AUX L Series Technical Manual

Dc inverter free match r32
Hide thumbs Also See for L Series:
Table of Contents

Advertisement

Quick Links

Technical Manual
(DC Inverter Free Match R32)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L Series and is the answer not in the manual?

Questions and answers

Related Manuals for AUX L Series

Summary of Contents for AUX L Series

  • Page 1 Technical Manual (DC Inverter Free Match R32)
  • Page 2 2019.07...

  • Page 3: Table Of Contents

    CONTENTS CONTENTS ........................3 Part1 General Information .................. 7 1. Nomenclature ........................7 2. Unit appearance ......................... 8 3. Combination Table ......................14 4. Accessories Included ......................19 Part2 Features ...................... 20 1. Outdoor Units ........................20 2. Wall Mounted ........................24 3.
  • Page 4 Part4 Specification ....................36 1. Wall Mounted ........................36 2. Cassette ..........................47 3. Ceiling Floor ........................52 4. Duct ..........................56 5. Outdoor Unit ........................58 Part5 Dimension ....................68 1. Wall Mounted ........................68 2. Cassette ..........................69 3.
  • Page 5 2. Capacity amendment of different ambient temperature ..........86 3. Long piping length ......................88 4. Capacity amendment of different piping length .............. 89 5. Equivalent Pipe length conversion ................... 90 Part8 Static pressure curve ................92 1. 07K、09K Duct ......................92 2.
  • Page 6 1. Preparation........................179 2. Precaution ........................180 3. Wall Mounted ........................ 181 4. Cassette .......................... 183 5. Ceiling Floor ........................190 6. Duct ..........................193 7. Outdoor Unit ........................197 8. Connection piping installation ..................198 9. Emptying or vacuum ...................... 201 10.

  • Page 7: Part1 General Information

    Part1 General Information 1. Nomenclature Indoor Unit Outdoor Unit...

  • Page 8: Unit Appearance

    2. Unit appearance 2.1 Wall - Mounted Picture Capacity Range / Mode 07 K Btu/h AMWM-H07/4R3(L*) 09 K Btu/h AMWM-H09/4R3(L*) 12 K Btu/h AMWM-H12/4R3(L*) Series 18 K Btu/h AMWM-H18/4R3(L*) 07 K Btu/h AMWM-H07/4R3(F*) 09 K Btu/h AMWM-H09/4R3(F*) 12 K Btu/h AMWM-H12/4R3(F*) Series 18 K Btu/h...
  • Page 9 24K Btu/h AMWM-H24/4R3(J*)
  • Page 10 2.2 Cassette Picture Capacity Range / Mode 09 K Btu/h AMCA-H09/4R3A 12 K Btu/h AMCA-H12/4R3A Four-way cassette 18 K Btu/h AMCA-H18/4R3A MB13A-I MB13B-I Standard Panel MB09A MB09B Optional Panel...
  • Page 11 2.3 Ceiling Floor Picture Capacity Range / Mode 09 K Btu/h AMCF-H09/4R3A 12 K Btu/h AMCF-H12/4R3A Ceiling Floor 18 K Btu/h AMCF-H18/4R3A...
  • Page 12 2.4 Duct Picture Capacity Range / Mode 07 K Btu/h AMSD-H07/4R3A 09 K Btu/h AMSD-H09/4R3A 12 K Btu/h AMSD-H12/4R3A DUCT 18 K Btu/h AMSD-H18/4R3A...
  • Page 13 2.5 Outdoor Unit 1 drive 2 14k/18k 1 drive 3 21k/27k （AM2-H18/4DR3） Capacity(Btu) （AM2-H14/4DR3） （AM3-H21/4DR3） （ AM3-H27/4DR3） Picture 1 drive 4 36k 1 drive 5 42k Capacity(Btu) （AM4-H36/4DR3） （AM5-H42/4DR3） Picture...

  • Page 14: Combination Table

    3. Combination Table AM2-H14/4DR3 Suggested Combination One Unit Two Units — 1 drive 2 — — — — AM2-H18/4DR3 Suggested Combination One Unit Two Units 1 drive 2 9+12 7+12 — — — AM3-H21/4DR3 Suggested Combination One Unit Two Units Three Units —...
  • Page 15 One Unit Two Units Three Units 7+12 9+24 7+7+7 7+9+18 7+18 12+12 7+7+9 7+12+12 1 drive 3 — 7+24 12+24 7+7+12 9+9+9 — 18+18 7+7+18 9+9+12 — 9+12 18+24 7+9+9 9+12+12 — 9+18 — 7+9+12 AM4-H36/4DR3 Suggested Combination Two Units Three Units Unit 7+12...
  • Page 16 7+7+9+12 7+9+12+12 9+12+12+12 AM5-H42/4DR3 Suggested Combination One Unit Two Units 7+18 18+18 7+24 18+24 9+12 24+24 — 9+18 — — 1 drive5 9+24 — — 12+12 — — 12+18 — — 12+24 — — AM5-H42/4DR3 Suggested Combination Three Units 7+7+7 7+9+24 9+9+18 12+12+18...
  • Page 17 7+9+12 9+9+9 9+18+24 — 7+9+18 9+9+12 12+12+12 — AM5-H42/4DR3 Suggested Combination Four Units 7+7+7+7 7+7+12+12 7+9+12+24 12+12+12+12 7+7+7+9 7+7+12+18 7+12+12+12 12+12+12+18 7+7+7+12 7+7+12+24 9+9+9+9 — 7+7+7+18 7+9+9+9 9+9+9+12 — 1 drive5 7+7+7+24 7+9+9+12 9+9+9+18 — 7+7+9+9 7+9+9+18 9+9+12+12 — 7+7+9+12 7+9+12+12 9+12+12+12 —...
  • Page 18 7+7+7+9+18 7+7+9+12+18 9+9+9+9+12 — Note： All of the above indoor unit can be freely matched and combined, but must be installed strictly according to the above table or the cooling capacity and stability would be decreased.

  • Page 19: Accessories Included

    4. Accessories Included 4.1 Outdoor Units QUANTITY N° Name AM2-H14/ AM2-H18/ AM2-H21/ AM3-H27/ AM4-H36/ AM5-H42/ 4DR3 4DR3 4DR3 4DR3 4DR3 4DR3 Installer manual Drainage connector Pipe adaptor copper nuts 4.2 Indoor Units QUANTITY N° Name Wall Duct Cassette Ceiling & Floor Mounted User manual Remote control...

  • Page 20: Part2 Features

    AUX DC Inverter Free Match 50HZ Part2 Features 1. Outdoor Units Environmental-friendly Refrigerant R32 The GWP value of R32 is smaller, so the effect on the greenhouse effect is smaller. The ODP value of R32 is 0, so it’s no harm to our planet’s ozone layer.
  • Page 21 AUX DC Inverter Free Match 50HZ Energy Saving Cutting-edge DC inverter of sine wave control and active PFC technology realize low noise and economical operation. Space-Saving Installation Up to 5 indoor units can be connected to a single outdoor unit, which reduces the number of outdoor units required so as to save installation space.
  • Page 22 AUX DC Inverter Free Match 50HZ EXV Regulation Each Indoor Unit adjusted by a EXV, whole unit could achieve quick cooling/heating, and decrease throttling noise in indoor units.
  • Page 23 AUX DC Inverter Free Match 50HZ Electrical heater （Optional） Heater code: 11330029000010 220V 50W The electrical heater is used to melt ice on the chassis, make sure good heat exchange performance for condenser, powerful heating performance in very cold condition and create comfortable environment.

  • Page 24: Wall Mounted

    AUX DC Inverter Free Match 50HZ 2. Wall Mounted Wall Mounted type A/C is installed by the wall, compared with Floor & Standing type A/C, it has following advantages: Wall mounting installation combining with the decoration, makes the room more elegant; Flexible installation in anywhere in the wall and swing blowing, makes you feel more comfortable.

  • Page 25: Four-Way Cassette

    AUX DC Inverter Free Match 50HZ 3. Four-way Cassette Four-way cassette type A/C is installed under the ceiling, compared with Floor &Standing type A/C, it has following advantages: Ceiling installation combining with the decoration, makes the room more elegant; Flexible installation in anywhere in the ceiling and 4-direction blowing, makes you feel more comfortable.

  • Page 26: Ceiling Floor

    AUX DC Inverter Free Match 50HZ 4. Ceiling Floor Ceiling& Floor type A/C can be installed under the ceiling and also on the floor. Compared with normal Floor &Standing type A/C, it can be hoisted under the ceiling, saving room space; it is also the updating Product for Floor &...
  • Page 27 AUX DC Inverter Free Match 50HZ...

