M-system M8BS2-042 Instruction Manual page 2

TERMINAL CONNECTIONS
Connect the unit as in the diagrams below.
■ EXTERNAL DIMENSIONS unit: mm (inch)
• M8BS2-042-M2
• M8BS2-042-R
5–M3.5 POWER
TERMINALS
7.3(.29)
V.ADJ
1
2
3
4
5
AC POWER UNIT
3–M3.5 POWER
TERMINALS
7.3(.29)
8.6 (.34)
1 2 3
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
250 (9.84)
230 (9.06)
210 (8.27)
16–M3.5
OUTPUT TERMINALS
CH1 CH4
+ – + – + – + –
+ – + – + – + –
1 2 3 4
250 (9.84)
230 (9.06)
210 (8.27)
16–M3.5
OUTPUT TERMINALS
CH1 CH4
+ – + – + – + –
+ – + – + – + –
1 2 3 4
M8BS2-042
OUTPUT 2 TERM.
OUTPUT 1 TERM.
OUTPUT 2 TERM.
POWER LED
OUTPUT 1 TERM.
EM-5478-2 Rev.4 P. 2 / 3
