GETTING TO KNOW YOUR SNOWPLOW
A-FRAME/T-FRAME, QUADRANT,
AND HEADGEAR
SPEEDWING™, POWER PLOW™, and
Straight Blade Snowplows
The quadrant is attached to the back of the blade
with heavy-duty trip springs and clevis pins with
cotters. The trip springs allow the blade to trip
forward and ride over obstacles such as low
curbs, manhole covers, etc., without damaging the
blade or the vehicle or injuring the driver. For trip
spring adjustment instructions, see "Maintenance
and Adjustment" in the Maintenance section of
this manual.
The quadrant is attached to the triangular A-frame
with a pivot bolt. The pivot bolt allows the quadrant
and blade to swing right or left.
Lit. No. 72448, Rev. 02
The hydraulic unit is easy to access and the cover
can be removed without tools. It is conveniently
located in front of the lift ram.
The snowplow headlamps are also attached to the
headgear.
HDV™ and RDV™ Snowplows
The blade wings are attached to the T-frame with
a hinge pin, which allows the wings to extend and
retract.
The hydraulic unit is mounted on the front of the
headgear. The hoses remain connected to the
hydraulic unit and the rams.
The snowplow headlamps are also attached to the
headgear.