  • Page 28: Duct

    AUX DC Inverter Free Match 50HZ 5. Duct Duct type A/C can be installed under the ceiling and also on the floor. Compared with normal Floor &Standing type A/C, it can be hoisted under the ceiling, saving room space, it is also the updating Product for Floor &...

  • Page 29: Wifi Control

    AUX DC Inverter Free Match 50HZ 6.WIFI Control The optional WiFi modular makes possible monitor and control your AC while on the road through your mobile phone or pad.

  • Page 30: Part3 Piping System

    AUX DC Inverter Free Match 50HZ Part3 Piping System 1. 14K, 18K...
  • Page 31 AUX DC Inverter Free Match 50HZ OUTDOOR INDOOR FILTER SERVICE VALVE Tdef TLq-A CONDENSER FILTER PMVA TLq-B FILTER PMVB EVAP B EVAP A SOUND REDUCER Tas-B LPS1 Tas-A...

  • Page 32: K, 27K

    AUX DC Inverter Free Match 50HZ 2. 21K, 27K OUTDOOR INDOOR SERVICE VALVE FILTER TLq-A Tdef FILTER PMVA TLq-B CONDENSER FILTER PMVB TLq-C FILTER PMVC EVAP C EVAP B EVAP A SOUND REDUCER Tas-C LPS1 Tas-B Tas-A...
  • Page 33 AUX DC Inverter Free Match 50HZ 3. 36K...
  • Page 34 AUX DC Inverter Free Match 50HZ SERVICE VALVE OUTDOOR INDOOR FILTER FILTER PMVA FILTER PMVA Tdef FILTER PMVB CONDENSER FILTER PMVC EVAP D EVAP C EVAP B EVAP A SOUND REDUCER HPS1 LPS1...
  • Page 35 AUX DC Inverter Free Match 50HZ 4. 42K SERVICE INDOOR OUTDOOR VALVE FILTER PMVA FILTER FILTER PMVA Tdef FILTER PMVA CONDENSER FILTER PMVB FILTER PMVC EVAP E EVAP C EVAP D EVAP B EVAP A SOUND REDUCER HPS1 LPS1...

  • Page 36: Part4 Specification

    AUX DC Inverter Free Match 50HZ Part4 Specification 1. Wall Mounted 1.1 L Series (07K, 09K) Model Indoor Unit AMWM-H07/4R3(L*) AMWM-H09/4R3(L*) Btu/h 7165(3855-9220) 8701(3412~11260) Cooling 2.05(1.13-2.70) 2.55(1.00~3.30) Capacity Btu/h 7510(3340-8530) 9042(3753~11260) Heating 2.15(0.98-2.50) 2.65(1.10~3.30) Power Supply V~,Hz,Ph 220～240,50,1 220～240,50,1 Electric Data Cooling Power 40(12～68)
  • Page 37 AUX DC Inverter Free Match 50HZ Refrigerant Type Liquid Side mm(inch) 6.35(1/4) 6.35(1/4) Pipe Dia. Gas Side mm(inch) 9.52(3/8) 9.52(3/8) Drainage 16.5 16.5 320/680/765 320/680/765 Loading Qty 20/40/40H unit 2.2 L Series (12K, 18K) Model Indoor Unit AMWM-H12/4R3(L*) AMWM-H18/4R3(L*) Btu/h...
  • Page 38 AUX DC Inverter Free Match 50HZ Air Flow Volume m 1000 Performance Sound Pressure dB(A) Net Dim 800*300*198 970*315*235 (W*D*H) Dimension Pack Dim 870*370*282 1047×385×317 (W*D*H) 12.5 Weight Gross 10.5 14.5 Refrigerant Type Liquid Side mm(inch) 6.35(1/4) 6.35(1/4) Pipe Dia.
  • Page 39 AUX DC Inverter Free Match 50HZ 2.3 F Series (07K, 09K) Model Indoor Unit AMWM-H07/4R3(F*) AMWM-H09/4R3(F*) Btu/h 7165(3855-9220) 9000(4780-11260) Cooling 2.05(1.13-2.70) 2.58(1.40-3.30) Capacity Btu/h 7510(3340-8530) 9215(4095-10240) Heating 2.15(0.98-2.50) 2.70(1.20-3.00) V~,Hz, Power Supply 220～240,50,1 220～240,50,1 Electric Data Cooling Power Input 40(12～68) 40(12～68)
  • Page 40 AUX DC Inverter Free Match 50HZ Gas Side 9.52(3/8) 9.52(3/8) (inch) Drainage 16.5 16.5 Loading Qty 20/40/40H unit 384/768/864 384/768/864 2.4 F Series (12K, 18K) Model Indoor Unit AMWM-H12/4R3(F*) AMWM-H18/4R3(F*) Btu/h 12285(5800-12625) 17747(8530-19790) Cooling 3.50(1.70-3.70) 5.27(2.50-5.80) Capacity Btu/h 12625(5120-12625) 18085(7680-19790) Heating 3.50(1.50-3.70)
  • Page 41 AUX DC Inverter Free Match 50HZ e.Tube Outside φ7， Inner grooved Dia.And Material Air Flow Volume m3/h Performance Sound Pressure Noise dB(A) Level Net Dimension 750×285×200 900×310×225 (W*D*H) Dimension Packing Dimension 820×347×277 970×382×302 (W*D*H) Weight Gross Refrigerant Type Liquid Side 6.35(1/4)
  • Page 42 AUX DC Inverter Free Match 50HZ 2.5 F Series (24K) Indoor Unit AMWM-H24/4R3(F*) Model Btu/h 23986(9895~24908) Cooling 7.03(2.90~7.30) Capacity Btu/h 24054(7165~27296) Heating 7.05(2.10~8.00) Power Supply V~,Hz,Ph 220～240,50,1 Electric Data Cooling Power Input 63(16~88) Heating Power Input 63(16~88) Model YYK50-4 Indoor Fan Motor...
  • Page 43 AUX DC Inverter Free Match 50HZ Drainage 16.5 Stuffing Quantity 20/40/40H unit 203/427/488 2.6 J Series (07K, 09K) Model Indoor Unit AMWM-H07/4R3(J*) AMWM-H09/4R3(J*) Btu/h 7165(3855-9220) 9000(4780-11260) Cooling 2.05(1.13-2.70) 2.58(1.40-3.30) Capacity Btu/h 7510(3340-8530) 9215(4095-10240) Heating 2.15(0.98-2.50) 2.70(1.20-3.00) V~,Hz, Power Supply 220～240,50,1 220～240,50,1...
  • Page 44 AUX DC Inverter Free Match 50HZ Air Flow Volume Sound Pressure Noise dB(A) 40/38/34 40/38/34 Performance Level Sound Pressure Noise dB(A) Level Net Dimension 792*292*201 792*292*201 (W*D*H) Dimension Packing Dimension 888*370*290 888*370*290 (W*D*H) Weight Gross Refrigerant Type Liquid Side 6.35(1/4) 6.35(1/4)
  • Page 45 AUX DC Inverter Free Match 50HZ 2.7 J Series (12K, 18K) Model Indoor Unit AMWM-H12/4R3(J*) AMWM-H18/4R3(J*) Btu/h 12285(5800-12625) 17747(8530-19790) Cooling 3.50(1.70-3.70) 5.27(2.50-5.80) Capacity Btu/h 12625(5120-12625) 18085(7680-19790) Heating 3.50(1.50-3.70) 5.37(2.25-5.80) V~,Hz, Power Supply 220～240,50,1 220～240,50,1 Electric Data Cooling Power Input 40(12～68) 63(16～88)
  • Page 46 AUX DC Inverter Free Match 50HZ mm(inc Liquid Side 6.35(1/4) 6.35(1/4) Pipe Dia. mm(inc Gas Side 9.52(3/8) 12.7(1/2) Drainage 16.5 16.5 Loading Qty 20/40/40H unit 304/640/720 238/490/560 2.8 J Series (24K) Indoor Unit AMWM-H24/4R3(J*) Model Btu/h 23986(9895~24908) Cooling 7.03(2.90~7.30) Capacity...

