The heat transfer medium must be water or other nontoxic fluid having a toxicity rating
or Class of 1, as listed in Clinical Toxicology of Commercial Products, 5th edition.
The pressure of the heat transfer medium must be limited to a maximum of 30 PSIG by
an approved safety or relief valve.
Installation and
Operating Manual
CAUTION:
IWT SERIES
Indirect Water Heaters
IWT 40
IWT 80-Max
IWT 50
IWT 119-Max
IWT 65
IWT 80
IWT 119

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IWT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IBC IWT Series

Summary of Contents for IBC IWT Series

  • Page 1 Installation and Operating Manual IWT SERIES Indirect Water Heaters IWT 40 IWT 80-Max IWT 50 IWT 119-Max IWT 65 IWT 80 IWT 119 CAUTION: The heat transfer medium must be water or other nontoxic fluid having a toxicity rating or Class of 1, as listed in Clinical Toxicology of Commercial Products, 5th edition.
