Vision Fitness Deluxe Console Calibration Manual

Calibration Guide
Deluxe Console
Models: E1500 (CB143), E3200 (CB142), R1500 (RB133), R2050 (RB134), R2250 (RB135)

ENTERING ENGINEERING MODE

• Press and hold the
"UP"

ENTER SPECIFIC ENGINEERING MODE

Use the arrows to scroll through the following engineering mode options:
P1 – Set Max Time
P2 – Set User Time
P3 – Set User Age
P4 – Set Weight
P5 – Default Resistance Level
P6 – Default Language
P7 – Unit
P8 – Machine Type
P9 – Accumulated Data
P10 – Display Test
P11 – Hardware test
P12 – Beeper Mode
P13 – Version
Press to select the mode you wish to enter.
"ENTER"

WORKING IN SPECIFIC ENGINEERING MODES

SET MAX TIME

• Use the arrows to set the max time a program can run, from 20 to 99 minutes.
• Press to save.
"ENTER"
• Press and hold
"START"

SET USER TIME

• Use the arrows to set your default time from 10 to 99 minutes.
• Press to save.
"ENTER"
• Press and hold
"START"

SET USER AGE

• Use the arrows to set your default age from 10 to 100.
• Press to save.
"ENTER"
• Press and hold
"START"

SET WEIGHT

• Use the arrows to set your default weight from 80 to 300.
• Press to save.
"ENTER"
• Press and hold
"START"

DEFAULT RESISTANCE LEVEL

• Use the arrows to set your default resistance level from 1 to 20.
• Press to save.
"ENTER"
• Press and hold
"START"
Date of last revision: 7.08
Arrow and Arrow simultaneously for approximately three seconds.
"DOWN"
for three seconds to exit this mode.
for three seconds to exit this mode.
for three seconds to exit this mode.
for three seconds to exit this mode.
for three seconds to exit this mode.
36
BIKE.CALIB.DELUXE.CB143.CB142.RB133.RB134.RB135.REV1