  • Page 47: Cassette

    AUX DC Inverter Free Match 50HZ f.Coil Length x Height x Width mm 850*41*18 Air Flow Volume m3/h 1150 Performance Sound Pressure Noise Level dB(A) 49/43/37 Sound Pressure Noise Level dB(A) Net Dimension (W*D*H) 1132*330*232 Dimension Packing Dimension (W*D*H) 1205*400*317...
  • Page 48 AUX DC Inverter Free Match 50HZ Btu/h 10240(5460-13000) 13306(6930-15080) Heating 3.00(1.60-3.81) 3.9(2.03-4.42) V~,Hz,P Power Supply 220~240,50,1 220~240,50,1 Electric Data Cooling Power Input W 70(17.5-109) 70(17.5-109) Heating Power Input W 70(17.5-109) 70(17.5-109) Model XD30B XD30B Output Power Capacitor Speed (Hi/Mi/Lo) r/min...
  • Page 49 AUX DC Inverter Free Match 50HZ Packing(Panel) 710x710x80 710x710x80 Net(Body) Gross(Body) Weight Net(Panel) Gross(Panel) Refrigerant Type mm(inc Liquid Side 6.35(1/4) 6.35(1/4) Pipe Dia mm(inc Gas Side 12.7(1/2) 12.7(1/2) Drainage Loading Qty 20/40/40H unit 147/309/348 147/309/348...
  • Page 50 AUX DC Inverter Free Match 50HZ 2.2 18K Model Indoor AMCA-H18/4R3AA Btu/h 17060(8530-19107) Cooling 5.0(2.50-5.6) Capacity Btu/h 19107(10340-24000) Heating 5.6(3.03-7.03) Power Supply V~,Hz,Ph 220~240,50,1 Electric Data Cooling Power Input 70(17.5-109) Heating Power Input 70(17.5-109) Model XD30B Output Power Capacitor Speed (Hi/Mi/Lo)
  • Page 51 AUX DC Inverter Free Match 50HZ Net(Panel) 650x650x55 Packing(Panel) 710x710x80 Net(Body) Gross(Body) Weight Net(Panel) Gross(Panel) Refrigerant Type Liquid Side mm(inch) 6.35(1/4) Pipe Dia Gas Side mm(inch) 12.7(1/2) Drainage Loading Qty 20/40/40H unit 147/309/348...

  • Page 52: Ceiling Floor

    AUX DC Inverter Free Match 50HZ 3. Ceiling Floor 3.1 09, 12K Model Indoor AMCF-H09/4R3A AMCF-H12/4R3A Btu/h 9560(5120-12115) 12285(5800-12625) Cooling 2.80(1.50-3.55) 3.60(1.70-3.70) Capacity Btu/h 10240(5460-13000) 13306(6930-15080) Heating 3.00(1.60-3.81) 3.9(2.03-4.42) V~ ,Hz, Power Supply 220~240,50,1 220~240,50,1 Electric Data Cooling Power Input...
  • Page 53 AUX DC Inverter Free Match 50HZ Sound Power Noise dB(A) Level Net Dimension 929×660×205 929×660×205 (W*D*H) Dimension Packing Dimension 1010×720×290 1010×720×290 (W*D*H) Weight Gross Refrigerant Type Liquid Side mm(inch) 6.35(1/4) 6.35(1/4) Pipe Gas Side mm(inch) 12.7(1/2) 12.7(1/2) Diameter Drainage Stuffing...
  • Page 54 AUX DC Inverter Free Match 50HZ 3.2 18K Model Indoor AMCF-H18/4R3A Btu/h 18080(8530-19107) Cooling 5.3(2.50-5.6) Capacity Btu/h 19790(10340-24000) Heating 5.8(3.03-7.03) Power Supply V~,Hz,Ph 220~240,50,1 Electric Data Cooling Power Input 80(20-125) Heating Power Input 80(20-125) Model FP40A-ZL Output Power Indoor Fan Motor...
  • Page 55 AUX DC Inverter Free Match 50HZ Weight Gross Refrigerant Type Liquid Side mm(inch) 6.35(1/4) Pipe Diameter Gas Side mm(inch) 12.7(1/2) Drainage Stuffing Quantity 20/40/40H unit 136/280/315...

  • Page 56: Duct

    AUX DC Inverter Free Match 50HZ 4. Duct 4.1 07, 09K Model Indoor AMSD-H07/4R3A AMSD-H09/4R3A Btu/h 7506(3855-9220) 8872(5120-12115) Cooling 2.20(1.13-2.70) 2.60(1.50-3.55) Capacity Btu/h 8530(4575-10820) 9895(5800-12450) Heating 2.50(1.34-3.17) 2.90(1.70-3.65) Power Supply V~,Hz,Ph 220~240,50,1 220~240,50,1 Cooling Power Electric Data Input Heating Power...
  • Page 57 AUX DC Inverter Free Match 50HZ Level Net Dim (W*D*H) 700×470×200 700×470×200 Dimension Packing 1005×580×275 1005×580×275 Dim(W*D*H) 18.5 18.5 Weight Gross Refrigerant Type Liquid Side mm(inch) 6.35(1/4) 6.35(1/4) Pipe Dia Gas Side mm(inch) 12.7(1/2) 12.7(1/2) Drainage 16.5 16.5 Loading Qty...

  • Page 58: Outdoor Unit

    AUX DC Inverter Free Match 50HZ Tube x Row Pitch 20.5x 12.7 20.5x 12.7 Fin Pitch Fin Material Hydrophilic aluminum Hydrophilic aluminum Tube Dia.& φ7， Inner grooved φ7， Inner grooved Material Coil L x H x W 541x255x 25.4 840x255x 25.4 Heat Exchange 5.01...

  • Page 59: Power Supply V~,Hz

    AUX DC Inverter Free Match 50HZ System Format 1 drive 2 1 drive 2 Btu/h 13989(6142-15388) 18084(6824-19892) Cooling 4.1(1.8-4.51) 5.3(2.0-5.83) Capacity Btu/h 16378(6995-18015) 19107(7541-21017) Heating 4.8(2.05-5.28) 5.6(2.21-6.16) Power Supply V~,Hz,Ph 220~240,50,1 220~240,50,1 Cooling Power Input 1240(198-2100) 1750(280-2300) Heating Power Input...
  • Page 60 AUX DC Inverter Free Match 50HZ Inverter Fan Type DC Inverter DC Inverter Motor Brand WELLING WELLING Quantities Insulation Class Safe Class IP24 IP24 Input Power Output Power Capacitor Speed r/min 850-350 850-350 Material Plastic Plastic Outdoor Fan Diameter Ф421×117 Ф421×117...

  • Page 61: Heating Power Input

    AUX DC Inverter Free Match 50HZ Gross Type Refrigerant type/Quantity Charged Volume 1.07 Liquid Side mm(inch) 2×6.35(1/4) 2×6.35(1/4) Gas Side mm(inch) 2×9.52(3/8) 2×9.52(3/8) Max. length for all rooms (m) Max. length for one IU Piping Max. height difference between IU and OU (m) Max.

  • Page 62: Rated Current

    AUX DC Inverter Free Match 50HZ Input Rated Current 8.3/7.8 10.7/9.8 (cooling&heating) Max current Max power SEER/SCOP 6.57/4.38（F） 6.30/4.04（F） SEER/SCOP 6.45/4.39（L） 6.29/4.04（L） Performance SEER/SCOP 6.57/4.39(J) 6.30/4.04(J) Energy Rate A++/A+ A++/A+ EER/COP 3.23/3.71 3.21/3.61 Model KTN150D30UFZ KTM240D57UKP Quantity Type Twin Rotary...
  • Page 63 AUX DC Inverter Free Match 50HZ Output Power Capacitor Speed r/min 870-350 870-350 Material Plastic Plastic Outdoor Fan Diameter Ф470×140 Ф470×140 Fan Quantity a.Number Of Row b.Tube Pitch(a)x 22x19.05 22x19.05 Row Pitch(b) c.Fin Pitch Hydrophilic aluminum Hydrophilic Outdoor Coil d.Fin Material aluminum fin e.Tube Outside...

  • Page 64: Quantity

    AUX DC Inverter Free Match 50HZ mm(inc Gas Side 3×9.52(3/8) 3×9.52(3/8) Max. length for all rooms (m) Max. length for one IU (m) Max. height difference between IU and OU (m) Max. height difference between IUs (m) Ambient Temp (Cooling/Heating) -15~52℃/-15~24℃...

