Amana MBVC Series Manual
Multi-position, variable-speed ecm-based, modular blower comfortbridge compatible
Hide thumbs
Also See for MBVC Series:
- Installation instructions manual (24 pages) ,
- Wiring diagram (8 pages)
Advertisement
Product Features
• Variable-speed ECM blower motor
• Integrated communicating ComfortBridge
• Commissioning and diagnostics via on board Bluetooth
with the CoolCloud phone and tablet application
• Advanced configuration of the airflow
and tonnage in communicating mode
• Provides constant CFM over a wide range of static
pressure conditions independent of duct system
• CFM indicator
• Fault recall of six most recent faults
• Provides adjustable low CFM for
efficient fan-only operation
• Improved humidity and comfort control
• Built-in compatibility with multi-stage
heat pump and cooling applications
• Blower section usable as electric heater
• AHRI certified; ETL listed
SS-AMBVC
Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P., Houston, Texas.
Multi-Position, Variable-Speed
ECM-Based, Modular Blower
• Horizontal or vertical configuration capabilities
Technology
™
• 21" depth for easier attic access
• Foil-faced insulation covers the internal
casing to reduce cabinet condensation
• Galvanized, leather grain-embossed finish
• Cabinet air leakage less than 2% at 1.0 inch
H₂0 when tested in accordance with
ASHRE standard 193
• Cabinet air leakage less than 1.4% at 0.5 inch
H₂0 when tested in accordance with
ASHRE standard 193
• Field Installed 3 kW - 25 kW electric heater
kits available
* Complete warranty details available from your local dealer or at www.amana-hac.com. To receive the
10-Year Parts Limited Warranty, online registration must be completed within 60 days of installation. Online
registration is not required in California or Québec.
www.amana-hac.com
ComfortBridge™ Compatible
Contents
Air Handler Nomenclature .................... 2
Heater Kit Nomenclature ...................... 2
Product Specifications ........................... 3
Airflow Data ........................................... 3
Heat Kit Data .......................................... 4
Dimensions ............................................ 5
Wiring Diagram ...................................... 6
MBVC
3/20
Supersedes 7/17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amana MBVC Series
Summary of Contents for Amana MBVC Series
-
Page 1: Table Of Contents
10-Year Parts Limited Warranty, online registration must be completed within 60 days of installation. Online registration is not required in California or Québec. SS-AMBVC www.amana-hac.com 3/20 Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P., Houston, Texas. Supersedes 7/17... - Page 2 None Single-‐Phase Single-‐Phase Kit w/ Three-‐Phase Circuit Breaker Heating C apacity @ 2 40 V olts 4.75 kW 15 14.25 to 15.00 kW 7.00 kW 20 19.00 to 19.60 kW 10 9.50 kW www.amana-hac.com SS-AMBVC...
-
Page 3: Air Handler Nomenclature
• Condensate management kits are available for units installed in high temperature and high humidity areas. Kit number MBK0002 has beendeveloped to resolve condensate issues in the field for MBVCs and is available from the Service Parts Department. Refer to IO-849 for installation instructions. SS-AMBVC www.amana-hac.com... -
Page 4: Airflow Data
The chart is for information only. For satisfactory operation, external static pressure must not exceed value shown on rating plate. • Use the CFM adjustment factors of .98 for horizontal left, .95 for horizontal right & .96 for downflow orientations. www.amana-hac.com SS-AMBVC... -
Page 5: Heat Kit Data
Maximum Overcurrent Protection = 2.25 X Motor Amps + Heater Amps • MBVC and MBR models * Revision level that may or may not be designated Heating kW Correction Factor Supply Voltage Correction Factor 1.00 0.92 0.84 0.77 0.75 Multiply the 240-volt heating capacity by correction factors. SS-AMBVC www.amana-hac.com... -
Page 6: Dimensions
Dimensions Side and Front Views Dimensions Model Width Depth Height MBVC1201AA-1 17½" 21" 26" MBVC1601AA-1 21" 21" 30" MBVC2001AA-1 24½" 21" 30" Top View 24½" 17½" 21" www.amana-hac.com SS-AMBVC... -
Page 7: Wiring Diagram
High Voltage: Disconnect all power before servicing or installing this unit. Multiple power Warning sources may be present. Failure to do so may cause property damage, personal injury, or death. Wiring is subject to change. Always refer to the wiring diagram on the unit for the most up-to-date wiring. SS-AMBVC www.amana-hac.com... - Page 8 Wiring is subject to change. Always refer to the wiring diagram on the unit for the most up-to-date wiring. Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P. All rights reserved. Our continuing commitment to quality products may mean a change in specifications without notice.
