Appliances
SECTION FIVE

COOKTOP WITH OVEN

The cooktop and oven use propane as a fuel source .
The cooktop burners are ignited with piezo ignition .
The oven pilot is lit with a match . The cooktop is
intended for cooking purposes only . It is not designed
as a heating source . The flame should be blue with a
lighter blue defined tips at the burner head . A yellow
flame or yellow tips indicate a rich fuel mixture that can
leave carbon on the bottom of cooking utensils .
To Use the Cooktop:
1 . The primary propane valve is open .
2 . The battery cut-off switch is on .
3 . House batteries are charged .
INFORMATION:
For detailed information, operating instructions
and safety refer to OEM manual .
94

LIGHTING THE COOKTOP BURNERS

• Place cookware on burner grate over the desired
burner .
• Push in and turn the appropriate burner knob to
Lite . Do not attempt to light more than one burner
at a time .
• Rotate Spark Control
Knob clockwise until
the burner lights .
• When
lights,
to the desired flame
setting .

USING THE OVEN

Lighting Oven Pilot:
• Light a cooktop burner to purge air from system then
shut off the burner .
• Push in oven control knob and rotate to Pilot On .
• Push and hold knob inward and light pilot under
031227e
broiler shelf .
• Once pilot is lit, hold in control knob for several
seconds then release . Ensure oven pilot remains lit .
• Rotate control knob to desired temperature .
• To extinguish pilot, push in the oven control knob
and rotate to Off .
WARNING:
Extinguish oven pilot when refueling or traveling .
Do not block vents in oven with any objects .
020327
the burner
rotate knob
Light Pilot Here Thermocouple
Lighting the Oven Pilot
Spark Control Knob
031274c
031227f