  • Page 65: A++/A

    AUX DC Inverter Free Match 50HZ SEER/SCOP 6.10/4.00(F) 6.10/4.10（F） SEER/SCOP 6.20/4.00(L) 6.10/4.00(L) SEER/SCOP 6.15/4.12（J） 6.14/4.14（J） Energy Rate A++/A+ A++/A+ EER/COP 2.66/3.49 2.70/3.47 Model KTF310D43UMT KTF310D43UMT Quantity Type Rotary Rotary Performance Brand GMCC GMCC Capacity 10010 10010 Input 2765 2765 Power Supply...
  • Page 66 AUX DC Inverter Free Match 50HZ Material Plastic Plastic Diameter Ф550×125 Ф550×125 Fan Quantity a.Number Of b.Tube Pitch(a)x 20.5x19.05 20.5x19.05 Row Pitch(b) c.Fin Pitch Outdoor Fan Hydrophilic Hydrophilic aluminum d.Fin Material aluminum fin e.Tube Outside φ7， Inner grooved φ7， Inner grooved Dia.And Material...
  • Page 67 AUX DC Inverter Free Match 50HZ Liquid Side mm(inch) 4×6.35(1/4) 5×6.35(1/4) Gas Side mm(inch) 4×9.52(3/8) 5×9.52(3/8) Max. length for all rooms (m) Max. length for one IU (m) Piping Max. height difference between IU and OU (m) Max. height difference...

  • Page 68: Part5 Dimension

    AUX DC Inverter Free Match 50HZ Part5 Dimension 1. Wall Mounted AMWM-H18 Physical AMWM-H07 AMWM-H09 AMWM-H12 /4R3(L*) Dimension /4R3(L*) /4R3 (L*) /4R3(L*) Length Height Width AMWM-H24 Physical AMWM-H07 AMWM-H09 AMWM-H12 AMWM-H18 /4R3(F*) Dimension /4R3(F*) /4R3(F*) /4R3(F*) /4R3(F*) 1082 Length Height...

  • Page 69: Cassette

    AUX DC Inverter Free Match 50HZ 1132 Length Height Width 2. Cassette 09K,12K,18K (515) (463) (55)
  • Page 70 AUX DC Inverter Free Match 50HZ...

  • Page 71: Ceiling Floor

    AUX DC Inverter Free Match 50HZ 3. Ceiling Floor 09K, 12K, 18K (841)

  • Page 72: Duct

    AUX DC Inverter Free Match 50HZ 4. Duct 4.1 07K 09K 12K Air Return Air Return Air Outlet Air Outlet...
  • Page 73 AUX DC Inverter Free Match 50HZ 4.2 18K Air Return 1000 1048 (832) Air Outlet (110) Air Outlet...

  • Page 74: Outdoor Unit

    AUX DC Inverter Free Match 50HZ 5. Outdoor Unit 5.1 14K, 18K (822) (545)
  • Page 75 AUX DC Inverter Free Match 50HZ 5.2 21K, 27K (854) (540)
  • Page 76 AUX DC Inverter Free Match 50HZ 5.3 36K, 42K (1000) (675)

  • Page 77: Part6 Electrical Principle Diagram

    AUX DC Inverter Free Match 50HZ Part6 Electrical Principle Diagram 1. Wall Mounted 1.1 L Type (07K, 09K, 12K, 18K) N O TE: "Lo " o n th e te rm i n a l b l o c k d o e s n o t n e e d to b e c o n n e c te d .
  • Page 78 AUX DC Inverter Free Match 50HZ 1.2 F Type (07K,09K,12K,18K,24K) N O TE: D o tte d l i n e p a rt i n th e fr a m e m a y n o t b e u se d .
  • Page 79 AUX DC Inverter Free Match 50HZ 1.3 J Type (07K,09K,12K,18K,24K) NOTE:if used as MONO unit, for the standby control needs, the cross section area of cable connected to L,Lo,N,S must be sufficient for the maximum system current. The maximum system current is equal to the sum of indoor unit and outdoor unit rated current if used as MULTI unit Lo on the terminal block does not need to be connected.
  • Page 80 AUX DC Inverter Free Match 50HZ...

  • Page 81: Cassette

    AUX DC Inverter Free Match 50HZ 2. Cassette 09K,12K,18K W a te r Fa n M o to r Pu m b Tra n sfo rm e r Ste p M o to r C P 10 A C - N...

  • Page 82: Ceiling Floor

    AUX DC Inverter Free Match 50HZ 3. Ceiling Floor 09k, 12k, 18k...

  • Page 83: Duct

    AUX DC Inverter Free Match 50HZ 4. Duct 07K, 09K, 12K, 18K...

  • Page 84: Outdoor Unit

    AUX DC Inverter Free Match 50HZ 5. Outdoor Unit 5.1 14K, 18K, 21K, 27K Electronic Expansion Valve Temperature Sensor Controller Indoor UnitA Indoor UnitB Indoor UnitC POWER...
  • Page 85 AUX DC Inverter Free Match 50HZ 5.1 36K, 42K 16437010000522 Metal Reactor1 Reactor2 DC FAN High 4-Way partition Pressure Heater T2 T3 T4 T5 Valve T51 T52 T31T32 Switch Pressure Switch DC-M1 L1-I L1-O L2-I L2-O Drive Modular Board AC-N-OUT...

  • Page 86: Part7 Capacity Amendment

    AUX DC Inverter Free Match 50HZ Part7 Capacity Amendment 1. Operation range Cooling capacity (KBtu/h) Power supply 220-240V~/50Hz Voltage 187~242V Cooling -15~52℃ Ambient temperature Heating -15~24℃ 2. Capacity amendment of different ambient temperature 2.1 Amendment coefficient of Cooling capacity under different indoor/outdoor DB/WB temperature K1 IDU temp.℃...
  • Page 87 AUX DC Inverter Free Match 50HZ ——Amendment coefficient of cooling capacity could be found from table above. 2.2 Amendment coefficient of heating capacity under different indoor/outdoor DB/WB temperature K2 Outdoor air inlet DB temperature℃ IDU temp.℃ 0.93 0.97 1.06 1.08 1.14...

  • Page 88: Long Piping Length

    AUX DC Inverter Free Match 50HZ 3. Long piping length Cooling capacity (Btu/h) Φ Φ Φ Φ Liquid pipe 6.35*2 9.52*3 9.52*4 9.52*5 Connection Pipe(mm) Φ Φ Φ Φ Gas pipe 9.52*2 15.88*3 15.88*4 15.88*5 Max. length for all rooms (m) Max.

  • Page 89: Capacity Amendment Of Different Piping Length

    AUX DC Inverter Free Match 50HZ 4. Capacity amendment of different piping length 4.1 Amendment coefficients of heating and cooling capacity under different height drop Different Cooling Capacity modified coefficients at different height: Equivalent pipe Note: H = Height of Outdoor Unit － Height of Indoor Unit...

  • Page 90: Equivalent Pipe Length Conversion

    AUX DC Inverter Free Match 50HZ Note: H = Height of Outdoor Unit － Height of Indoor Unit 4.2 Correction capability Cooling capacity = Rated cooling capacity xK1xK3 Heating capacity = Rated heating capacity xK2xK3 5. Equivalent Pipe length conversion Equivalent pipe length means converting pipe elbow to straight pipe length after considerate the pressure loss.
  • Page 91 AUX DC Inverter Free Match 50HZ bends and 2 oil loops during the installation, then the equivalent pipe length should be: L=25+0.25×5+2.0×2=30.25(m) Note: If there is relatively level difference of indoor and outdoor unit, S-shaped oil trap must be installed every 8~10m for vertical pipe.

  • Page 92: Part8 Static Pressure Curve

    AUX DC Inverter Free Match 50HZ Part8 Static pressure curve 1. 07K、09K Duct...

  • Page 93: K Duct

    AUX DC Inverter Free Match 50HZ 2. 12K Duct...

  • Page 94: K Duct

    AUX DC Inverter Free Match 50HZ 3. 18K Duct...

