BLIZZARD BLAST SERVICE MANUAL
For Additional Information or for an Electronic Copy of This Manual Visit Our Website
www.JENNISONGAMES.com
VERSION 0.5
Jennison Entertainment Technologies Corporation
822 South Nova Road • Daytona Beach, Florida 32114 • U.S.A.
Toll Free Number: 1-855-JET-GAME
Phone Number: 1-386-255-1599
Fax Number: 1-386-255-1589
MANUFACTURED BY:
Service Email: Service@JennisonGames.com
Information Email: Info@JennisonGames.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jennison Entertainment Technologies BLIZZARD BLAST
Summary of Contents for Jennison Entertainment Technologies BLIZZARD BLAST
- Page 1 BLIZZARD BLAST SERVICE MANUAL VERSION 0.5 MANUFACTURED BY: Jennison Entertainment Technologies Corporation 822 South Nova Road • Daytona Beach, Florida 32114 • U.S.A. Toll Free Number: 1-855-JET-GAME Phone Number: 1-386-255-1599 Service Email: Service@JennisonGames.com Fax Number: 1-386-255-1589 Information Email: Info@JennisonGames.com For Additional Information or for an Electronic Copy of This Manual Visit Our Website...
-
Page 2: Safety Notifications
Follow all instructions contained within this manual and do not make any modifications to the game without first contacting Jennison Entertainment Technologies. DANGER All danger messages are marked in RED boxes. Failure to adhere to these messages could result in personal injury or injury to others. -
Page 3: Epilepsy Warning
Play in a well-lit room Do not play when you are drowsy or fatigued If you or any of your relatives have a history of seizures or epilepsy, consult a doctor before playing. Jennison Entertainment Technologies Blizzard Blast Service Manual Page 4... - Page 4 BLIZZARD BLAST, CAUTIONS, & NOTICES WARNING Make sure that the 115/230 VAC selector switch is properly selected on all power supplies for the correct line voltage at the installation site. WARNING This unit is suitable for INDOOR use only. The game should not be placed in damp environments or in areas within close proximity to the ocean.
-
Page 5: Fcc Compliance
BLIZZARD BLAST complies with this requirement and the following statement is posted on all units. This equipment has been tested and found to comply with the limits for a Class “A”... -
Page 6: Rohs Compliance
As of January 2016, Jennison Entertainment Technologies has tested all components used in the manufacturing of BLIZZARD BLAST. All components have been found to be within the standards set forth for RoHS compliance by the European Union. Test reports are available and will be provided upon request. - Page 7 GAME SETTINGS & PROGRAM BLIZZARD BLAST has been designed to include a software program where all game settings are easily managed through the use of a simple dip switch changes Although the software is very simple to navigate, we highly recommend reading the following programming section to fully understand how to make changes to the software and how each change will affect the machine.
- Page 8 Under the rules and regulations governed by the State of New Jersey Legalized Games of Chance Control Commission, there are certain requirements for amusement and redemption games. A certain version of software has been designed to allow Blizzard Blast to be operated within the State of New Jersey. This version of the software complies with the following requirements: 1) Maximum allowable wager per player dose not exceed $10.00 per game.
- Page 9 SEG # 3 SEG # 2 SEG # 1 USD $2.00 GAME PLAY - (SCORE STATE D) BONUS 1000 SEG # 4 SEG # 3 SEG # 2 SEG # 1 Jennison Entertainment Technologies Blizzard Blast Service Manual Page 27...
- Page 10 GAME SETTINGS - DIP SWITCH SETTINGS (SWITCH # 1) All game settings in Blizzard Blast can be programmed using the three dip switch banks on the I/O board. The switches are Switch # 1 (SW1), Switch # 2 (SW2), and Switch # 3 (SW3). Reference the chart below to make program changes including the number of coins required to start the game, the length of game play, and the score group options for SWITCH # 1 (SW1).
- Page 11 SW11 SW12 SW13 SW14 SW15 SW16 SW17 SW18 $0.50 GAME PLAY $1.00 GAME PLAY $1.50 GAME PLAY OFF OFF $2.00 GAME PLAY NOT CURRENTLY USED NOT CURRENTLY USED NOT CURRENTLY USED Jennison Entertainment Technologies Blizzard Blast Service Manual Page 29...
- Page 12 GAME SETTINGS - DIP SWITCH SETTINGS (SWITCH # 2) All game settings in Blizzard Blast can be programmed using the three dip switch banks on the I/O board. The switches are Switch # 1 (SW1), Switch # 2 (SW2), and Switch # 3 (SW3). Reference the chart below to make program changes including the number of tickets per score, shake time, and the handle speed frequency for SWITCH # 2 (SW2).
- Page 13 GAME SETTINGS - DIP SWITCH SETTINGS (SWITCH # 3) All game settings in Blizzard Blast can be programmed using the three dip switch banks on the I/O board. The switches are Switch # 1 (SW1), Switch # 2 (SW2), and Switch # 3 (SW3). Reference the chart below to make program changes including double score play, duel meters, and various testing options for SWITCH # 3 (SW3).
- Page 14 MAIN BOARD INPUTS BLIZZARD BLAST - MAIN BOARD INPUT IC (74HC245N) CHART INPUT # CONTENT PICTURE COIN UP SIGNAL BILL ACCEPTOR TICKET RESET TICKET SIGNAL # 1 TICKET SIGNAL # 2 BLIZZARD BUTTON # 1 BLIZZARD BUTTON # 2 MIDDLE SENSOR...
- Page 15 The Blizzard Blast input/output board utilizes 5 input IC's to control all inputs used within the game. In Blizzard Blast, only TWO of the FIVE IC's are used. You may use the THREE spare input IC's in U09, U11, &...
-
Page 16: Main Board Outputs
MAIN BOARD OUTPUTS BLIZZARD BLAST - MAIN BOARD IC (ULN2803) OUTPUT CHART OUTPUT # CONTENT PICTURE U23 IS NOT UTLIZED IN BLIZZARD BLAST. THIS SPARE IC CAN BE USED IN U27 OR U29 TO RECITFY POTENTIAL ISSUES WITH THOSE IC'S. IF YOU SWAP IC'S, BE SURE TO PUT THE DEFECTIVE IC BACK INTO U23 BEFORE POWERING THE UNIT ON. - Page 17 MAIN BOARD OUTPUTS - CONTINUED BLIZZARD BLAST - MAIN BOARD IC (ULN2803) OUTPUT CHART OUTPUT # CONTENT PICTURE COIN COUNTER TICKET COUNTER TICKET DRIVE # 1 TICKET DRIVE # 2 COIN LOCK SINGLE PLAYER SENSOR DOUBLE PLAYER SENSOR Jennison Entertainment Technologies...
