- Page 1 M-PACK (HS) + PRIO HEAD Instruction manual Instruction manual M-PACK (HS) + PRIO HEAD PRIOLITE GmbH / Gattingerstr. 7 / D-97076 Würzburg / Tel +49(0)931 20700000 / eMail info@priolite.com / http://www.priolite.com...
- Page 2 Instruction manual PRIOLITE M-PACK 500 / M-PACK 1000 (HS) + PRIO HEAD 1000 USER MANUAL. Technical data are subject to change. No guarantee for misprints. The listed values are guide values and should not be understood as binding in a legal sense. The values can differ due to tolerances in used components.
-
Page 3: Table Of Contents
Instruction manual PRIOLITE M-PACK 500 / M-PACK 1000 (HS) + PRIO HEAD 1000 Table of contents. Introduction........................4 Description ........................4 Standard delivery ......................4 Intended use........................5 Safety instructions .......................5 Specific safety precautions when working with Lithium-ion batteries ......6 Technical data power pack..................7 Technical data flash head....................8... -
Page 4: Introduction
Instruction manual PRIOLITE M-PACK 500 / M-PACK 1000 (HS) + PRIO HEAD 1000 Introduction. Dear photographer, Thank you for selecting the PRIOLITE power pack and flash head. As a young, aspiring company, PRIOLITE intends to use innovative technologies and high- quality products to open up new market segments for professional photography. -
Page 5: Intended Use
Instruction manual PRIOLITE M-PACK 500 / M-PACK 1000 (HS) + PRIO HEAD 1000 Intended use. This power pack is intended for mobile use in professional photography in the studio or on location. Its purpose is the provision of electrical power for flash generation. The generated power output is delivered to the flash head. -
Page 6: Specific Safety Precautions When Working With Lithium-Ion Batteries
In any case, following first aid measures a doctor should be consulted. Lithium-ion batteries must be only recharged with the supplied PRIOLITE charger of the respective voltage class; use the 16V charger for M-PACK 500 and the 58V charger for M- PACK 1000 (HS). -
Page 7: Technical Data Power Pack
Instruction manual PRIOLITE M-PACK 500 / M-PACK 1000 (HS) + PRIO HEAD 1000 Technical data M-PACK 500 M-PACK 1000 (HS) Output: 500 Ws 1000 Ws Voltage supply: Lithium-ion battery with protection circuit, no memory effect 16V, 50 Wh 58V, 80 Wh weight approx. -
Page 8: Technical Data Flash Head
The Manfrotto Superclamp mounted on a tripod now takes the stand mount of the PRIOLITE tilt head. Hereby, the generator serves as a weight loading on the stand. Depending on the mounting height the power pack can be operated easily from waist height. -
Page 9: Attachment And Removal Of The Glass Dome Before Operating Flash Heads
Instruction manual PRIOLITE M-PACK 500 / M-PACK 1000 (HS) + PRIO HEAD 1000 Using the lateral small thumbscrew on the opposite side, the flash unit can be shifted ◊ backwards or forwards in the rail profile; this might be useful for weight compensation (e.g., when attaching heavy accessories). -
Page 10: Connection Of Softboxes To Flash Heads
Instruction manual PRIOLITE M-PACK 500 / M-PACK 1000 (HS) + PRIO HEAD 1000 The system is generally compatible with most reflectors of the Bowens / S-Line as well as HENSEL / E and EH series. As for HENSEL reflectors, the clamps fit around the raised edge of the reflector from the outside. -
Page 11: Replacement Of The Battery Drawer
The charger is designed for multi-voltage operation, i.e., it operates worldwide from 90V - 240V. The 16V chargers for M-PACK 500 have a 2-pin connector, the 58V chargers for M-PACK 1000 (HS) have a 6-pin connector so that any confusion is excluded. -
Page 12: Connection To The Charger
The control knob is used to set the desired flash power in 1/10 increments from a minimum of 16V to a maximum of 500J (M-PACK 500) or 1000J (M-PACK 1000 (HS)) covering 6 f- stops for M-PACK 500 and 7 f-stops for M-PACK 1000 (HS). The output is displayed on the two-digit 7-segment display in f-stops: 10 stands for maximum power and 5.0 (M-PACK... -
Page 13: Radio Function Box (Radio Operation)
Instruction manual PRIOLITE M-PACK 500 / M-PACK 1000 (HS) + PRIO HEAD 1000 By pressing the FULL button, the LED lamp lights up with maximum power. FREE mode allows for adjustment independently of the selected flash power output by simultaneously pressing the FREE button and turning the control knob. -
Page 14: Flash Triggering
Instruction manual PRIOLITE M-PACK 500 / M-PACK 1000 (HS) + PRIO HEAD 1000 Flash triggering Flashes can be triggered as follows: Flash triggering via the synchronization cable The power pack is connected to the camera using a synchronization cable with a 3.5 mm phone jack via the synchronization socket. -
Page 15: Maintenance
For replacement pull the flash tube carefully out of the plug connector and replace it with a new one (to be ordered from PRIOLITE) by plugging the three contacts into the sockets. Before using the unit once again the glass dome is to be mounted for safety reasons. -
Page 16: Contact Data
Instruction manual PRIOLITE M-PACK 500 / M-PACK 1000 (HS) + PRIO HEAD 1000 Contact information. PRIOLITE GmbH Gattingerstr. 7 D-97076 Würzburg Germany Phone: +49 (0)931 20700000 E-mail: info@priolite.com Internet: http://www.priolite.com Declaration of Conformity. The company PRIOLITE GmbH Gattingerstr. 7, D-97076 Würzburg, Germany...
