Thank you for purchasing Physilog®5, the Swiss quality movement sensor. This manual introduces
how to use the different features of the sensor.
Table of Contents
1.
Physilog®5 elements .................................................................................................................................. 2
2.
Charging ..................................................................................................................................................... 2
3.
Recording with Physilog®5 ........................................................................................................................ 3
3.1.
Standalone measurement ..................................................................................................................... 3
3.2.
Standalone synchronous measurement with multiple Physilog®5 ....................................................... 3
3.3.
Start measurement from Android application ...................................................................................... 4
4.
Data Analysis ............................................................................................................................................. 6
5.
Practical Considerations ............................................................................................................................ 6
5.1.
Fixation .................................................................................................................................................. 6
5.2.
Handling / Maintenance ........................................................................................................................ 6
5.3.
How to update Date and Time of the Physilog®5 .................................................................................. 9
5.4.
How to update firmware of Physilog®5 with nRF Connect ................................................................... 9
5.5.
Sensor specifications ........................................................................................................................... 12
5.6.
Battery autonomy estimations ............................................................................................................ 13
5.7.
Troubleshoot ....................................................................................................................................... 13
6.
Limited Warranty & Support Policy ......................................................................................................... 15
7.
Certification claims .................................................................................................................................. 16
Contact information ........................................................................................................................................ 17
Physilog5 user manual v1.2.6 Date: 19.06.2018
Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland
User manual
EPFL Innovation Park, Bat C. CH-1015 Lausanne
TVA CHE-145.136.760
Gait Up SA
www.gaitup.com
1
Advertisement
Table of Contents
Related Manuals for Gait up Physilog 5
Summary of Contents for Gait up Physilog 5
-
Page 1: Table Of Contents
Battery autonomy estimations ......................13 5.7. Troubleshoot ............................13 Limited Warranty & Support Policy ......................15 Certification claims ..........................16 Contact information ............................17 Physilog5 user manual v1.2.6 Date: 19.06.2018 Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland... -
Page 2: Physilog®5 Elements
Physilog5 user manual v1.2.6 Date: 19.06.2018 Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland... -
Page 3: Recording With Physilog®5
To stop the measurement, push the main button of the sensors until the LED turns orange, you can turn off the sensors in any order. Physilog5 user manual v1.2.6 Date: 19.06.2018 Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland... -
Page 4: Start Measurement From Android Application
5.7 Troubleshoot. Physilog5 user manual v1.2.6 Date: 19.06.2018 Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland... - Page 5 Note: Bluetooth 4.0 or higher is required on the mobile device to be able to communicate with Physilog®5. Physilog5 user manual v1.2.6 Date: 19.06.2018 Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland...
-
Page 6: Data Analysis
Practical Considerations 5.1. Fixation The Physilog®5 comes with a fixation clip as default attachment accessory. Additional clips and elastic straps with Velcro patches to stick onto the Physilog® can be purchased from Gait Up's online shop (shop.gaitup.com). 5.2. Handling / Maintenance Physilog®5 should be handled carefully. - Page 7 Sensors do not need yearly recalibration. Do not throw Physilog® sensors in the normal trash, dispose of it properly considering local laws and rules about electronic waste and batteries. Contact Gait Up's customer support for more information about elimination of Physilog®. ...
- Page 8 Physilog®5 doit être chargé par une connexion USB avec un ordinateur. Un chargeur externe peut être utilisé; mais Gait Up ne livre et ne recommande pas de chargeur. Gait Up refuse toute responsabilité liée à l’utilisation d’un chargeur externe.
-
Page 9: How To Update Date And Time Of The Physilog®5
Select connect of one Physilog®5 sensor in the list Plug the selected Physilog to a power source to be sure to have enough battery to perform the update Physilog5 user manual v1.2.6 Date: 19.06.2018 Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland... - Page 10 LED shines orange, blinks red and then stops) Plug the Physilog® to the computer and update the date and time (see above) Physilog5 user manual v1.2.6 Date: 19.06.2018 Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland...
- Page 11 LED shines orange, blinks red and then stops) Plug the Physilog® to the computer and update the date and time (see above) Physilog5 user manual v1.2.6 Date: 19.06.2018 Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland...
-
Page 12: Sensor Specifications
The Matlab function to read the .BIN file has the option to output the quaternions and Euler angles. Physilog5 user manual v1.2.6 Date: 19.06.2018 Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland... -
Page 13: Battery Autonomy Estimations
USB entry and gently press until you feel a button pressed inside the sensor. Warning: This manipulation destroys the waterproofing membrane and the sensor is therefore no Physilog5 user manual v1.2.6 Date: 19.06.2018 Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland... - Page 14 Charge the Physilog® Error 4 Contact Gait Up Error 5 Contact Gait Up Error 6 Empty the memory card *see LED indication above Physilog5 user manual v1.2.6 Date: 19.06.2018 Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland...
-
Page 15: Limited Warranty & Support Policy
Physilog®. The warranty shall not apply to any product or component thereof which has been repaired or altered by anyone other than Gait Up in any manner so as, in Gait Up’s judgement, to affect its service ability, or any product been subject to alteration, accident, misuse, abuse, neglect or abnormal wear. -
Page 16: Certification Claims
Caution: the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Physilog5 user manual v1.2.6 Date: 19.06.2018 Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland... -
Page 17: Contact Information
- LED error indication not repeated 3 times 1.2.6 - Charging voltage specifications updated from 4.2 to Rebekka Anker 19.06.2018 - Hard reset instructions Physilog5 user manual v1.2.6 Date: 19.06.2018 Copyright © 2018, All Rights Reserved - Gait Up SA. CH-1015 Switzerland...
