OLIMEX© 2020
CHAPTER 6: SCHEMATICS
6. Introduction to the chapter
In this chapter is located information about the schematics describing logically and physically MOD-IO.
6.1 Eagle schematic
Latest MOD-IO schematics may be found at its web-page in the "HARDWARE" section:
https://www.olimex.com/Products/Modules/IO/MOD-IO/
The board and schematic files are usually packed in a zip archive.
We mostly use Eagle by Cad Soft 4.16r2 for designing. However, the files should be compatible with the
latest Eagle available. Cad Soft offers a trial version of their software that allows you to inspect
schematics and board files (without being able to modify them).
This work is licensed under the Creative Commons Attribution-ShareAlike 3.0 Unported License. To
view a copy of this license, visit http://creativecommons.org/licenses/by-sa/3.0/.
If you are looking for a schematic of an older revision of the board and it isn't available at our web site
you may request it by the support e-mail.
Page 25 of 30
MOD-IO user's manual
