P A R T N A M E S
M I CROWAV E OV EN PART S
1
1 Door handle
Pull to open door.
2 Oven door with see-through window
3 Safety door latches
The oven will not operate unless the
door is securely closed.
4 Door hinges
5 Door seals and sealing surfaces
6 Turntable motor shaft
7 Removable turntable support
Carefully place the turntable support in
the center of the oven floor.
I N T ERACT I V E DI SPLAY
Downloaded from: http://www.usersmanualguide.com/
5 9
6
4
3 2
The two-line, Interactive Display spells out operating steps and
shows cooking hints. When HELP is lighted in the display, touch the
Custom Help pad to read a specific hint which may assist you.
1 0
1 3
1 2
1 1 3
8 Removable turntable
Place the turntable on the turntable
support securely. The turntable will
rotate clockwise or counterclockwise.
Only remove for cleaning.
9 Ventilation openings (Rear)
1 0 Oven light
It will light when oven is operating or
door is open.
1 1 Waveguide cover: DO NOT REMOVE.
1 2 Auto-Touch control panel
1 3 Interactive Display: 99 minutes, 99
seconds
7
8
7
