SPECIFICATIONS

Minimum RMS Output Power per Channel
< >
AX-590
8 ohms, 20 Hz to 20 kHz, 0.015% THD
...............................................100W+100W
6 ohms, 20 Hz to 20 kHz, 0.03% THD
...............................................120W+120W
< >
AX-490
8 ohms, 20 Hz to 20 kHz, 0.019% THD
...................................................85W+85W
6 ohms, 20 Hz to 20 kHz, 0.038% THD
...............................................100W+100W
Dynamic Power per Channel
(by IHF Dynamic Headroom measuring
method)
< >
AX-590
8/6/4/2 ohms.................140/170/220/290W
< >
AX-490
8/6/4/2 ohms.................130/150/185/220W
DIN Standard Output Power per Channel
(4 ohms, 1 kHz, 0.7% THD)
[Europe model only]
< >
AX-590 .........................................150W
< >
AX-490 .........................................120W
IEC Power [Europe model only]
< >
AX-590
(8 ohms, 1 kHz, 0.015% THD) ..........110W
< >
AX-490
(8 ohms, 1 kHz, 0.019% THD) ..........100W
Power Band Width
< >
AX-590
8 ohms, 50W, 0.03% THD
..........................................10 Hz to 50 kHz
< >
AX-490
8 ohms, 42.5W, 0.038% THD
..........................................10 Hz to 50 kHz
Damping Factor
8 ohms, 20 Hz–20 kHz
< >
AX-590 ...........................more than 320
< >
AX-490 ...........................more than 240
Damping Factor (DIN)
4 ohms, 40 Hz
[Australia, U.K. and Europe models]
< >
AX-590 ...........................more than 160
< >
AX-490 ...........................more than 120
Maximum Power (EIAJ)
1 kHz, 10% THD
[General model only]
< >
AX-590
8 ohms .................................................145W
6 ohms .................................................170W
< >
AX-490
8 ohms .................................................130W
6 ohms .................................................150W
Input Sensitivity/Impedance
PHONO MM .....................2.5 mV/47 k-ohms
<
PHONO MC AX-590 only
..........................................160 µV/220 ohms
CD/TUNER/TAPE/AUX ....150 mV/47 k-ohms
< >
MAIN IN AX-590 only
14
Maximum Input Signal (1 kHz, 0.007% THD)
<
AX-590
PHONO MM ...................................150 mV
PHONO MC......................................10 mV
Maximum Input Signal (1 kHz, 0.003% THD)
<
AX-490
PHONO MM ...................................115 mV
Output Level/Impedance
<
AX-590
REC OUT ......................150 mV/470 ohms
PRE OUT.............................1.0V/1 k-ohms
<
AX-490
REC OUT ......................150 mV/470 ohms
Headphone Jack Rated Output/ Impedance
<
AX-590
Output Level (8 ohms, 0.015% THD)
..........................................................0.33V
Impedance ..................................680 ohms
<
AX-490
Output Level (8 ohms, 0.019% THD)
............................................................0.3V
Impedance ..................................680 ohms
Frequency Response (20 Hz to 20 kHz)
CD/TUNER/TAPE/AUX ....................0±0.5 dB
MAIN IN
RIAA Equalization Deviation (20 Hz to 20 kHz)
PHONO MM......................................±0.3 dB
PHONO MC
Total Harmonic Distortion (20 Hz to 20 kHz)
<
AX-590
PHONO MM to REC OUT (3V) ......0.003%
PHONO MC to REC OUT (3V).......0.007%
CD/TUNER/TAPE/AUX to PRE OUT (1V)
........................................................0.005%
CD/TUNER/TAPE/AUX to SP OUT
(50W/8 ohms) .................................0.008%
<
AX-490
PHONO MM to REC OUT (3V) ......0.003%
CD/TUNER/TAPE/AUX to SP OUT
(42.5W/8 ohms) ..............................0.008%
Intermodulation Distortion
(Rated output/8 ohms) ........................0.01%
Signal-to-Noise Ratio (IHF-A Network)
<
AX-590
PHONO MM (5 mV Input Shorted)
......................................................... 92 dB
PHONO MC (500 V Input Shorted)
......................................................... 76 dB
CD/TUNER/TAPE/AUX (Input Shorted)
(CD DIRECT AMP; ON) ................. 110 dB
<
AX-490
PHONO MM (5 mV Input Shorted)
......................................................... 88 dB
CD/TUNER/TAPE/AUX (Input Shorted)
(CD DIRECT AMP; ON) ................. 110 dB
>
Residual Noise (IHF-A Network)
(CD DIRECT AMP; ON).......................35 V
......1.0V/10 k-ohms (PURE DIRECT; ON)...........................90 V
>
>
>
>
>
>
< >
AX-590 only .................0±0.5 dB
< >
AX-590 only ............±0.5 dB
>
>
>
>
Channel Separation (Vol. –30 dB)
< >
AX-590
PHONO MM/MC (Input Shorted
1 kHz/10 kHz) .........................75 dB/60 dB
CD/TUNER/TAPE/AUX (Input 5.1 k-ohms
Terminated 1 kHz/10 kHz) ......65 dB/50 dB
< >
AX-490
CD/TUNER/TAPE/AUX (Input 5.1 k-ohms
Terminated 1 kHz/10 kHz) ......65 dB/50 dB
Tone Control Characteristics
BASS: Boost/cut ................±10 dB (20 Hz)
Turnover Frequency.........(350 Hz)
TREBLE: Boost/cut...........±10 dB (20 kHz)
Turnover Frequency.....(3.5 kHz)
<
Filter Characteristics AX-590 only
SUBSONIC FILTER .........15 Hz, –18 dB/oct
Continuous Loudness Control
Attenuation ............................–30 dB (1 kHz)
(Level related equalization)
Gain Tracking Error (0 to –60 dB) ............2 dB
Power Supply
[U.S.A. and Canada models]
..........................................AC 120V, 60 Hz
[Australia and U.K. models]
..........................................AC 240V, 50 Hz
[Europe model]..................AC 230V, 50 Hz
[General model]
................AC 110/120/220/240V, 50/60 Hz
Power Consumption
< >
AX-590
[U.K., Europe, Australia and General
models]..............................................210W
< >
AX-490
[U.S.A. model] ...................................190W
[Canada model] ...................320 VA, 250W
[U.K., Europe, Australia and General
models]..............................................210W
AC Outlets
[U.S.A., Canada, Europe and General
models]
3 SWITCHED OUTLETS
..........................................100W max. total
[U.K. and Australia models]
1 SWITCHED OUTLET ....100W max. total
Dimensions (W x H x D)
< >
AX-590 .................435 x 146 x 388.5 mm
(17-1/8" x 5-3/4" x 15-5/16")
< >
AX-490 ....................435 x 146 x 386 mm
(17-1/8" x 5-3/4" x 15-3/16")
Weight
< >
AX-590 ................10.4 kg (22 lbs. 14 oz.)
< >
AX-490 ....................9.2 kg (20 lbs. 4 oz.)
Accessories ...........Remote control transmitter
Specifications subject to change without
notice.
>
