TPH 175
Remove vehicles existing ball hitch from the mounting bracket
Place TPH bracket onto the vehicle mounting bracket and place the ball hitch over the bolts and fasten
Self locking nuts (ensure that the bolts are long enough they should be at least 2 threads slowing
through the nuts when tight).
The Snowex spreader can now be mounted onto the TH-175 by inserting the 2" receiver tube of the
spreader, the 2" female receiver tube of the TH-175 one located a locking pin (supplied with the spreader)
can be inserted into the holes on the side of the hitch. To ensure all free play is removed tighten the pinch
bolt on the hitch(19mm spanner or socket required)
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SnowEx TPH 175
Summary of Contents for SnowEx TPH 175
- Page 1 The Snowex spreader can now be mounted onto the TH-175 by inserting the 2” receiver tube of the spreader, the 2” female receiver tube of the TH-175 one located a locking pin (supplied with the spreader) can be inserted into the holes on the side of the hitch.
- Page 2 Snowex TBH-175 Towbar Hitch The TBH-175 is designed for use with the following Snowex models only SP-375 SP-100 SP-325 US-100 US-200 SP-575 SP-1575 The TBH-175 can be fitted to any vehicle fitted with a 2 pin back plate towing bracket with sufficient weight capacity.
-
Page 3: Parts List
TLR - 275 PARTS LIST TLR275/01 Axle bracket TLR275/02 Drawbar mounting bracket TLR275/03 Drawbar TLR275/04 Ball hitch swivel TLR/05 Ball hitch TLR275/06 Wheel TLR275/07 Pin and clip TLR275/08 Pin, Washer, Hub cap Assembly Bolt item 2 to item 1 using 2 OH 12x35 bolts and nuts Insert item 3 into item 2 and secure using pin and R clip. - Page 4 Removal from the towing vehicle may result in damage and/or personnel injury. Always thoroughly wash Snowex equipment after contact with corrosive substances. When towing the TLR-275 care must be taken when turning sharply, especially on wet or icy surfaces or on snow.
- Page 5 DSM 175 PART NO’s DSM175/01 Top Hangers DSM175/02 Main frame DSM175/03 Bottom frame DSM175 Pair of Racthet straps Insert items 1 into item 2 through top sockets leave clamp bolts loose. Insert 2 m6x50 safety bolts into item 1 and tighten. Insert item 3 into bottom socket leave clamp bolt loose.
- Page 6 Snowex DSM-175 Drop Side Mount The DSM-175 is resigned for use with the Snowex SP-1875 only. The hitch is multi adjustable and designed for the use with drop sided commercial vehicles fitted with a 50mm towing ball. The DSM-175 should not be used with ‘Flare side’...
- Page 7 FSM-175...
- Page 8 Snowex FSM-175 Fork Sleeve Mount The FSM-175 is designed for use with the Snowex SP1875 spreader only. The FSM-175 can be used with any forklift with 120x50mm tines and sufficient lift capacity to handle the FSM- 175 weight of 389kgs. Maximum weight should not be exceeded.
- Page 9 SAFETY LABELS ATTENTION: Description Do not use without PTO Never remove guards or of pictograms. shaft guard. attempt adjustment until rotor has stopped. Read operating manual Ear defenders must be Bystanders must be at before use. worn. least 20 metres from machine range of action.
- Page 10 Protective eyewear, ATTENTION: Description Read operating manual footwear, gloves and ear of pictograms. before use. protectors must be worn.
