- Page 1 Katadyn Rapidyn Filter Kit Quick Starter Guide Components A: Ceramic Filter Element Katadyn Rapidyn B: Mouth Piece Seal C: Filter Nut D: Outlet Tap E: Tap Nut F: Tap Seal (2pcs) Quick Starter Guide Page 1/11...
- Page 2 Components (continued) G: End of Life Indicator H: Abrasive Cleaning Paper I: Resealable Bag K: Step Drill (drill bit) Only a drill is needed no extra tools. (Drill is not included) Buckets are not included. Quick Starter Guide Page 2/11...
- Page 3 Assembling the Filter Kit Check if mouth piece seal (B) is mounted to the filter outlet (A). Use the included drill bit to make a hole in your upper bucket and into the lid of the lower container. Make sure that the hole is placed in the middle. 1.
- Page 4 Assembling the Filter Kit (continued) Use the included drill bit to make a hole in the lower bucket for the outlet tap. Make sure that the hole is placed in the middle. 4. Place the included template with the blue line level to the bucket bottom and positioned in the middle.
- Page 5 Assembling the Filter Kit (continued) Place the entire system on a stable higher surface (such as a table) to allow high flow rate. Fill water in the upper bucket and wait. It takes approx. 1 hour to get 3-4 liters. Wait until the lower bucket is filled.
-
Page 6: Maintenance
Maintenance If the flow rate decreases and/or the filter becomes dirty the filter cartridge needs to be cleaned with the included abrasive cleaning paper (H). Unscrew the filter nut (C) and remove the filter element. Wrap the abrasive cleaning paper around the filter element and clean the surface by scrubbing gently up and down. - Page 7 Maintenance (continued) After cleaning the mount, install the filter according to step number three in the “Install new Filter Element” manual on page 8. Quick Starter Guide Page 7/11...
- Page 8 Install new Filter Element Unscrew the filter nut and remove the filter element. Check if mouth piece seal (B) is mounted to the filter outlet (A). Push the filter outlet through the bottom of the upper bucket and the lid of the lower container. Fix the filter by screwing on the filter nut (C).
- Page 9 After that your Water Filter System is ready for use. Enjoy. DRINKING FIRST 10 L Contact: Katadyn Products Inc. Katadyn North America Inc. Pfäffikerstrasse 37 4830 Azelia Ave North #300 8310 Kemptthal Minneapolis, MN 55429 Switzerland +41 44 839 21 11 1-800-755-6701 customerservice@katadyn.ch...
- Page 10 Template for Filter Element Hole Quick Starter Guide Page 10/11...
- Page 11 Template for Outlet Tap Hole Quick Starter Guide Page 11/11...