  • Page 95: Part9 Controller

    AUX DC Inverter Free Match 50HZ Part9 Controller 1. Controller Controller IDU type Standard Optional Wall Mounted YK-H(AUX) YK-K(AUX) Cassette YK-K(AUX) XK-04 Ceiling & Floor XK-04 YK-L(AUX) Duct...
  • Page 96 AUX DC Inverter Free Match 50HZ XK05-DY(AUX)120 XK-04 1.1 K series POWER button: Switch the unit ON/OFF. MODE button: Select mode, press the button one time, then the operation modes will change in turn as Auto-Cooling-Dehumidify-Heating TEMP + button and TEMP - button: Temperature adjustment range: 16~32 FAN button: Change the fan speed;...
  • Page 97 AUX DC Inverter Free Match 50HZ Feeing button: Press this button for setting the feeling function. The LCD shows the actual room temperature when the function is set and it shows the setting temperature when the function is cancelled. The function is invalid in the fan mode.
  • Page 98 AUX DC Inverter Free Match 50HZ SCREEN button: Press the button to let the LCD display working or not. 1.2 H series...
  • Page 99 AUX DC Inverter Free Match 50HZ POWER button: Switch the unit ON/OFF. MODE button: Select mode, push the button one time, then the operation modes will change in turn as Auto-Cooling-Dehumidify-Heating TEMP + button and TEMP - button: Temperature adjustment range: 16~32...
  • Page 100 AUX DC Inverter Free Match 50HZ 3. After the setting of sleeping mode, the heating operation enables the set temperature to drop 2℃ after 1 hour and another 2℃ automatically after 1hour. 4. The air condition runs in sleeping mode for 7hours and stops automatically.
  • Page 101 AUX DC Inverter Free Match 50HZ 1.3 Wired Controller XK-05/XK-04 XK-05 Features Technical indicator 1. Power source: voltage DC 12V; 2. Work temperature range of PCB:(-10~+70)℃; 3. Work humidity range of PCB:RH20%~RH90%; 4. Button: Touch button 5. Dimensions(W*H*D):120*120*20mm Main functions 1.
  • Page 102 AUX DC Inverter Free Match 50HZ Main functions 1. 9-keytouch button input 2. Buzzer prompt tone function 3.Comfort one-button setting 4. LCD+ white backlight 5. Display the failure of main controller 6. Ambient temperature detection sensor 7.Connect to indoor unit via 3-core shielded cable 8.
  • Page 103 AUX DC Inverter Free Match 50HZ XK-04 Detailed operation instructions (6)
  • Page 104 AUX DC Inverter Free Match 50HZ 1.【ON/OFF button】 Press- "ON / OFF" button to start or shutdown the unit. 1.1.When the unit is running, users can regulate the operation mode, fan speed, setting temperature, special functions and other parameters on the wired controller XK-05 Set Temp.
  • Page 105 AUX DC Inverter Free Match 50HZ 2.1.When the unit is running, press" ∧ " or " ∨ "button to increase or decrease the setting temperature by 1℃. Under COOL, DRY, and HEAT modes, the setting temperature range is 16 ℃ ~ 32 ℃；The controller will display" Set temp." to show the setting temperature;...
  • Page 106 AUX DC Inverter Free Match 50HZ The initial setting temperature for each mode is 24 ° C, and there is no temperature setting and automatic wind under FAN mode. 4.【"Fan"buttom】 When the unit is running, press "Fan" button to switch fan speed in the following order:...
  • Page 107 AUX DC Inverter Free Match 50HZ " Up and Down Swing On " " Up and Down & Left and RightSwing OFF " “ Up and Down Swing OFF " " Up and Down & Left and RightSwing On "...
  • Page 108 AUX DC Inverter Free Match 50HZ 6.2.After entering timing time setting interface, the default timing time is 0.5H, at this moment, press" ∧ " or " ∧ "button to regulate the timing time. If the button is not pressed for 10 seconds, the timing setting will be canceled, and then return to the state of non-timing.
  • Page 109 AUX DC Inverter Free Match 50HZ Time off Time off Room Temp. Room Temp. TI M E R FA N S WI NG M ODE Time on Time on FUNCTI ON ON/ OFF Set Temp. Set Temp. XK-04 6.4.After the setting "Timer On"function, you can adjust the fan speed, running mode, set temperature, and swing angle.
  • Page 110 AUX DC Inverter Free Match 50HZ Ti m e o n Ti m e o n Se t Te m p . Se t Te m p . T IM ER F AN SWING M O DE F UNCT IO N...
  • Page 111 AUX DC Inverter Free Match 50HZ 6.5.Timing range: 0.5～24 hours. press " ∧ " or " ∧ "button once, the timing time will increase or decrease by 0.5 hours.When the timing time is more than 10 hours, press " ∧ " or " ∧ " button once, the timing time will increase or decrease by1 hour.
  • Page 112 AUX DC Inverter Free Match 50HZ 1.【"Turbo"】 Turbo function: The fan speed will be ultra-high in turbo mode and users can achieve rapid cooling or heating effect. Enter turbo function: 1.When the unit is running in cooling or heating mode, press "Function" key to enter the interface of function selection.
  • Page 113 AUX DC Inverter Free Match 50HZ 1. When turbo function is opened, press "Function" button to enter the interface of function selection. 2. Press " ∧ " or " ∧ "button to switch to strong function, at this moment, icon"...
  • Page 114 AUX DC Inverter Free Match 50HZ Turbo performance is high fan speed, but " " icon and " " icon do will not display. 2.【"Sleep"】 Sleep function: Make indoor unit will run according to pre-set sleep temperature curve, which creates a comfortable sleep environment and improves sleep quality Enter sleep function: 1.
  • Page 115 AUX DC Inverter Free Match 50HZ Cancel "sleep" function: 1. In the state of running, press "Function" button to enter the interface of function selection. Sleep 2. Press " ∧ " or " ∧ "button to switch to sleep function, "...
  • Page 116 AUX DC Inverter Free Match 50HZ 3.【"ECO"】 Enter ECO function: 1. Press "Function" button to enter the interface of function selection. 2. Press " ∧ " or " ∧ "button to switch to ECO function, at this moment " "icon is flashing 3.Press "Function"...
  • Page 117 AUX DC Inverter Free Match 50HZ Cancel ECO function: 1. Press "Function" button to enter the interface of function selection. 2. Press " ∧ " or " ∧ "button to switch to ECO function, at this moment " "icon is flashing 3.Press "Function"...
  • Page 118 AUX DC Inverter Free Match 50HZ 4. 【"Mildew-proof"】 Mildew-proof function: After shutdown, the air conditioner would automatically dry the moisture in the evaporator of indoor unit, so as to avoid mildewing. Enter mildew-proof function: 1.Under COOL and DRY mode, press "Function" button to enter the interface of function selection 2.Press "...
  • Page 119 AUX DC Inverter Free Match 50HZ Cancel fungus-proof function: 1.When mildew proof function is ON, press "Function" button to enter the interface of function selection 2.Press " ∧ " or " ∧ " button to mildew-proof function icon " " is flashing;...
  • Page 120 AUX DC Inverter Free Match 50HZ 5.【"Light Sensation"】 Light sensation function: Detect the On and Off of indoor lamplight and switch o low fan speed when the lamplight is off, which can reduce the noise and create a comfortable sleep environment...
  • Page 121 AUX DC Inverter Free Match 50HZ Sleep Se t Te m p . TI MER SWI NG MODE TI MER SWI NG MODE FUNCTI ON ON/OFF FUNCTI ON ON/OFF Sleep Se t Te m p . Se t Te m p .
  • Page 122 AUX DC Inverter Free Match 50HZ Sleep Se t T e mp . T IM ER F AN SWING M ODE F UNCT ION ON/ OF F Se t T e mp . T IM ER F AN SWING M ODE...
  • Page 123 AUX DC Inverter Free Match 50HZ Ro o m T e mp . Ro o m T e mp . T IM ER F AN SWING M O DE C l e an F UNCT IO N O N/O F F Ro o m T e mp .
  • Page 124 AUX DC Inverter Free Match 50HZ 2.【"Shielding"】function display When unit is locked by centralized control, the wired controller will display 3.【"Mute"】 function display When the unit enter silent function, display " " icon, when silent function is cancelled,the icon does not display.
  • Page 125 AUX DC Inverter Free Match 50HZ 7.【"Child Lock" function display】 Press both" ∧ " or " ∧ " buttons for more than 5S to enter locking, the controller will display " " . In the state of locking, operations on the wired controller are disabled (but remote control receiving is valid).
  • Page 126 AUX DC Inverter Free Match 50HZ 1. Power supply: voltage DC 12V; Wired 2. Work temperature range of PCB:(-10~+70)℃; controller 3. Work humidity range of PCB:RH20%~RH90%;...

  • Page 127: Parameters Setting

    AUX DC Inverter Free Match 50HZ 2. Parameters Setting Indoor unit’s parameters can be set by remote controller (YK-L) and wired remote controller—for after-sales (In indoor side, after a new PCB was replaced, indoor parameters set is necessary). 2.1 Parameter setting table...
  • Page 128 AUX DC Inverter Free Match 50HZ 2.2 Working mode parameter (Heating only function) Under heating only mode, IDU cannot receive signal of other working mode besides “OFF” signal. Once change the parameter, need to power on again to activate the function.
  • Page 129 AUX DC Inverter Free Match 50HZ 2.3 Parameter Setting by YK-L Enter the setting interface ① Make sure the remote controller is off ② Press the two white button at the down side simultaneously more than 10s to enter the address setting mode.
  • Page 130 AUX DC Inverter Free Match 50HZ For example: If you changed a new PCB to 18K cassette indoor unit , then you should set the type of the unit , check the above【Parameter Setting Items table】--- Mode of IDU is 【04】 ，18K cassette parameter is 【37】...
  • Page 131 AUX DC Inverter Free Match 50HZ In the timing setting zone: HH means series NO. MM means parameter value. After entering into IDU parameter checking , via pressing the“ ”or“ ”button ,you can check the parameter value of series NO.【04】【05】【1】.
  • Page 132 AUX DC Inverter Free Match 50HZ 2. Press “ ”or“ , change the parameter value. 1. Only in checking model, Press “FUNCTION” for 5S , enter parameter checking model For example: If you want to change the PCB from cassette type to mid duct type for 42k unit , you should set the type of the unit , check the above【Parameter Setting Items table】--- Mode of IDU is...
  • Page 133 AUX DC Inverter Free Match 50HZ 【0411】change to 【0439】 （step2） 04 39 Press the“ ”or“ ”button to get “ ” ④ ⑤ After finishing setting , press “ “to confirm FUNCTION...

