POWER – Power, from the internal 9-volt battery or external battery eliminator, is
activated by plugging into the Input jack. The input cable should be removed when-
the unit is not in use to avoid running down the battery. The barrel connector on the
front of the Micro Q-Tron is for a 9-volt battery eliminator capable of delivering 100
mA of current. The inner ring of the 9-volt battery eliminator must be negative, the
outer ring positive. The unit's battery may be left in or taken out when the eliminator
is in use.
BATTERY – The Micro Q-Tron can run off of a 9V battery. To change the 9-volt
battery, you must remove the 4 screws on the bottom of the Micro Q-Tron. Once the
screws are removed, you can take off the bottom plate and change the battery.
Please do not touch the circuit board while the bottom plate is off or you risk
damaging a component.
-PLAYING THE MICRO Q-TRON-
The Micro Q-Tron's effect is controlled by the musician's playing dynamics: a stronger
attack or louder note will yield a more dramatic effect, while softer playing will
produce more subtle effects. Use the full range of control settings in combination
with different playing techniques to obtain a number of different and unique effects
combinations. You might find that the DRIVE and Q controls work best when they are
in the middle of their range rather than maximized.
When you play a note into the Micro Q-Tron, its filter will jump up to a high
frequency and then slowly descend in frequency according to the envelope of the
notes you play. The louder your note, the higher in frequency the filter jumps.
-POWER-
- WARRANTY INFORMATION -
Please register online at http://www.ehx.com/product-registration or complete and
return the enclosed warranty card within 10 days of purchase. Electro-Harmonix will
repair or replace, at its discretion, a product that fails to operate due to defects in
materials or workmanship for a period of one year from date of purchase. This
applies only to original purchasers who have bought their product from an authorized
Electro-Harmonix retailer. Repaired or replaced units will then be warranted for the
unexpired portion of the original warranty term.
If you should need to return your unit for service within the warranty period, please
contact the appropriate office listed below. Customers outside the regions listed
below, please contact EHX Customer Service for information on warranty repairs at
info@ehx.com or +1-718-937-8300. USA and Canadian customers: please obtain a
Return Authorization Number (RA#) from EHX Customer Service before returning
your product. Include with your returned unit: a written description of the problem
as well as your name, address, telephone number, e-mail address, and RA#; and a
copy of your receipt clearly showing the purchase date.
United States & Canada
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX
c/o NEW SENSOR CORP.
55-01 2ND STREET
LONG ISLAND CITY, NY 11101
Tel: 718-937-8300
Email: info@ehx.com
Europe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ
UNITED KINGDOM
Tel: +44 179 247 3258
Email: electroharmonixuk@virginmedia.com
This warranty gives a purchaser specific legal rights. A purchaser may have even
greater rights depending upon the laws of the jurisdiction within which the product
was purchased.
