Menu level 1 Menu level 2
Functions
Defrosting
Modbus
→Factory reset
Service Languages
→Language
Language ENGLISH
Versions
Alarms
Service
Version VC300
Languages CD EC
→Versions
Appl.
1.22.00
Alarms
Boot 1.00.01
1.01.00
Service Alarms
Languages Fan Y
Versions EmT/Frost N
→Alarms
Damp/Rot N
Pb Fail N
Temp N
Filter Y

3.1 Setting Temperature

The supply air temperature is set manually in 5 steps in the main menu display by choosing the
temperature symbol (figure 2).
If an electrical or water re-heater is installed the temperature steps are 12.0, 14.5, 17.0, 19.5 and 22.0
°C. Default is 12.0 °C.
If the unit is used without any re-heater installed or if the re-heater is deactivated, the temperature steps
are 15.0, 16.0, 17.0, 18.0 or 19.0 °C . Default is 15.0 °C.
Each temperature step is illustrated by increasing the filling of the temperature symbol.
Fig. 2 Temperature symbol

3.2 Manual Setting of Fan speed

It's possible at any time to manually set the fan speed in the main menu display. By choosing the fan
symbol and confirming (figure 3) it's possible to increase or decrease the fan speed in the 3 steps, Low,
Nom and High. By doing so you override the programmed week schedule for the unit until the end of
CD Control panel
D2074870
Menu level 3
Factory reset
Really reset?
Yes/No
1.08.00
7
Explanation
Use this dialogue frame to return to factory
settings.
Set YES or NO
Note:
This will erase all your personal settings that
have been done for the unit.
Use this dialogue frame to select your local
language.
Set Language by turning the selection knob.
Shows current software version and unit.
Shows the alarm list and which alarms have
been triggered (indicated by Y). See alarm
list.
Service Menu
