ekwb EK-FC670 GTX Series Installation And Mounting Manual

This product is intended for installation only by expert users. Please consult with a qualified technician for installation. Improper installation may result in damage to your equipment. EK Water Blocks assumes no liability
whatsoever, expressed or implied, for the use of these products, nor their installation. The following instructions are subject to change without notice. Please visit our web site at
installation of this product please read important notice, disclosure and warranty conditions printed on the back of the box.
Before you start using this product please follow these basic guidelines:
1. Please carefully read the manual before through before beginning with the installation process!
2. Please remove your motherboard from the computer to assure safest mounting process in order to prevent any possible damages to your CPU and/or motherboard's circuit board (PCB).
3. The EK High Flow and EK-PSC type fittings require only a small amount of force to screw them firmly in place since the liquid seal is ensured by the rubber o-ring gaskets.
4. The use of corrosion inhibiting coolants is always recommended for any liquid cooling system.

STEP 1: GENERAL INFORMATION.

STEP 2 cont.: PREPARING YOUR GRAPHIC CARD
1 cont.. REMOVING STOCK COOLER.
screws should be removed, including self-adhesive washers on both sides of the PCB (if
present). There are up to 10 screws on the back of the graphics card. After you remove the
fan housing, unplug the fan and also remove two push-pins securing the aluminium VRM
heatsink to the circuit board.

3. APPLYING THERMAL COMPOUND.

nVidia
compound: lightly coat GPU chip with for example
Arctic Cooling MX-2 ™,MX-4 ™ or GELID GC-Extreme ™
thermal grease. EKWB recommends to apply thermal
grease in cross form for best performance (see sample
picture).

STEP 3: INSTALLING WATER BLOCK

1. PLACING THERMAL PADS ON PCB.

enough pads to cover all surfaces that need to be covered to make block fully functional). EKWB recommends using small drops of electrically non-conductive (for
example: Arctic Cooling MX-2 ™, MX-4 ™ or GELID GC-Extreme™) thermal grease on each phase regulator (that is being covered with thermal pad) in order to even
further improve the thermal performance of the EK-FC670 series water block.
All disclosures, notices and warranty conditions are being written on the EKWB website. Please read terms of use.
Installation and mounting manual for EK-FC670 GTX water block
Sample picture of nVidia GeForce GTX 670 (NVA P2004 equivalent)
Remove all encircled screws. All heat sink assembly

4. CUTTING THERMAL PADS.

Apply thermal
have to be cut to smaller chunks in order to cover all the VRM components such as MOSFETs and drivers. PLEASE
REMOVE THE PROTECTIVE FOIL FROM BOTH SIDES OF THE THERMAL PADS PRIOR TO INSTALLATION.
Replacement thermal pads: Thermal Pad B – 1.0mm (75x50mm), Thermal Pad A – 1.0mm (100x16mm).
1: Thermal pad A – 1.0mm
(for memory IC):
Place thermal pads on chips so that numbers on chips match size of thermal pads. EKWB made sure users have more than

2. CLEANING THE PCB.

all screws securing it to the board. Wipe off the remains (by using non–abrasive
qtip
cloth or
the components and circuit board are completely clean. EKWB recommends the
use of denatured alcohol for removing TIM leftovers.
Your block comes with thermal pads, some of which are already pre-cut. Others
1 1 1 1 1 1
1
2
1

STEP 2: PREPARING YOUR GRAPHIC CARD.

1. REMOVING STOCK COOLER: Remove encircled screw on
the bracket (required only on certain models):
Carefully detach the original stock cooler after removing
, as shown on sample photo) of the original thermal compound until
2
1 1
1
1
Released on 26
www.ekwb.com for updates. Before
2: Thermal pad B – 1.0mm
(for VRM):
Some 4GB editions of
NVA P2004 equivalent
graphics cards have 8
RAM chips!
If four more RAM chips are
present on these otherwise
empty solder pads please
place 1mm thermal pads (1)
on them as well.
th
of June, 2012. Revision 1.0
