ITEM PRODUCT CODE DESCRIPTION
86 BRACKET
87 SOCKET CAP SCREW (M5x16xP0.8)
88 PRIMING VALVE
89A PUMP FILTER (30MESH)
89B PUMP FILTER (60MESH)
89C PUMP FILTER (100MESH)
90 FILTER CAP
91 HIGH PRESSURE HOSE (3/8"-19PF)
92 FILTER HOUSING
93 HANDLE
94 ROLL PIN (Ø5x30)
95 HANDLE MOUNT
96 FLAT WASHER (Ø22.5xØ30x2)
97 FRAME
98 END CAP
99 FLAT WASHER
100 WHEEL
101 M5x20
102 HEX BOLT (M6x16xP1.0)
103 SOCKET CAP SCREW (M5x20xP0.8)
104 PANHEAD TAPPING SCREW-B (M5x16)
105 CONTROL DIAL
106 CONTROL BOX COVER
107 RHEOSTAT
108 SWITCH
109 ELECTRONICS UNIT
110 WINDOW (76x42x2)
111 LCD DISPLAY
112 PANHEAD TAPPING SCREW (M4x8)
113 SOCKET CAP SCREW (M8x16xP1.25)
114 HEX BOLT (M8x35xP1.25
115 NYLOCK NUT (M8xP1.25)
116 PUSH BUTTON SWITCH
117 CABLE GLAND (SB5F-3)
118 CABLE GLAND (SB5M-1)
119 GROMMET
120 SOCKET CAP SCREW (M4x6xP0.7)
121 SOCKET CAP SCREW (M5x12xP0.8)
122 MOUNTING BRACKET
123 TOOL BOX
QTechSpray.com
QTY ITEM PRODUCT CODE DESCRIPTION
1 124
4 125
1 126
1 127
1 128
1 129
1 130
1 131
1 132
1 133
2 134
2 135
2 136
1 137
2 138
4 139
2
2
2
4
2
1
1
1
1
1
1
1
4
2
2
2
1
2
1
1
4
6
2
1
TOOL BOX LID
HINGE PIN (Ø3x230)
TOOL BOX LOCK
HIGH PRESSURE HOSE
LUBRICATING OIL TANK
DUAL PURPOSE WRENCH
PACKING NUT TOMMY BAR
DRAIN TUBE
SUCTION HOSE SET
BOLT (PT 3/8")
EARTH WIRE
CONNECTION CABLE
INLET STRAINER (8MESH)
SWITCH WIRES
NYLOCK NUT (M5xP0.8)
SOCKET SET SCREW (M4x8xP0.7
