- Page 1 U-MIC Item ref: 171.808UK USB Powered UHF Neckband Microphone 171.809UK User Manual Version 1.0 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
- Page 2 USB type A socket Setting up The U-MIC is supplied as a neckband microphone, beltpack transmitter and USB receiver with a 3.5mm to 6.3mm jack lead. The USB type A plug (6) on the receiver should be connected to a USB port for power (5V, 500mA).
- Page 3 Turn down the volume level on the microphone input of the mixer or amplifier before connecting to avoid loud noises when connecting. Connect the 3.5mm plug end of the supplied lead to the U-MIC receiver (7) and the 6.3mm plug into an appropriate microphone input channel.
- Page 4 Specifications Model U-MIC-863.2-N U-MIC-864.8-N Carrier frequency 863.2MHz 864.8MHz Power supply USB 5V 0.5A (receiver), 2 AA batteries (transmitter) Frequency response 50Hz - 15kHz Capsule Back electret condenser Output connection 3.5mm mono jack Wireless range Up to 50m Dimensions: transmitter 105 x 65 x 30mm...