  • Page 134: Room Card Function

    AUX DC Inverter Free Match 50HZ 3. Room Card Function 3.1 Function setting Contact Parameter Model Operation model specification setting State 0900 Stand （default) The IDU Will be into standby mode, can be controlled by controller Room Card 0901 (optional)
  • Page 135 AUX DC Inverter Free Match 50HZ Step 2 09 01 ④ Press the“ ”or“ ”button to get “ ” ⑤ after finishing setting , press “FUNCTION “to confirm 3.2 Wiring diagram When the room card is inserted, the air conditioning can be controlled; when you leave the room, the AC will standby, can’t be controlled.

  • Page 136: Wifi Module

    AUX DC Inverter Free Match 50HZ 4. Wifi Module 4.1 Wi-Fi Module Configuration ① APP Download Mobile terminal scan the following dimensional code to download APP, or search “AC Freedom” in APPSTORE and Google store ② Light Commercial WIFI Module Installation...
  • Page 137 AUX DC Inverter Free Match 50HZ the configuration  Connect mobile terminals to WIFI, open APP “AC Freedom”, and then operate following the steps below: Note: If the configuration fails or you change the password of wireless router, you need to reset the WIFI module to reconnect: Turn on the power of the module, then repeat the steps above for APP configuration.
  • Page 138 AUX DC Inverter Free Match 50HZ If unable to properly configured or connect the WIFI box:  Make sure the WIFI box for wiring is properly connected.  Long press WIFI box 8 seconds to reconfigure the positive button. If the problem can't be solved, please contact after sales person.

  • Page 139: Part10 Explosive View

    AUX DC Inverter Free Match 50HZ Part10 Explosive View 1. Wall Mounted 1.1 L Type (07K, 09K, 12K) 27 26...
  • Page 140 AUX DC Inverter Free Match 50HZ Material code Part name 11220502004504 Panel 11222014000521 Display board assembly 11220508000142 Filter 11320096000105 Screw cover 11220509000062 Medium frame wiring cover 11320078000196 Right-side cover 11320065000028 Breakwater 11220513000067 Air blade 11230003000127 Indoor motor 11320052000032 Motor cover...
  • Page 141 AUX DC Inverter Free Match 50HZ 11320061000275 Decoration board 1.2 L Type (18K)
  • Page 142 AUX DC Inverter Free Match 50HZ Material code Part Name 11320003003301 Panel 11320005000388 air louver（Horizontal） 11320094000054 Decoration board 11222014000522 Display board assembly 11220508000144 Filter 11320076000057 Medium frame wiring cover 11321071000006 Medium frame wiring cover scale board 11320096000104 Screw cover 11320078000207...
  • Page 143 AUX DC Inverter Free Match 50HZ 1.3 F Type (07K, 09K, 12K)
  • Page 144 AUX DC Inverter Free Match 50HZ Material code Part name 11220502004342 Decro panel 11320135000018 Air louver（Horizontal） 11220508000139 Filter 11320096000104 Screw cover 11320076000084 Medium frame wiring cover 11320002000305 Medium frame 11320085000094 Guide vane linkage 11320017000125 Left-right swing blade 11320127000007 Step motor bracket...
  • Page 145 AUX DC Inverter Free Match 50HZ 1.4 F Type (18K) 18 19 16 17...
  • Page 146 AUX DC Inverter Free Match 50HZ Material code Part name 11321003000028 Mounting plate assembly 11320084000014 Pipe clamp 11230005000013 IDU fan motor 11220513000066 Scroll fan 11224003000695 Evap asm 11320052000043 Fan motor cover 11220551000003 bearing assembly 11220500000213 Chassis assembly 11220508000140 Filter 11320002000303...
  • Page 147 AUX DC Inverter Free Match 50HZ 1.5 F Type (24K) 11 12...
  • Page 148 AUX DC Inverter Free Match 50HZ BOM Code Part Name Quantity 11320003002072 panel 11320005000288 air louver（Horizontal） 11222014000608 display board 11220508000138 filter 11320096000075 Screw cover 11320076000057 medium frame wiring cover 11320002000233 medium frame 11320017000110 left-right swing blade 11320135000008 air louver 11320079000016...
  • Page 149 AUX DC Inverter Free Match 50HZ 1.6 J Type ( 07K, 09K, 12K) 13. 1 13. 2 13. 3 9. 7 9. 6 9. 5 9. 4 9. 3 9. 8 9. 2 9. 1 18 9. 9 9. 10 19.
  • Page 150 AUX DC Inverter Free Match 50HZ Chinese Name Part Name Part Code Quantity Panel 11320003002875 面板 Display board assembly 11222014000608 显示灯板组件 11320005000359 Air louver（Horizontal） 导风门 Screen assembly 11220508000146 过滤网组件 Medium frame panel 11320088000038 中框装饰板 Left cover 11320078000159 左端盖 Medium frame 11320002000292 中框...
  • Page 151 AUX DC Inverter Free Match 50HZ Motor cover 11320052000044 电机压盖 Inside the motor 11230003000125 内电机 Hanging panel 11221500000034 挂板组件 Line pressure climbing 11320084000013 管路压攀 Negative ion generator 11330016000018 负离子发生器 Main controller 11222003002899 主控制器 19.1 电控盒屏蔽盒 A Electric control box shielding box A 11321020000033 19.2...
  • Page 152 AUX DC Inverter Free Match 50HZ 1.7 J Type (18K) 29 30 31 32 27 28 23 22 19 18...
  • Page 153 AUX DC Inverter Free Match 50HZ Chinese Name Part Name Part Code Mounting plate assembly 11321003000028 挂板组件 Motor support plate 11320074000004 电机支撑板 Indoor fan motor 11230005000013 室内电机 The motor holder 11320087000030 电机压板 The motor holder 11320087000031 电机压板 Evaporator left side carriage 11320015000138 蒸发器左支架...
  • Page 154 AUX DC Inverter Free Match 50HZ Panle 11320003002874 面板 底座保温泡沫 B Chassis foam B 11328030000012 底座保温泡沫 A Chassis foam A 11328030000013 底座保温泡沫 D Chassis foam D 11328030000014 Left-right swing blade 11320017000153 自动导风叶片 Electric control box cover shield plate 11321020000038 电控盒护盖屏蔽板...
  • Page 155 AUX DC Inverter Free Match 50HZ 1.8 J Type (24K) 13. 2 13. 1 13. 3 13. 4 9. 1 9. 2 8. 3 8. 2 13. 5 9. 3 18. 1 18. 2 18. 3 18. 5 18. 4 18.
  • Page 156 AUX DC Inverter Free Match 50HZ Chinese Name Part Name Part Code Panel 11320003002880 面板 Display board 11222014000608 显示灯板 Air louver（Horizontal） 11320005000360 导风门 Filter 11220508000145 过滤网 Screw cover 11320096000102 螺钉盖 Medium frame wiring cover 11320076000105 中框接线盖 Medium frame decorating plate 11320088000039 中框装饰板...
  • Page 157 AUX DC Inverter Free Match 50HZ 13.1 Chassis 11320001000269 底座 13.2 Stopple 11333003000009 水塞 13.3 Air louver 11320135000026 蜗舌 13.4 Left-right swing blade 11320017000155 左右扫风叶片 13.5 Manual air guide link 11320085000106 手动导风连杆 Mounting plate assembly 11221500000029 挂板组件 Pipe clamp 11320084000014 管路压攀...

