Weller WSF 80 Instructions

Thermo-regulated soldering iron gun with manual solder wire feed.
Choose a tube guide wire 1 or 1.5 mm suitable for w
1.5 mm).
Insert the end of the wire, perfectly straight, into t
ti p, (check the correct insertion through the windo
Adjust the pre-load on the external spring acting on the knob, it is recommended to exercise the minimum
pressure to avoid the deformation of the wire.
If the wire blocks, holding down the lever and pull it out, after cutting the deformed part, proceed to a new post.
Connect the tool to the mains (230V ~) the indicator begins to flash.
TIN THE TIP AS SOON AS THE MELTING TEMPERATURE IS REACHED
Pushing the trigger, the wire advances toward the tip, for a length adjustable from 1 to 6 mm. To adjust the amount
o f wire needed, act on the grain, in front of the trigger; for adjusting th
grain beneath the thread guide
.
Model
WSF 80 80W-230V~ SF25
T0051 384899
READ THE FO LLOWING IMP
Before connecting the appli
This appliance must only be used for the purpose it was designed.
Do not touch the appliance with wet hands and / or feet are wet.
Do not pull the cord or the appliance itself to remove the plug from the socket.
Before performing any maintenance, disconnect the appliance from the mains and allow to cool.
Do not use non-standard extensions (IMQ-VDE-NF-ETC..)
This tool can be placed on a holder when not in use

WARRANTY

Weller warrants this product against defects in workmanship for one year from date of purchase documented, in
case of absence of such documentation will be considered the date of manufacture.
The warranty excludes all parts subject to wear.
The warranty is void in case of tampering or improper use of the device.
Transport costs are paid by the customer.
WSF 80
INSTRUCTIONS
he rear hole of th
Longlife c urve Tips
SF10(Ø1.0) T0051384999
SF15(1.6) T0051385099
SF25(2.5) T0051385199
SF40(4.0) T00513 85299
ORTANT INFORMATIO
ance make sure that the

Technical data:

Voltage supply: 230 V 50 and 60 Hz
Max power: 80W
Power regulation: PWM from 0 to 100%
Max temperature: 550°C @ 100%
Cable: 3 x 0.75 H03 Schuko male connector
Weight: 320 gr.
Consist of:
•
WSF 80
•
6 gr. Lead-free wire SACX0307 1mm coil
•
WB 10 1mm and WB 15 1.5mm wire-guide pipe
•
Empty spare coil
•
2mm EX key
•
SF25 2,5 sqmm
ire diameter (use lead-free or
e gun holding down the lever until the soldering
w).
e orientation of the wire to the tip, act on the
Tubetti guidafilo
TB/70/10 Ø 1.0 T0051385399
TB/70/15 Ø 1.5 T0051385499
N REGARDING THE SAFETY USE OF THE DEVICE
nameplate data corresponds with the mains.
SnPb alloys give 1mm min, max
Max Temperature
100% = 550°C
