- Page 1 MMA WELDING MACHINE KOLARC S 400 OPERATION MANUAL * The manufacturer reserves the right to change specifications without notice. * NOTE: Specifications may vary by country...
-
Page 2: Table Of Contents
CONTENTS WARRANTY CERTIFICATE CE DECLARATION OF CONFORMITY SAFETY WARNINGS INSTALLATION AND OPERATOR INSTRUCTIONS WORK CYCLE AND OVERHEATING TECHNICAL DATA LABEL APPLICATION MAINTENANCE AND TROUBLESHOOTING ERROR RESOLUTION TABLE WIRING DIAGRAM PART LIST... -
Page 3: Warranty Certificate
MANUFACTURER & IMPORTERS COMPANY Ünvanı :Center Dış Ticaret Makina San. ve Paz. A.Ş. Name : Kolarc Makine İmalat Sanayi ve Ticaret A.Ş Adres :Hamidiye Mah. Atatürk Cad. No :292/A Sultanbeyli/ İSTANBUL Address : Kargalıhanbaba OSB Mh. Organize Sanayi 3. Sk. No:8 Hendek / SAKARYA... - Page 4 1-) The warranty period starts from the delivery date of the goods and is 2 years. 2-) The goods including all parts are covered by KOLARC warranty. 3-) In case of malfunction of the goods within the warranty period, the time spent in repair is added to the warranty period.
-
Page 5: Ce Declaration Of Conformity
AVRUPA TOPLULUĞU - UYGUNLUK BEYANI EUROPEAN COMMUNITY - DECLARATION OF CONFORMITY Üretici : KOLARC MAKİNE İMALAT SAN. VE TİC. A.Ş Manufacturer : Kargalıhanbaba OSB Mh. Organize Sanayi 3. Sk. No:8 Hendek / SAKARYA / TURKEY Tel : 0 (264) 502 24 20 Fax : 0 (264) 502 24 21 Beyan : Aşağıda belirtilen ürünler AT Direktiflerine ve Standartlarına uyumludur. -
Page 6: Safety Warnings
Please read the warnings against the symbols listed below. Kolarc Makine İmalat San. ve Tic. Inc. is not responsible, due to improper connections, storage conditions and damage caused by use, WARNING: This symbol indicates that the instructions in this manual must be observed to avoid possible serious injury, loss of life, or damage to the machine. - Page 7 Noise: Ear muffs should be worn to protect the ear from sparks and molten metals and to prevent hearing loss from the arc welding machine noise. When the noise in the working environment reaches a level that is disturbing and causing headaches, an auditory problem may occur. In this case, your ear muffs should be worn immediately.
- Page 8 SMOKE AND GASES MAY BE DANGEROUS: Welding may cause fumes and gases to be released. Adequate ventilation must be provided or fumes and gases must be vented out of the breathing zone to protect users from this hazard. In general, welding applications;...
-
Page 9: Installation And Operator Instructions
be ignited by contact; liquids (gasoline, oil, paint, thinner and the like), solids (wood, cardboard, paper and the like) and gases (acetylene, hydrogen and the like). Observe the welded medium. If there are systems operating with petrol or hydraulic oil in the vicinity and you are unable to move the welding medium or the system, put a fire-resistant screen in between. -
Page 10: Work Cycle And Overheating
The welding machine can only be connected to the mains with a 16-amp delayed fuse with the plug on it. 1- KOLARC 400 AC; It must be connected to a three-phase, 380 V (AC) and 50-60 Hz network with 3 Phase and Ground lines. -
Page 11: Technical Data Label
2- It must be connected by a qualified electrician to the network with a healthy protective earth connection approved by the competent authorities. 3- Improper connection will cause damage to the machine and damage caused by such connections is not covered by the warranty. Improper connection will damage the machine and damage caused by such connections is not covered by the warranty. -
Page 12: Application
APPLICATION : Front Rear Wiev Wiev 1. Carrying handle 6. On-Off Switch 2. Front panel housing 7. Communication socket 3. Negative (-) Welding Cable connection 8. Mains Cable 4. Positive (+) Welding Cable connection 9. Glass fuse 5. Air ventilation 10. - Page 13 Front Panel Label : 1. Hot Start Indicator 5. Ampere Indicator 2. Arc Force Indicator 6. Digital Display 3. Lift TIG Indicator 7. Ampere Indicator 4. Function Button 8. Potency Button...
-
Page 14: Maintenance And Troubleshooting
Covered Electrode Welding: Before starting welding, the following operations should be performed: 1- First determine the appropriate pole for the electrode used. You can find this information in the electrode data sheet. Then connect the welding cables to the outlets to match the selected pole. For example, if DC (+) is used, connect the electrode cable to the (+) outlet (4) of the machine and the grounding pliers to the ( -) outlet (3). -
Page 15: Error Resolution Table
Six Month Maintenance Clean the machine with air that is not too high pressure. Do not open the machine covers during cleaning. Contact the authorized service for annual maintenance. During the annual maintenance, continuity of the grounding and insulation control of the machine is required. Ask your annual maintenance report to include this data. -
Page 16: Wiring Diagram
WIRING DIAGRAM : PART LIST : 1. Power Card 2. Filter Card 3. Front Panel Card 4. Control Card 5. Power Transformer 6. Shock Coil 7. IGBT 8. Plastic holder 9. Fan... - Page 17 Kolarc Makine İmalat Sanayi ve Ticaret A.Ş. Factory :Kargalıhanbaba OSB Mah. 3. Sokak No:8 54300 Hendek/SAKARYA :+90 264 502 24 20 :+90 264 502 24 21 :100. Yıl Mah. Horasan Sok. No:16/4 06700 Çankaya/ANKARA www.kolarc.com info@kolarc.com...
