WATER SYSTEM — INTRODUCTION
This section contains information about the operation
and care of various water system equipment . More
detailed information with CAUTION or WARNING
instructions for various equipment, other than what is
found in this section, can be found in the OEM manuals
in the owner information box .
If new to using a self-contained motorhome, use of
water will need to be conserved otherwise water does
not last long unless habits are modified .
For example, less water can be used for showering
if the shower is turned off while soaping down, and
turned back on to rinse . Plenty of water will be available
to meet personal needs once habits are adjusted .
The plumbing system is fully self contained (FSC); the
NOTE:
Illustration is a general depiction of water system Layout .
Fresh Water Tank
Fresh Water Tank Shut-Off Valve
FLEETWOOD RV CLASS A GAS 2020 OWNER'S MANUAL
entire fresh water system and waste water system can
operate independently of shore services . The plumbing
system includes holding tanks for fresh water (potable),
grey water (sinks and shower) and black water (toilet) .
An onboard water pump will supply all faucets and
toilets with water from the fresh tank . A monitor panel
will indicate holding tank levels .
If shore services are available, city water is used to
pressurize the water system so the onboard water
pump can be left off . The grey and black holding tanks
share a termination outlet . A sewer hose attaches
between the termination outlet and shore sewer
connection . Leave the black tank drain valve closed to
prevent solids from clogging the hose . Leave the drain
valve to the grey tank open . Drain and flush the grey
and black tanks prior to departure .
Kitchen Faucet
Toilet
Screen
Winterization Valve
Bathroom Faucet
Bypass Valves
040487v
Typical Water System
City Water Inlet
Shower
Water Heater
