Page 1
SERVICE MANUAL Bass Treble Level Level Level Level Pgm Rev Gain Gain Phono Phono Normal Reverse Line Line Bass Treble Bass Treble 10dB 10dB 10dB 10dB 10dB 10dB Balance Balance Effect Effect Phones Vu-meter Pfl1-2 Ch 1 Ch 2 INPUT 1 CUT INPUT 2 CUT HAK 360 Performance Mixing Instrument...
Page 2
SERVICE MANUAL HAK360 INDEX BLOCK DIAGRAM SCHEMATICS Main schema Potentiometer schema COMPONENTS LOCATION SCHEMA AND PARTS LIST Main circuit Potentiometer circuit TECHNICAL CHARACTERISTICS WIRING DIAGRAM MECHANICAL DIAGRAM PACKING DIAGRAM...
Page 27
Verify the SHAPE 1 response curve, which should show a smooth transition at its left and a faster transition when turning it to the right. Verify the CROSSFADER sweep and attenuation. Check the REVERSE function switch, which, when used, inverts the crossfader’s functioning. Verify the SHAPE response curve, which should show a smooth transition at its left and a faster transition when turning it to the right.
Page 28
Verify the HEADPHONES output; when the MONITOR selection switch is set to PFL, sliding the potentiometer from one side to another will allow us to hear channel one (PGM1) and two (PGM2); when slided to the center position, both signals are mixed. When the MASTER option is selected, the slider doesn’t operate.
Page 30
Heat Shrink code: FCMC00TR10 16.1030.00.80 16.1029.00.80 JUMPER PIN CONFIGURATION. TOP VIEW FACTORY ADJUSTED OUT 1 OUT 2 +6dB +6dB OUT 1 L OUT 1 R OUT 2 L OUT 2 R...
