Thermostat Operation Thermostat Operation LCD Display System Button See page 6 for details about Selects the operation mode on your HVAC system. this display readout. Selecting HEAT turns on the heat mode. Selecting Glow in the dark light button COOL turns on the cool The glow in the dark light mode.
Thermostat Quick Reference Thermostat Quick Reference Battery Door Information Important: The low battery icon is displayed when the AA battery power is low. Whenever the thermostat detects low battery voltage Replace with from the AA batteries, the low battery icon will begin flashing 2 AA Alkaline batteries.
Page 5
Thermostat Quick Reference Thermostat Quick Reference Indicates current room temperature Indicates if heating or cooling equipment is running Hold Indicator: Displayed when the thermostat is in permanent hold Low Battery Indicator Energy Efficient Globe: Indicates the setpoint temperature chosen is a efficient choice.
Setting the Humidity Setting the Humidity Setting Target Humidity Setpoint Setting Target Humidity Setpoint Follow the steps below to change your target humidity setpoint. Ambient humidity will flash in the time field when Humidify or De-Humidify is set to ON. Press the HUMIDITY key Use the key to select the target humidity setpoint.
Page 7
Setting the Humidity Setting the Humidity Recommended Heating Settings: The table on page 11 shows recommended indoor humidity levels in relation Outside Recommended to outdoor temperatures during heating (adding humidity). Temperature (0˚F) Relative Humidity +20˚ and above 35% to 40% +10˚...
Programming Programming Set Time Set Program Schedule For Four Time Periods (If using programming) (WAKE, LEAVE, RETURN, SLEEP or OCCUPIED 1, UNOCCUPIED1, OCCUPIED 2, UNOCCUPIED 2) Follow the steps below to set the day of the week and current time: To customize your 5+1+1 Program schedule, follow these steps: 1.
Page 9
Programming Programming Set Program Schedule For Two Time Periods Saturday: (OCCUPIED, UNOCCUPIED) Repeat steps 4 through 7 for the Saturday WAKE/OCC1 time period, for the To customize your 5+1+1 Program schedule, follow these steps: Saturday LEAVE/UNOCC1 time period, for the Saturday RETURN/OCC2 Weekday: time period, and for the Saturday SLEEP/UNOCC2 time period.
Programming Features Temporary & Permanent Hold Feature Saturday: Repeat steps 4 through 7 for the Saturday OCCUPIED time period Temporary Hold: The thermostat will display HOLD and RUN SCHED and for the Saturday UNOCCUPIED time period. on the bottom of your screen when you press the Sunday: key.
Page 11
Features Features Filter Change & Other Reminders If your HVAC contractor has configured the thermostat to remind Energy Efficient Globe Note: you when the air filter needs changed, you will see a reminder in the display when your air filter needs to be changed. The energy efficient globe indicates the occupant is making an energy efficient choice in temperature control.
Features Warranty Information Filter Change & Other Reminders Warranty Registration Your new thermostat has a 5 year limited warranty. You must register Keypad Lockout Note: your thermostat within 60 days of installation. Without this registration the warranty period will begin on the date of manufacture. Keypad lockout provides the option to disable some or all of the For warranty issues please contact the HVAC professional that buttons on the thermostat.
Page 13
Cut Out For Warranty Registration www.pro1iaq.com...
