Argox PT-60 Quick Start Manual

PT-60 Mobile Computer
Quick Start Guide
http;//www.argox.com

Front View

Touch Screen
Stylus
Reset Button
6
7
8
PT-60
See User Manual for more information
Charging the Main Batteries at least 16 hours for the first time
1.
2. Please cold rest (press reset and power button simultaneously) and
make sure system reboot then start to charge.
It may take up to 2 hours to fully charge the empty backup battery.
The first time charge should be for at least 16 hours to insure a
proper charge
After you have initially charged your device for about 8 hours, the
device is ready to be used. You can now start up your device where
you'll calibrate the display, learn some basic stylus usage, and set
up the system time zone, date and time.
Scan Button
Connector
1
2
3
4
5
Battery Cover Latch
Speaker
Power Button
Scan Window
When the Function button is
pressed, an icon appears in
the operation system
1. Scan key
2. Cursor key
3. 10-key pad
4. Function key
Function key
Use this key to launch applications and select items (show on the keypad in
yellow.
Press the "FUNC" key once to activate this mode followed by another key
Alpha key
Use this key to access the secondary layer of characters and actions.
Press the "Alpha" key once to lock the keypad in the Alpha state
Press the "Alpha" key second time to return to the normal state
KEYPADS

Back View

SD Installation

Remove the cover
Function activated icon
5. Power key
6. ESC key
7. Alpha key
8. Reset
Quick Start Guide
Battery Cover
SD Card Cover
