GTCO CalComp DrawingBoard VI Quick Start

D r a w i n g B o a r d V I

Contents

Verify that your DrawingBoard VI package includes the following:
DrawingBoard VI digitizing tablet
Transducer (corded or cordless pen, 4-button cursor,
or 16-button cursor)
USB Cable
DrawingBoard VI User's Guide (visit gtcocalcomp.com)
DrawingBoard VI Quick Start (this document)
Warranty Sheet
Check the insert in the large packing
box for some of the items listed here.
Some digitizing applications (typically, non-Windows CAD applications where the tablet is used solely as
a digitizer with no mouse functions) may not require the use of the TabletWorks software. If you need
to configure your DrawingBoard VI for use with a third-party application, please refer to the
configuration instructions in the DrawingBoard VI User's Guide, found on our website gtcocalcomp.com
Install the software first, then set up the hardware connections for USB (or the optional serial).

Software Configuration

Software drivers provide the communication bridge between your software application and the DrawingBoard VI. GTCO
CalComp TabletWorks supports reduced functionality Wintab and TabCon-compatible applications. If you're not sure about your
application's driver requirements, contact your application vendor.

Installing Tabletworks

Visit gtcocalcomp.com/software-downloads/ to download.
TM
Quick Start

Optional Equipment

RS232 cable with 9-pin connector for serial
connection
Power supply – required only for a serial
installation
Accessory Tray
Plan Holder
Universal Mounting Brackets
Table Feet
1