  • Page 158: Cassette

    AUX DC Inverter Free Match 50HZ 2. Cassette 09K,12K,18K...
  • Page 159 AUX DC Inverter Free Match 50HZ Chinese Name Part Name BOM Code panel 16108022000017 面板 Shaft bushing of damper 16420009000009 导风门轴套 air return grille 16420010000033 回风格栅 Motor Assembly 16320005000042 步进电机 Guide the wind vane 16420007000035 导风条 Filter net 16420012000012 过滤网...
  • Page 160 AUX DC Inverter Free Match 50HZ Outlet valve plate 16421014000089 阀板 chassis assembly 16321001000071 底盘组件 coaming C 16421010000073 围板 C Hangers 16421040000042 挂耳 围板 A Coaming A 16421010000071...

  • Page 161: Ceiling Floor

    AUX DC Inverter Free Match 50HZ 3. Ceiling Floor 09K,12K,18K 18 19...
  • Page 162 AUX DC Inverter Free Match 50HZ Chinese Name Part Name BOM Code air return grille 16420012000002 格栅 Filter net 16420010000002 滤网 Adornment board 16420015000002 左装饰板 electric control box 16421038000364 电器盒 Electric cover plate 16421005000205 电控盒盖 Terminal plate 16427001000087 端子板 Terminal plate 16427001000064 端子板...

  • Page 163: Duct

    AUX DC Inverter Free Match 50HZ Drain pipe 16432019000021 塑料排水软管 Motor fixing plate 16421002000190 电机固定板 Motor support 16421035000057 直流电机架 Motor 16430001000504 直流电机 Wind wheel 16444001000013 风轮 Upper spiral case 16444002000014 上蜗壳 Lower spiral case 16444002000015 下蜗壳 R 显示灯板 Display lamp board...
  • Page 164 AUX DC Inverter Free Match 50HZ...
  • Page 165 AUX DC Inverter Free Match 50HZ Chinese Name Part Name BOM Code Right plate 16421001000768 右侧板 底盘 A Chassis A 16421005000622 底盘 B Chassis B 16421005000619 Volute mounting plate 16421002000492 蜗壳固定板 Motor support 16430001000599 电机支架组件 Lower spiral case 16444002000023 下蜗壳...
  • Page 166 AUX DC Inverter Free Match 50HZ 4.2 18K...
  • Page 167 AUX DC Inverter Free Match 50HZ Chinese Name Part Name BOM Code Right plate 16421001000768 右侧板 底盘 A Chassis A 16421005000620 底盘 B Chassis B 16421005000623 Volute mounting plate 16421002000493 蜗壳固定板 Motor support 16430034000007 电机及支架组件 Lower spiral case 16444002000023 下蜗壳...

  • Page 168: Outdoor Unit

    AUX DC Inverter Free Match 50HZ 5. Outdoor Unit 5.1 14K， 18K...
  • Page 169 AUX DC Inverter Free Match 50HZ Chinese Name Part name Part code Qty/Per Front panel 11321005000107 前面板 Plastic grille 11320026000061 出风网罩 Fan blade 11320009000063 风叶 Left side panel 16421001000729 左侧板 Condenser asm 16324002000103 冷凝器 Motor bracket 11321002000040 电机支架 Electric board asm 11222550000016 电控总成...
  • Page 170 AUX DC Inverter Free Match 50HZ 5.2 21K， 27K...
  • Page 171 AUX DC Inverter Free Match 50HZ...
  • Page 172 AUX DC Inverter Free Match 50HZ Chinese Name Part name Part code Qty/Per Front panel 16421004000355 前面板 Plastic grille 11320026000052 出风网罩 Fan blade 11320009000064 风叶 Left side panel 16421001000736 左侧板 Condenser asm 16324002000102 冷凝器 Motor bracket 11321002000036 电机支架 Electric board asm 11222550000017 电控总成...
  • Page 173 AUX DC Inverter Free Match 50HZ 5.3 36K...
  • Page 174 AUX DC Inverter Free Match 50HZ Chinese Name Part name Part code Qty/Per Electric board asm 11222550000021 控制器总成 Electric Box 11320057000110 电控盒 Electric Box cover 11320058000088 电控盒盖 11222542000106 控制板 Radiator 11329031000064 散热器 Electrical cover 11320068000006 电器盖板 valve cover 16421014000090 阀板...
  • Page 175 AUX DC Inverter Free Match 50HZ 21.1 Low pressure switch 16442024000005 低压开关 Four way valve 16325020000032 四通阀组件 Exhaust pipe 16325017000028 排气管组件 23.1 Silencer 11325512000011 消音器 23.2 High pressure switch 16442024000006 高压开关 23.3 Oil separator 16442021000020 油分离器 Stop valve 16325033000002 截止阀...
  • Page 176 AUX DC Inverter Free Match 50HZ 5.4 42K...
  • Page 177 AUX DC Inverter Free Match 50HZ Chinese Name Part name Part code Qty/Per Electric board asm 11222550000021 控制器总成 Electric Box 11320057000110 电控盒 Electric Box cover 11320058000088 电控盒盖 11222542000106 控制板 Radiator 11329031000064 散热器 Electrical cover 11320068000006 电器盖板 valve cover 16421014000090 阀板...
  • Page 178 AUX DC Inverter Free Match 50HZ 21.1 Low pressure switch 16442024000005 低压开关 Four way valve 16325020000032 四通阀组件 Exhaust pipe 16325017000028 排气管组件 23.1 Silencer 11325512000011 消音器 23.2 High pressure switch 16442024000006 高压开关 23.3 Oil separator 16442021000020 油分离器 Stop valve 16325033000002 截止阀接管组件...

  • Page 179: Part11 Installation

    AUX DC Inverter Free Match 50HZ Part11 Installation 1. Preparation Please buy following spare parts from your local market before installation Hung bolts M12, 4 pcs Drainage pipe PVC Copper connecting pipe Adhesive belt (big size) 5 pcs, (small size) 5 pcs...

  • Page 180: Precaution

    AUX DC Inverter Free Match 50HZ 2. Precaution ◇ Hanging location should be able to support the unit’s weight, there should be no increase in noise and vibration. If the hanging location needs reinforcement, it should be reinforced before installation;...

  • Page 181: Wall Mounted

    AUX DC Inverter Free Match 50HZ 3. Wall Mounted 3.1 Spacing Reserved 3.2 Hoisting of Indoor Unit ◇ The wall for installing indoor unit should be firm to prevent vibration. Horizontally install hanging plate on the wall with four cruciform screws to keep laterally horizontal and longitudinally vertical.
  • Page 182 AUX DC Inverter Free Match 50HZ 3.4 Drainage Checking In case of maintenance, remove grille from casing of the unit according to the following procedures: ◇ As shown in right diagram, remove two screw caps on both sides of the front grille and then screw down two fixing screws.

  • Page 183: Cassette

    AUX DC Inverter Free Match 50HZ 4. Cassette 4.1 Installation drawing...
  • Page 184 AUX DC Inverter Free Match 50HZ 4.2 The distance between indoor unit and obstacle...
  • Page 185 AUX DC Inverter Free Match 50HZ 4.3 Indoor unit suspension ◇ Select the suspension foundation: The suspension foundation is a structure of either wooden frame or reinforced concrete. It must firm and reliable to bear at least 4 times weight of itself and capable of bearing vibration for long periods.
  • Page 186 AUX DC Inverter Free Match 50HZ ◇ Adjust the relative position of the suspension hook on the suspension bolt so that the unit can be in level position in all directions. Check with a level gauge after installation to ensure that the indoor unit is horizontal, otherwise it will cause water leakage, air leakage etc.
  • Page 187 AUX DC Inverter Free Match 50HZ ◇ Drainage pipe must have a downward gradient (1 / 50 1 / 100) to avoid water backflow or leakage etc. ◇ The unit has a drain pump which will lift up to 700 mm. However after the pump stops the water left in the pipe will drain back and may overflow the drain tray causing water leakage.
  • Page 188 AUX DC Inverter Free Match 50HZ ◇ When finish installation please carry out the drainage test to ensure that the water flow through the pipeline fluently, and carefully observe the junction to ensure that there is no water leakage. If the unit is installed in the newly built house, strongly recommend that this test taken before the ceiling installation.
  • Page 189 AUX DC Inverter Free Match 50HZ...

  • Page 190: Ceiling Floor

    AUX DC Inverter Free Match 50HZ 5. Ceiling Floor 5.1 Installation spacing 5.2 Indoor unit suspension ◇ Select the suspension foundation ◇ The suspension foundation is a structure of either wooden frame or reinforced concrete. It must be firm and reliable to bear at least 4 times weight of itself and capable of bearing vibration for long periods;...
  • Page 191 AUX DC Inverter Free Match 50HZ etc. ◇ Tighten the bolt and ensure that four hooks are in close contact with the nuts and washers, and the unit is suspended firmly and reliably onto the hooks. ◇ After the unit is installed ensure it is secure and does not shake or sway.
  • Page 192 AUX DC Inverter Free Match 50HZ ◇When finish installation please carry out the drainage test to ensure that the water flow through the pipeline fluently, and carefully observe the junction to ensure that there is no water leakage at the junction. If the unit is installed in the newly built house, strongly recommend that this test taken before the CFiling installation.

