Bircher PrimeMotion C Translation Of The Original Instructions

EN ISO
9001
Quality
international
level
PrimeMotion
Translation of the original instructions

General

PrimeMotion C

Safety instructions

1
Observe the national and international regulations on door safety.
Only trained, qualified personnel may mount and start up the detector.
The unit may only be opened and repaired by Bircher Reglomat.
The unit may only be operated from a safety extra-low voltage (SELV) system with safe electrical separation.
Always consider the safety functions of your application as a whole, never just in relation to one individual section of the system.
The installer is responsible for carrying out a risk assessment and installing the detector and the door system correctly.
Avoid touching any electronic components.
The door drive and transom profile must be earthed correctly.

Start-up

Recommended start-up sequence: I. Mounting
Montage
2
I
1. Remove cover hood
Mounting of the detector
1. Position drill template
2. Drill the holes, remove drill template
3. Lay cable and mount detector
3

Electrical connections

PrimeMotion C
II
white
Power
Supply
brown
green
Potential-
free
yellow
output

Mechanical fine tuning

4
Manual settings of the
inclination
0° ... +45° in 5° steps
+
– –
+ +
– –
Manual settings of the
pivoting
– 20° ... +20° in 5° steps
+ +
– –
–
+
C
Radar field
Radarfeld
II. Connection
2. Lay and connect cable
Controller
12–36 VDC
white
+
12–28 VAC
3m
brown
Cable GND
yellow
green
Controller input
Low Active
Wide radar field
Inclination angle: 35°
0m
1m
2m
3m
4m
min. = 1.6 x 0.8, max. = 4.8 x 2.3 m (WxD)
Microwave motion detector for opening
3. Mount detector
PrimeMotion C
Power white
Supply
brown
green
Potential-
free
output yellow
turn 90°
90°
0m
1m
2m
automatically controlled doors
Hood
Light window detector indication
no function
Cable bushing

Mounting

Microwave module
LED microwave: green
Potentiometer
12–36 VDC
white
+
12–28 VAC
green
3m
brown
GND
Cable
yellow
Controller input
High Active
Narrow radar field
Inclination angle: 35°
0m
1m
2m
3m
4m
min. = 0.8 x 1.6, max. = 2.3 x 4.8 m (WxD)
Controller
0m
1m
2m
