- Page 1 PREMIER UPPER BOARD ENGINEERING GUIDE S T A N D A R D C O N S O L E F O R : (T9200 PREMIER, T9500 PREMIER, T9600 PREMIER, T9250 PREMIER, T9450 PREMIER, T9700S, T9700HRT) TREADMILL.PREMIERENG.REV2 Date of last revision: 2.06...
- Page 2 Premier Upper Board: Engineering Guide ENGINEERING MODE The user must hold down for 5 seconds after powering up the treadmill to “ELEVATION UP” “SPEED DOWN” enter the engineering menus. The P6 menu appears with the software version in the message center along with the model number.
- Page 3 Premier Upper Board: Engineering Guide T9200/T9250/T9450 VARIABLES (continued) Address Description Default Value Min.Value MaxValue Scroll Speed Deck Lubrication (T9700 only) Clean Message (T97000 only) Check Motor Brushes (T9700 only) Exit Mode (Exits Eng 1) T9500/T9600/T9700S/T9700HRT VARIABLES Address Description Default Value Min.Value...
- Page 4 Premier Upper Board: Engineering Guide CONFIGURATION Modify the units by pressing the speed arrows to select MI or KM.Press and hold to save. “SELECT” T9250 T9500 0-12% elevation 0-12% elevation 0.5-10 mph/ 0.8-16kph 0.5-12 mph/ 0.8-20 kph T9450 T9600 0-12% elevation 0-15% elevation 0.5-10 mph/ 0.8-16kph...
- Page 5 Premier Upper Board: Engineering Guide ENG 3: BURN IN MODE The burn in mode can be used to run tests that require the treadmill to continually run. The program is based on the 5k program. Segment changes will occur, depending on the treadmill configuration. When the system reaches the last segment, it loops to the first segment.
- Page 6 Premier Upper Board: Engineering Guide ERROR MESSAGES Three types of errors can occur; speed, elevation, and EEPROM software error. All three use the same display to indicate the error, with the error number appearing in the main window. An elevation error shuts down the treadmill and disables normal operation.
- Page 7 Premier Upper Board: Engineering Guide USER ENGINEERING MODE (Models T9700S, T9700HRT, & PREMIER Only) Your Treadmill offers a User Engineering Mode that can access certain data and help to troubleshoot your Treadmill. User Engineering Mode is designed for you to access functions that will not affect important Treadmill settings. To...
- Page 8 Premier Upper Board: Engineering Guide USER ENGINEERING MODE (Models T9700S, T9700HRT, & PREMIER Only) P17 - ELEVATION ERRORS P17 allows you to clear an elevation error. This will allow you to operate the Treadmill without elevation. Press and hold to clear.
