FORM FIT HDW 8M 01-E Manual

FORM FIT
HOOD PROTECTOR
Ford Ranger Edge 2001-2003

Thank you for purchasing a form fit hood protector.

Care Instructions

Clean the protector with a mild soap and water solution or plastic cleaner only.
Periodically check to make sure the bumpons are in place and the protector is secure.

Attention!

Do not use chemicals or solvents. Avoid using automatic car washes. Do not pull on the
protector when opening or closing the hood.
# 8 x 9/16" Screws
x 6

Tools Required

Installation Instruction

1. Open the hood. Be sure that the hood is clean and dry inside and out.
2. Center the protector on the hood to determine where the protector will mount.
3. Make sure that the protector is nested into the hood. Use a 1/8" drill bit to drill holes in
the hood centered through the holes in the mounting tab of the protector. Use care
when drilling to avoid damaging the hood or protector while doing this step.
4. Center the protector on the hood, and then insert screws through the protector and
tighten them into the holes drilled in step 3. See Illustration #1.
5. Install the (2) two bumpons as shown in Illustration #2. Attention: The bumpons must
be installed on the hood not the protector!!!! If the bumpons are installed on the
protector, they will wear through the paint.
6. On some vehicles it may be necessary to adjust the hood bumpers and/or latch for
proper clearance.
Note: Do not pull on the protector when opening or closing the hood.

Illustration #1 : Hardware Assembly

Hood
Protector
Screw
Made in Canada
HDW 8M 01-E
x 2
1 – Drill with a 1/8" twist bit
1 – Grease Pencil
#
2

Illustration # 2 : Bumpon Placement

Bumpons
Rev1.031231
FORM FIT
HOOD PROTECTOR
Ford Ranger Edge 2001-2003
Thank you for purchasing a form fit hood protector.
Care Instructions
Clean the protector with a mild soap and water solution or plastic cleaner only.
Periodically check to make sure the bumpons are in place and the protector is secure.
Attention!
Do not use chemicals or solvents. Avoid using automatic car washes. Do not pull on the
protector when opening or closing the hood.
# 8 x 9/16" Screws
x 6
Tools Required
Installation Instruction
1. Open the hood. Be sure that the hood is clean and dry inside and out.
2. Center the protector on the hood to determine where the protector will mount.
3. Make sure that the protector is nested into the hood. Use a 1/8" drill bit to drill holes in
the hood centered through the holes in the mounting tab of the protector. Use care
when drilling to avoid damaging the hood or protector while doing this step.
4. Center the protector on the hood, and then insert screws through the protector and
tighten them into the holes drilled in step 3. See Illustration #1.
5. Install the (2) two bumpons as shown in Illustration #2. Attention: The bumpons must
be installed on the hood not the protector!!!! If the bumpons are installed on the
protector, they will wear through the paint.
6. On some vehicles it may be necessary to adjust the hood bumpers and/or latch for
proper clearance.
Note: Do not pull on the protector when opening or closing the hood.
Illustration #1 : Hardware Assembly
Hood
Protector
Screw
Made in Canada
HDW 8M 01-E
x 2
1 – Drill with a 1/8" twist bit
1 – Grease Pencil
#
2
Illustration # 2 : Bumpon Placement
Bumpons
Rev1.031231
