INTRODUCTION
The SP-37 is a secondary surge protector designed to be mounted on a load center at the power
service
entrance.
It offers a gap-type arrestor and is easily wired into existing
no exposed terminals.
BLACK
022701-29X
WHITE
INSTALLATION
The SP-37 must be mounted horizontally as shown.
•
Never mount the SP-37
The arrestor may not "clear" properly if mounted in the vertical position.
•
The SP-37 should never be mounted with the
vent holes obstructed.
•
This unit is only for use in
weather, such
as
•
Never install on the "line" side of a branch breaker on a load
center.
I&M 010836-7
Revised 11/95, 6/00, 8/14
Doc. No.: SIG-00-00-09 Version A.1
010900-53X
vertically.
areas
protected from the
inside
a
bungalow or equipment
Installation & Maintenance
Power Line Surge Protector
Model SP-37
RED
010802-7X
case.
Siemens Industry, Inc., Rail Automation
2400
Nelson
1
systems.
It has
Pkwy., Louisville KY
