispose of properly. GENERAL SAFETY WARNINGS FOR YOUR BAT- TERY CHARGER WARNING! Read all safety warnings and all instruc- tions.
  • Page 16 SAFETY INFORMATION Before charging, ensure your charger is matching the local AC supply. For indoor use, or do not expose to rain. The charging device must be protected from mois- ture. Do not use the charging device in the open. Do not short out the contacts of battery or charger.
  • Page 17 SAFETY INFORMATION 18. Charge only battery pack of the same model provid- ed by manufacturer and of models recommended by manufacturer. CORDLESS CHAIN SAW SAFETY WARNINGS Keep all parts of the body away from the saw chain when the chain saw is operating. Before you start the chain saw, make sure the saw chain is not contacting anything.
  • Page 18 SAFETY INFORMATION When cutting a limb that is under tension be alert for spring back. When the tension in the wood fi- bers is released the spring loaded limb may strike the operator and/or throw the chain saw out of control. Use extreme caution when cutting brush and saplings.
  • Page 19 SAFETY INFORMATION kicking the guide bar up and back towards the opera- tor. Pinching the saw chain along the top of the guide bar may push the guide bar rapidly back towards the operator. Either of these reactions may cause you to lose control of the saw which could result in seri- ous personal injury.
  • Page 20 SAFETY INFORMATION 13. Cut the wood in right direction. 14. Before use the chain saw, be sure to check the chain and bar in tension. Don’t use the chain saw if the chain and bar are loose. Also confirm with that no ab- normality exists by actual test running.

  • Page 21: Assembly

    ASSEMBLY Assembling the Bar and chain blade WARNING : Before assembling the chain saw Following items should be considered. - Before assembling this product .ensure the battery pack has been removed. - Ensure the hand guard in position “brake off” As shown in Fig 6 •...
  • Page 22 ASSEMBLY Position the saw rail so that the chain tension pin and locking pin can engage into the saw rail and the chain saw blade lies around the sprocket. Make sure the chain cutters on top of the guide bar face forward towards the bar tip. ( Fig 8) First insert tongue locates on the bottom left of the clutch cover into its matching hole at a certain angle.

  • Page 23: Adjustment

    ADJUSTMENT Checking the tension of the saw chain As shown in Fig10 Fig 10 CAUTION ! Always ensure the battery pack has been removed. When the saw chain can be raised by around 2mm In the middle of the cutter bar. You know that the chain tension is ideal.
  • Page 24 ADJUSTMENT Checking the chain lubrication As shown in Fig11 The product may not be used without adequate chain lubrication. Inadequate lubrication reduc- es the service life of the product.. Check the oil quantity in the tank. Switch on the device. (see the later section “switch on/off” ) Hold the running chain saw approx.

  • Page 25: Knowledge Of Kickback

    KNOWLEDGE OF KICKBACK Definition of kickback Pinch kickback : the rapid push back of the saw chain that can occur when the wood closes in and pinches the moving saw chain in the cut along the top of the guide bar. Rotational kickback : the rapid upward and backward motion of the saw that can occur when the moving saw chain near the upper portion of the tip of the guide bar contacts an object such as a long or branch.
  • Page 26 KNOWLEDGE OF KICKBACK With a basic understanding of kickback , you can reduce or eliminate the element of sud- den surprise contributes to accidents; Keep a good firm grip on the saw with both hands, the right hand on the rear handle and the left hand on the front handle, when the tools is running.
  • Page 27 KNOWLEDGE OF KICKBACK Push stroke As shown in Fig14 Fig 14 This technique involves sawing from bottom to top with the top side of the saw rail. The saw chain pushes the product backwards and to- wards the user. If the saw rail twists, the product can be flung towards the user at high force.

  • Page 28: Operation

    OPERATION Charging the battery pack As shown in Fig15 NOTE! Remove the battery pack from the charger after it has been fully charged . NOTE! This battery pack has been shipped in a low charge condition,it should be fully charged before first use. NOTE! make sure the main voltage is the same as rating label which located on the charger.
  • Page 29 OPERATION The green LED light of the charger will flash continuously during normal charging. After charging is complete, you will hear a beep sound again, the green LED on the char- ger will be on and the four green lights of the battery pack will be on for 3-5 seconds then turn off.
  • Page 30 OPERATION Always unplug the charger when not in use and store in a dry secure place. Avoid charging or storing your battery in temperatures below 0°C and above 45°C . Cool down hot battery pack from a just-operated tool for approximately 30 minutes before at- tempting to recharge.
  • Page 31 OPERATION Fig 17 9.5CM Switching On/Off As shown in Fig 18 NOTE :the cordless chain saw will not operate unless the hand guard in position “brake off” Hold the product firmly in both hands. To switch on the product . Press the safety lock-off button then press the trigger switch and hold it in this position .
  • Page 32 OPERATION Before use Check that the chain brake works correctly and is not damaged. Check that the rear right hand guard is not damaged. Check that the lock-off button and on/off trigger switch works correctly and is not dam- aged. Check that all handles are free from oil.
  • Page 33 OPERATION Before felling is started, consider the natural lean of the tree, the location of larger branches and the wind direction to judge which way the tree will fall. Remove dirt, stones, loose bark, nails, staples and wire from the tree. Fig 19 Fig 20 Felling direction...
  • Page 34 OPERATION Limbing a tree Limbing is removing the branches from a fallen tree. When limbing leave larger lower limbs to support the log off the ground. Remove the small limbs in one cut As shown in Figure 21 Branches under tension should be cut from the bottom up to avoid binding the chain saw. Fig 21 Limb cut Keep work off ground leave support limbs until log is cut...
  • Page 35 OPERATION When the log is supported on one end, As shown in Figure 23 cut 1/3 the diameter from the underside (underbuck). Then make the finished cut by overbuck- ing to meet the first cut. Fig 23 2nd cut overbuck (2/3 diameter) to meet 1st cut (to avoid pinching) 1st cut underbuck (1/3 diameter) to avoid splintering...
  • Page 36 OPERATION When bucking on a slope always stand on the uphill side of the log, As shown in Figure 25 When “cutting through”, to maintain complete control release the cutting pressure near the end of the cut without relaxing your grip on the chain saw handles. Don’t let the chain contact the ground.

  • Page 37: Storing And Maintenance

    STORING AND MAINTENANCE WARNING! Before performing any repair work, always remove the battery pack and wait until the cutting blade has come to a standstill ! Do not spray the unit with water. Ingress of water may destroy the battery pack and the electric motor.

  • Page 38: Troubleshooting

    TROUBLESHOOTING WARNING! Before performing any repair work, always ensure the battery pack has been removed . CAUTION! Improper repairs can result in the product functioning unsafely. This endan- gers yourself and your environment. Faults which cannot be rectified with the aid of following table may be rectified by a specialist company only (customer service center).

  • Page 39: Warranty Conditions

    WARRANTY The mower is covered by a 2 year parts and labour warranty against manufacturing defects. The battery pack and charger are covered by a 1 year parts and labour warranty against manufacturing defects. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
