Appliances
SECTION FIVE
Refrigerator Operation:
• House batteries must be
charged .
• The primary propane
valve must be open .
Figure A:
•
refrigerator 120 Volt AC
cord(s) must be plugged
in (located outside
behind refrigerator
access door) .
Dometic 2-Door Control Panel

CONTROL PANEL (2 DOOR)

On/Off Button:
Turns the refrigerator on or off .
• Push the On/Off button to turn on the refrigerator .
Gas Button:
Sets mode of operation .
• Automatic operation (Gas button not selected)
sets mode of operation to 120 Volt AC as the
primary energy source . If 120 Volt AC is not
available, the refrigerator will automatically switch
to Gas (propane) operation .
• Press the Gas button to select Gas (propane) only
operation .
Operation:
Auto feature selects 120 Volt AC as the primary
energy source . If AC discontinues or is unavailable,
the refrigerator will automatically switch to propane
operation .
• Leave the Gas button in the out position for
automatic energy selection .
• Press the Gas button to switch to propane operation
only .
• Temperature is present and not adjustable .
86
Icemaker
(if applicable)
The
Refrigerator
030967
Figure A

ICEMAKER (4 DOOR)

The icemaker requires 120 Volts AC to operate . Only
after the freezer reaches freezing temperature will the
icemaker function . City water or the water pump must
be on and the water valve for the water supply line to
the icemaker must be on .
To Icemaker
Icemaker Shut-Off Valve Located in Roadside Bay
030864j
• Pull the metal arm (bail) down to turn the icemaker
on .
• Push the arm up to turn the icemaker off .
031007
• Depending upon water pressure, the water refill
rate for the ice tray may need to be adjusted to
produce proper size cubes . See the OEM manual
for refill adjusting instructions .
Important:
• Do not operate icemaker while the motorhome
is in transit . Water may spill out during travel .
• Do not use the first one or two trays of ice
following storage .
• Do not operate the icemaker without water
pressure supplied to the refrigerator . Damage to
the icemaker assembly could occur .
Supply
040531
Off
On
