- Page 1 OPERATING INSTRUCTIONS LEHLE SUNDAY DRIVER II...
- Page 2 1999. Your new LEHLE SUNDAY DRIVER II com- prises only the very best components. Every assembly of your LEHLE SUNDAY DRIVER II has been made and tested in Germany.
- Page 3 (unbalanced and balanced) booster DI box with preamp Typical uses of the LEHLE SUNDAY DRIVER II in the studio as recording preamp recording preamp with LEHLE P-SPLIT III signal flow diagram LEHLE GmbH · Germany · www.lehle.com · support@lehle.com...
- Page 4 INTRODUCTION The LEHLE SUNDAY DRIVER II is a high- dB. To exploit the dynamics of tube am- end preamp and DI box all in a conveni- plifiers to the full, the input voltage is also ently compact format. Its circuit is based...
-
Page 5: Technical Data
Total harmonic distortion 0.008 % (0 dBu, 1 kHz) Frequency range 20 Hz – 100 kHz Input impedance D-mode 1 MΩ Input impedance S-mode 5 MΩ Output impedance 220 Ω Max gain 18 dB LEHLE GmbH · Germany · www.lehle.com · support@lehle.com... -
Page 6: General Description
1 MOhm, ef- treble pickups. ficiently eliminating sound losses caused LEHLE GmbH · Germany · www.lehle.com · support@lehle.com... - Page 7 9 – 15 V. the gain knob is turned up. In order for the LEHLE SUNDAY DRIVER II 3. OUTPUT SOCKET to work flawlessly, it needs a current sup- Connect your target device here.
- Page 8 7. BASE AND FIXING turbed on stage or during transportation. If required, mount the LEHLE SUNDAY DRIVER II to a pedalboard using the The LEHLE SUNDAY DRIVER II with its mounting kit. discrete Class A JFET circuitry performs two functions simultaneously - reducing...
-
Page 9: Typical Uses
The LEHLE SUNDAY DRIVER II is de- S U N D AY D R I V E R signed to perform both tasks perfectly. M A D E I N G E R M A N Y... -
Page 10: Device Connection
LEHLE SUNDAY DRIVER II AS A LINE DRIVER DEVICE CONNECTION Input Instrument Output Input effect(s) S U N D AY D R I V E R M A D E I N G E R M A N Y Electric guitarists and bassists often like It’s easy to get an idea of how much... - Page 11 Output socket (3) of such cases is to use one or more LITT- the LEHLE SUNDAY DRIVER II. LE LEHLE III or LEHLE D.LOOP SGoS, so 3. Switch the S/D selector (2) in the D po- that the effects can be switched passively sition, for “Driver“.
- Page 12 LEHLE SUNDAY DRIVER II AS A CABLE DRIVER DEVICE CONNECTION 20 m Input Instrument Output Amplifier S U N D AY D R I V E R M A D E I N G E R M A N Y...
- Page 13 Output Amplifier LEHLE P-SPLIT III If you play on very big stages and need HOW TO DO THIS WITH A LEHLE P- long cables over a large distance we SPLIT III recommend transmitting the signal bal- 1. Connect your instrument to the Input anced.
- Page 14 LEHLE SUNDAY DRIVER II AS A BOOSTER DEVICE CONNECTION Input Instrument Output Amplifier S U N D AY D R I V E R M A D E I N G E R M A N Y The LEHLE SUNDAY DRIVER II can be...
- Page 15 LEHLE SUNDAY DRIVER II AS A DI BOX WITH PREAMP DEVICE CONNECTION Input Instrument Output Mixer or stage box S U N D AY D R I V E R M A D E I N G E R M A N Y...
- Page 16 The third conductor is the screening, and again constitutes the signal ground (Sleeve, XLR Pin 1). JACK CABLE Sleeve Ground Pin 1 Ring Pin 3 Signal in mirrored phase Signal in phase Pin 2 LEHLE GmbH · Germany · www.lehle.com · support@lehle.com...
- Page 17 TYPICAL USES IN THE STUDIO RECORDING PREAMP The LEHLE SUNDAY DRIVER II gives top performances not only on stage and in the concert hall, but also in the recording studio. Its wide 20 to 100,000 Hz transmission range and extremely good signal-to-...
- Page 18 2. Connect the output (3) of the LEHLE SUNDAY DRIVER II to the input of the au- Here, you can use the LEHLE SUNDAY dio interface (unbalanced or balanced).
- Page 19 5. Adjust the Gain controller (6) so that If the inputs are balanced you can tap the the signal is optimal for your audio inter- LEHLE SUNDAY DRIVER II’s output in bal- face. anced with a TRS jack. 6. Done! For both take a look at “4.
- Page 20 LEHLE SUNDAY DRIVER II AS A RECORDING PREAMP COMBINED WITH THE LEHLE P-SPLIT III I S O D I R P- S P L I T S U N D AY D R I V E R M A D E I N G E R M A N Y...
- Page 21 2. Connect the output (3) of the LEHLE noise. SUNDAY DRIVER II to the input socket of Please read the LEHLE P-SPLIT III operat- the LEHLE P-SPLIT III. ing manual for a precise explanation of 3.
- Page 22 LEHLE SUNDAY DRIVER II SIGNAL FLOW DIAGRAM GAIN-CONTROLLER ( ) INPUT ( ) OUTPUT ( ) S/D SWITCH ( ) LEHLE GmbH · Germany · www.lehle.com · support@lehle.com...
- Page 23 LEHLE GmbH · Grenzstrasse 153 · 46562 Voerde · Germany www.lehle.com · support@lehle.com LEHLE SUNDAY DRIVER II OPERATING INSTRUCTIONS EN V1.0 · 2019-08-01 Copyright 2019 by LEHLE LEHLE GmbH · Germany · www.lehle.com · support@lehle.com...