  • Page 193: Duct

    AUX DC Inverter Free Match 50HZ 6. Duct 6.1 Installation spacing Air Outlet Air Return Air Outlet Air Return A （mm） B（mm） C（mm） D （mm） E（mm） F（mm） G （mm） H （mm） I（mm） Model 1000 1048 110- 6.2 Indoor unit suspension Warning：...
  • Page 194 AUX DC Inverter Free Match 50HZ 6.3 Installation of duct There are two installation methods of duct ,as follow. 6.4 Drainage pipe  The drainage pipes should have good insulation measures. The specific steps are as follows: a) The drainage hoses should be tightly clambed with the inner water outlet and the drainage...
  • Page 195 AUX DC Inverter Free Match 50HZ The drain pipe must have a downward gradient(1/50-1/100).  If the drain pipe is installed ups and downs or upward,it will lead to water back flow or leakage etc.  During pipe connection, do not use too much force to the drain joint of indoor unit.
  • Page 196 AUX DC Inverter Free Match 50HZ...

  • Page 197: Outdoor Unit

    AUX DC Inverter Free Match 50HZ 7. Outdoor Unit 7.1 Installation location ◇The site shall be strong enough to bear its weight, prevent noise and vibration. ◇The site shall be ensured to avoid direct sunshine, if necessary set a Havelock above the outdoor unit.

  • Page 198: Connection Piping Installation

    AUX DC Inverter Free Match 50HZ Note: Require A＞300mm; B＞1500mm; C＞300mm; D＞500mm; 7.3 Installation Foundation ◇Use size M10 bolt and nut to fasten the outdoor unit tightly on the bracket, keep it in the horizontal level. The suitable length for bolt shall 20mm over the base level, in order to minimize vibration please do set a rubber shock absorber.
  • Page 199 AUX DC Inverter Free Match 50HZ Please welding before fasten the nut, when welding using nitrogen gas to replace the air in the pipe in order to prevent oxidation. ◇If there are many points to be welded ,please set a filter in the pipe(buy from local market) ◇Please use nitrogen gas or air to remove the dust and water in the pipe,...
  • Page 200 AUX DC Inverter Free Match 50HZ 8.2 Piping specification selection As to the detail selection please take reference to the cooling capacity adjust index figure during different installation situations. Expanding size Piping diameter Tighten torque Expanding shape Paint the frozen oil 1/4in(φ6.35mm)

  • Page 201: Emptying Or Vacuum

    AUX DC Inverter Free Match 50HZ Equivalent pipe length means converting pipe elbow to straight pipe length after considerate the pressure loss. Elbow and Oil loop conversion tablet Type Bend Oil Loop Pipe Dia.(mm) 6.35 0.10 9.52 0.18 12.70 0.20 15.88...
  • Page 202 AUX DC Inverter Free Match 50HZ absolute pressure is no less than 50Pa after this operation. 3. Turn off the pressure gauge and vacuum pump to keep the pressure in the same level in 20 minutes. ◇Emptying: When process this operation, please disconnect the high pressure valve with liquid valve.

  • Page 203: Insulation

    AUX DC Inverter Free Match 50HZ 10. Insulation ◇ Use heat insulation material with good insulation performance to wrap the pipe.
  • Page 204 AUX DC Inverter Free Match 50HZ Notes Drainage pipe and connection piping should be wrapped by heat insulation material respectively lift the air conditioner is proved my dew conditioner experiment. But if it keeps on working in high humidity (the dew temperature is more than23℃) environment which may lead to water leakage, please use following additional insulation material: ◇Glass fiber insulation material with the thickness between 10~20mm can be used.

  • Page 205: Additional Refrigerant Charge

    AUX DC Inverter Free Match 50HZ 11. Additional refrigerant charge When pipe length exceeds 7.5m, please add refrigerant according to the table below: Piping size) Connection Additional refrigerant piping charge amount (kg/m) Gas pipe Liquid pipe φ9.52×0.75mm φ6.35×0.75mm 0.02 φ12.7×1mm φ6.35×0.75mm...

  • Page 206: Electrical Connection

    AUX DC Inverter Free Match 50HZ 12. Electrical connection 12.1Electrical connection precaution Installation of electric items must be carried out by qualified, professional technicians. An isolated circuitry should be fixed with whole-pole disconnection devices, which is with at least 3mm gap of touch point Power supply and indoor to outdoor connection wire should use special cable.
  • Page 207 AUX DC Inverter Free Match 50HZ 12.2 Specification of wire Wiring Diagram of Indoor Unit and Outdoor Unit Power line must be properly fixed; Outdoor unit must be grounded; Each indoor unit must be grounded; Power wire must be thickened when it is overlong.
  • Page 208 AUX DC Inverter Free Match 50HZ Notice: Above mentioned power supply cord is the cables which connect air on-off of indoor to indoor/outdoor unit. Power supply cord of indoor/outdoor unit is the power supply cable connecting indoor and outdoor unit The section area of power supply cord core is minimized one.
  • Page 209 AUX DC Inverter Free Match 50HZ ◇ Switch the mode for “heating” and check whether there is warm air flow come from indoor unit, whether there is abnormal noise come from indoor/outdoor units ◇ After confirmation of normal working condition, press the “on-off” button to stop the system.

  • Page 210: Part12 Pcb Instruction

    AUX DC Inverter Free Match 50HZ Part12 PCB Instruction 1. Outdoor Unit PCB 1.1 14K,18K Main PCB and Driver modular...
  • Page 211 AUX DC Inverter Free Match 50HZ 1.2 21K,27K Main PCB and Driver modular...
  • Page 212 AUX DC Inverter Free Match 50HZ 1.3 36K,42K Main PCB...
  • Page 213 AUX DC Inverter Free Match 50HZ Drive Modular Board...

  • Page 214: Indoor Unit Pcb

    AUX DC Inverter Free Match 50HZ 2. Indoor Unit PCB 2.1 09K,12K,18K(Cassette)
  • Page 215 AUX DC Inverter Free Match 50HZ 2.2 09K,12K,18K(Ceilling&Floor)
  • Page 216 AUX DC Inverter Free Match 50HZ 2.3 07k,09K,12K,18K(Duct)

  • Page 217: Part13 Trouble Shooting

    AUX DC Inverter Free Match 50HZ Part13 Trouble Shooting 1. Failure code display ERROR ERRO CODE CODE DESCRIPTION (display (wired board) controller) Fault with the over-electric current protection Fault with the Compressor Power supply Phase deficiency protection Fault with the inverter module protection(IPM)
  • Page 218 AUX DC Inverter Free Match 50HZ Fault with the drainage Communication error between the wired controller and main PCB of the indoor unit fault with the low temperature discharge temperature sensor fault with the low pressure switch fault with the low pressure...

  • Page 219: Failure Analysis

    AUX DC Inverter Free Match 50HZ 2. Failure analysis 2.1【H2】Wired controller communication failure...
  • Page 220 AUX DC Inverter Free Match 50HZ...
  • Page 221 AUX DC Inverter Free Match 50HZ 2.2【E5】Communication failure between indoor and outdoor unit...
  • Page 222 AUX DC Inverter Free Match 50HZ Outdoor protection(phase sequence)
  • Page 223 AUX DC Inverter Free Match 50HZ 2.3【P2】high pressure protection Cooling high pressure protection...
  • Page 224 AUX DC Inverter Free Match 50HZ Heating high pressure protection...
  • Page 225 AUX DC Inverter Free Match 50HZ 2.4【H6】low pressure protection...
  • Page 226 AUX DC Inverter Free Match 50HZ Cooling low pressure protection...
  • Page 227 AUX DC Inverter Free Match 50HZ Heating low pressure protection...
  • Page 228 AUX DC Inverter Free Match 50HZ...
  • Page 229 AUX DC Inverter Free Match 50HZ 2.5【P5】High exhaust temperature protection Cooling exhaust temperature protection...
  • Page 230 AUX DC Inverter Free Match 50HZ Heating exhaust temperature protection...
  • Page 231 AUX DC Inverter Free Match 50HZ...
  • Page 232 AUX DC Inverter Free Match 50HZ 2.6【H8】four way valve failure protection...
  • Page 233 AUX DC Inverter Free Match 50HZ...
  • Page 234 AUX DC Inverter Free Match 50HZ 2.7 Sensor failure protection...
