STEREO ELECTRIC MISTRESS
Digital Flanger/Chorus
Plug your guitar into the INPUT jack and run a cable from the Main Output to
your amplifier. If you want to produce lush Stereo flanges run a second cable
from the Stereo Output to a second amplifier. There are three basic controls
on the STEREO ELECTRIC MISTRESS.
Rate Knob: This knob controls the speed or rate of the LFO signal that
modulates the flanger. It also controls the rate of the Chorus effect. As you
turn the Rate knob up the rate will increase. When the Rate knob is turned
down between fully counter-clockwise and the 10 o'clock position, the Stereo
Electric Mistress will enter Filter Matrix mode. In Filter Matrix mode the LFO
signal is disconnected from the Flanger and Chorus so that you can manually
modulate the Flanger/Chorus by turning the Rate knob. Keep the Rate knob
below 10 o'clock to keep it in Filter Matrix mode.
1. Flanger Depth Knob: Controls the amount of Flange that is mixed with
the direct signal. The more you turn the knob clockwise, the more
pronounced the flanger effect.
2. Chorus Depth Knob: Controls the amount of the sweet chorus sound.
The more you turn the knob clockwise, the more pronounced the chorus
effect.
Hint: The Flanger and Chorus effect can be used together. While both
produce rich sweeping textures on their own, together they can produce
dramatically different and warm sonic textures that are not available when
one effect is used alone.
STATUS LED – This LED indicates the current state of the unit. When the
LED is lit up, the box is in EFFECT mode. When the LED is off, the box is in
BYPASS mode. Pressing the Footswitch will toggle
INPUT Jack – This ¼" jack is the audio input to the Stereo Electric
Mistress. The input impedance presented at the Input Jack is 2 MΩ.
