Settings > Input
For each individual input you make various settings separately. To do this, just turn on
the source player at the input you want to configure and start playback – for example
the TV (HDMI ARC) shown here.
In the area of DOWNMIX you can
determine on which speakers the
playback should take place, if this
input is active. The first number
means the number of front speakers.
The number after the slash indicates
the number of rear speakers. So you
can, for example, when watching TV,
play the sound in full surround sound
(HDMI: 3/2) and in contrast, let your
audio device run in stereo only via the
two front speakers (DIN: 2/0).
For the sound settings, you can raise
or lower the level of treble and bass by
up to 12 dB each. And you also have
the option to enable or disable
loudness.
Use this slider to set the channel-
specific volume
connected to the active input - level
(gain) respectively start volume.
Delay / Lipsync. Select a TV channel
with a news program or a talk show
and move the slider until the picture
and the sound of the lips are in sync.
This function is only available with the
HDMI or SPDIF 2 inputs.
Although some TVs have an HDMI-
CEC connection,
additional parallel cabling with an
optical cable (Toslink). In this case,
connect it to the OPTICAL input and
enable this function to pair the HDMI
ARC and OPTICAL inputs.
for the device
they require
