Alan alan441 Quick Start Manual

Alan alan441 Quick Start Manual

8 channels pmr446 transceiver

Advertisement

Quick Links

T h e
W o r l d
i n
C o m m u n i c a t i o n
8 CHANNELS
PMR446 TRANSCEIVER
Congratulations on your purchase!
ALAN 441 is a new generation PMR
446 transceiver which may be used,
without license, in all the countries in
which Pan-European PMR446 fre-
quencies are authorised (446.00625 –
446.09375 MHz). Please consult the
"Restrictions on the use" charts for
information regarding country specif-
ic limitations.
Main features:
• Freq. 446.00625 ÷ 446.09375 • Channel spacing: 12.5 KHz • 8 channels • Power 500 mW ERP • Coverage up
to 4÷5 km • VOX adjustable in 3 levels • Batteries: AAA type, rechargeable or alkaline • Alphanumeric backlit LCD
Display • Battery life up to 35 hours (alkaline type) • Operating temperature –20° +55° • Weight 78 gr • Size
54x87x34 mm • Jack MIC CHG [13]: 2 pins for audio accessories and wall charger
Specifications are subject to change without notice.
To open the battery compartment, hold the unit face down and unhook the battery holder in the lower part
of the radio; gently slide the cover towards the bottom of the radio. ALAN 441 accepts 3 x AAA alkaline or
rechargeable batteries.
Display lighting: When you press
®
2
11
10
BSCAN DW VOX SAVE
3
CHANNEL
CALL
9
CALL
8
[7], the display lights up for 10 seconds approx.
Content
• 2 ALAN 441 transceivers
• 1 user instructions
1
4
5
®
12
13
BEEP
6
7
F
ENTER
VOX
14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the alan441 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alan alan441

  • Page 1 To open the battery compartment, hold the unit face down and unhook the battery holder in the lower part of the radio; gently slide the cover towards the bottom of the radio. ALAN 441 accepts 3 x AAA alkaline or rechargeable batteries.
  • Page 2 In your ALAN 441 the background noise reduction device (squelch) is activated by default. Hold MON [10] button down to deactivate it. In this way, even low level signals can be received. 7 Automatic power save ALAN 441 is supplied with an automatic current economy circuit. If the transceiver receives no signal for 7 se-...
  • Page 3 10 Hands-free transmission mode (VOX) / Baby-sitter ALAN 441 has built-in VOX capability (automatic transmission) settable in 3 positions. This feature is particularly useful to keep a check of the baby at a distance as you can automatically listen to all sounds or noises close to the transmitter (Baby-sitter).
  • Page 4 it may cause transmission to stop between some words) and allows you to speak at a steady rate with no loss of transmission. To enable this feature, press once the [8] button. On the display: Use again the [6] keys to select the desired delay: •...
  • Page 5 [9] keys. 19 Reset In case your ALAN 441 does not work properly or you want to cancel all the user settings, it is necessary to hold [8] button down for 2 seconds while switching the unit on. With this procedure, all the settings made by the constructor are restored.
  • Page 6 CHART “A” DERIVED FROM ERC/DEC (98) 25-26-27 RESTRICTIONS TO THE USE COUNTRY PMR446 Restrictions from ERC Decisions and introduced other comments AUSTRIA Hobby use excluded BELGIUM Individual licence is required DENMARK Free Use FINLAND Free Use FRANCE Not allowed use ch 1 (446.00625 MHz) and ch 2 (446.01875 MHz) GERMANY Free Use...
