Assembly / Connection

Connecting the gun

OptiSelect Pro GM04-CF
Rev. 00 03/20
The gun is delivered ready-to-use by the manufacturer. Just a few cables
and hoses must be connected.
The compressed air must be free of oil and water!
The gun is connected as follows:
1. Connect the red quick release connection (with integrated powder
stop) with the Quick release coupling of the conveying air hose.
–
The conveying air hose must already be connected to the output
1.2 on the rear side of the control unit.
2. Connect the black quick release connection (with integrated powder
stop) with the Quick release coupling of the supplementary air hose.
–
The supplementary air hose must already be connected to the
output 1.3 on the rear side of the control unit.
3. Connect the conveying air hose as well as the supplementary air
hose to the gun
4. Lay out the gun cable, conveying air hose and supplementary hose
and bind them using Velcro strips (included)
5. Connect the gun cable plug to the socket 2.3 on the rear side of the
control unit
6. Thread the enclosed nut with screw cap (4) onto the fluidizing air
connection and closing coupling (5) onto the electrode rinsing air
connection
