- Page 1 U-MIC Item ref: 171.812UK USB Dual Neckband UHF Wireless System User Manual Version 1.0 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
- Page 2 USB type A socket Setting up The U-MIC is supplied as 2 individual beltpack microphone transmitters and a USB receiver with a 3.5mm to 6.3mm jack lead. The USB type A plug (6) on the receiver should be connected to a USB port for power (5V, 1000mA).
- Page 3 Operation The U-MIC receiver is designed to connect to a microphone input jack on a mixer or amplifier. Turn down the volume level on the microphone input of the mixer or amplifier before connecting to avoid loud noises when connecting.
- Page 4 Specifications Carrier frequency 863.2MHz + 864.8MHz RF power 10mW Power supply: transmitter 2 x AA batteries (each) Power supply: receiver 5Vdc 1000mA (USB) Frequency response 50Hz - 15kHz Capsule Back electret condenser Output connection 3.5mm mono jack Wireless range Up to 50m Dimensions: transmitter 105 x 65 x 30mm each Weight: transmitter...
